Product Introduction
The GE IC693BEM321 is an I/O LINK Master Module developed for use within the GE Series 90-30 Programmable Logic Controller (PLC) system. As an integral component of distributed I/O systems, the IC693BEM321 serves as a communication bridge between the CPU and I/O devices connected via I/O LINK. This module significantly simplifies wiring while enhancing the flexibility of control systems through distributed architecture.
The IC693BEM321 supports Siemens-compatible I/O LINK protocols and allows integration with remote I/O slave modules over a single twisted pair of wires. This enables engineers to deploy efficient and cost-effective automation solutions, particularly in environments where space, complexity, and wiring costs are major concerns.
The module is designed with rugged industrial applications in mind, featuring reliable communication performance, compact form factor, and high data throughput for demanding environments.
Product Specifications
| Parameter | Description |
|---|---|
| Manufacturer | GE Fanuc Automation |
| Product Code | IC693BEM321 |
| Product Type | I/O LINK Master Module |
| Series | GE Series 90-30 |
| Protocol | Siemens-compatible I/O LINK |
| Number of Channels | 1 Master Channel |
| Max Number of Slaves | Up to 62 I/O LINK slave devices |
| Baud Rate | 38.4 kbps (I/O LINK communication speed) |
| Power Supply Requirement | Supplied via the PLC backplane (5V DC nominal) |
| Communication Cable | Single twisted pair (shielded recommended) |
| Mounting Type | Rack-mounted (Series 90-30 baseplate) |
| Hot Swap Support | No |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Relative Humidity | 5% to 95% (non-condensing) |
| Dimensions (H×W×D) | 119 × 33 × 91 mm |
| Weight | 0.25 kg |
| Compliance | CE, UL, CSA |
| Slot Occupation | Occupies 1 slot in the baseplate |
Applications
The GE IC693BEM321 is well-suited for use in various industrial automation and control applications. Key areas include:
-
Factory Automation: Ideal for integrating distributed I/O on production lines and assembly systems.
-
Process Control: Used in chemical, oil & gas, and water treatment plants to collect sensor and actuator data from field devices.
-
Material Handling: Interfaces with conveyor systems and robotic arms in logistics and packaging facilities.
-
Building Automation: Efficient for HVAC, lighting, and energy management systems.
-
OEM Machine Integration: Flexible for use in specialized machinery developed by original equipment manufacturers.
Product Advantages
-
Reduced Wiring Complexity: The use of a single twisted pair for multiple I/O devices minimizes wiring cost and space.
-
Modular Design: Integrates seamlessly into GE’s Series 90-30 platform, promoting scalability.
-
Flexible Device Integration: Compatible with a wide range of I/O LINK slave modules, allowing device-level control.
-
Improved Diagnostics: Offers status monitoring and diagnostic feedback, enhancing maintenance efficiency.
-
High Reliability: Built to operate in industrial-grade conditions with excellent EMI immunity.
-
Simple Configuration: Easily configured through GE’s programming tools without complex network programming.
-
Cost-Effective: Lowers total installation cost through streamlined I/O expansion.
Frequently Asked Questions (FAQ)
-
Q: What type of PLC is the IC693BEM321 compatible with?
A: It is designed for the GE Fanuc Series 90-30 PLC systems. -
Q: How many I/O devices can I connect to this module?
A: You can connect up to 62 I/O LINK slave devices. -
Q: Can this module be hot-swapped during operation?
A: No, the IC693BEM321 does not support hot swapping. -
Q: What kind of wiring is needed for communication?
A: It uses a shielded single twisted pair communication cable. -
Q: Is the module programmable independently?
A: No, it is configured through the main Series 90-30 PLC programming software. -
Q: What is the communication speed of the module?
A: The I/O LINK communication speed is 38.4 kbps. -
Q: Is this module suitable for outdoor use?
A: No, it is meant for installation in control cabinets or indoor environments with proper environmental controls. -
Q: Does the module support diagnostics?
A: Yes, it supports basic diagnostics for channel and device health status. -
Q: What kind of applications use this module?
A: It’s commonly used in manufacturing, process control, and distributed automation systems. -
Q: How is this module mounted in the system?
A: It mounts into a standard 90-30 series baseplate and occupies one slot.
