Product Introduction
The GE IC693CBL301 is a standard programming cable designed for GE Fanuc Series 90-30 programmable logic controllers (PLCs). This cable is essential for establishing a communication link between a PLC CPU module and a programming device, such as a PC or handheld programmer. Known for its reliability and durable construction, the IC693CBL301 provides a secure and stable connection necessary for programming, monitoring, and diagnostic activities. It supports RS-232 serial communications and is engineered to meet industrial automation demands with high compatibility and performance stability.
Product Specifications
| Parameter | Details |
|---|---|
| Model Number | IC693CBL301 |
| Product Type | Programming Cable |
| Compatible Systems | GE Fanuc Series 90-30 PLCs |
| Interface Type | RS-232 (DB9 Male to DB9 Female) |
| Cable Length | 2 m |
| Voltage Rating | Not Applicable |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Insulation Material | PVC |
| Wire Gauge | 26 AWG |
| Shielding | Foil Shielded |
| Weight | 0.25 kg |
Product Applications
The GE IC693CBL301 cable is primarily used in industrial automation environments. Its key applications include:
-
PLC Programming: Used to connect the programmer (usually a PC with Proficy or Logicmaster software) to the Series 90-30 CPU for code upload/download.
-
Real-time Monitoring: Enables live monitoring and diagnostics of system processes.
-
Firmware Updates: Facilitates the transfer of updated firmware versions to GE PLC modules.
-
Troubleshooting and Debugging: Supports error diagnosis and performance analysis in live environments.
-
Testing & Commissioning: Commonly used during new PLC installations for system validation.
-
Field Maintenance: Essential tool for field service engineers managing GE PLC systems.
Product Advantages
-
High Compatibility: Seamlessly supports GE Fanuc Series 90-30 modules without the need for additional drivers.
-
Durable Construction: Robust insulation and shielding enhance lifespan in demanding industrial environments.
-
Ease of Use: Plug-and-play design with RS-232 connectivity simplifies setup for technicians and engineers.
-
Secure Data Transmission: Shielded cable design minimizes EMI and guarantees stable data communication.
-
Reliable Connection: Strong mechanical connector locking prevents accidental disconnection during use.
-
Portable and Flexible: Lightweight, flexible, and easily coiled for transport and storage in field toolkits.
10 Frequently Asked Questions (FAQs)
Q1: What is the primary use of the IC693CBL301 cable?
A1: It is used for connecting a GE Series 90-30 PLC to a programming device via RS-232 serial communication.
Q2: Is this cable compatible with Series 90-70 or VersaMax?
A2: No, the IC693CBL301 is specifically designed for Series 90-30. Other cables are recommended for 90-70 and VersaMax systems.
Q3: Can I use this cable with Windows 10-based programming software?
A3: Yes, as long as the PC has a serial port or a compatible USB-to-serial adapter, it will function correctly.
Q4: Is there any driver required for the cable itself?
A4: No, the cable does not require a driver. However, the USB-to-serial converter (if used) may require one.
Q5: How long is the cable?
A5: The IC693CBL301 has a length of 2 meters.
Q6: Can this cable be used in outdoor environments?
A6: It is not rated for outdoor or harsh environments unless additional protective measures are taken.
Q7: What should I do if the cable connection is unstable?
A7: Ensure both DB9 connectors are firmly secured. If using a USB adapter, verify that the adapter is functioning correctly.
Q8: Is the cable shielded against electrical noise?
A8: Yes, it is foil-shielded to reduce electromagnetic interference.
Q9: Does it support data transfer both ways?
A9: Yes, it allows full-duplex communication between the PLC and the programming device.
Q10: What is the part number for a replacement if this one fails?
A10: You can reorder using the same part number: GE IC693CBL301.
Related Models (Same Series or Functionally Similar)
| Model | Description |
|---|---|
| IC693CBL300 | 15-foot version of IC693CBL301 |
| IC693CBL302 | Cable with RS-232 to RS-485 converter |
| IC690USB901 | USB-to-Serial Converter Cable for Series 90 |
| IC693ACC300 | Programming cable kit with adapters |
| IC693CBL316 | Programming cable with external power support |
| IC693CBL307 | Cable for high-speed communication ports |
Popular Models from GE Fanuc
| Model | Description |
|---|---|
| IC693CPU364 | CPU module with Ethernet capability |
| IC693MDL645 | 32-Point DC Input Module (24VDC) |
| IC693PWR330 | Power Supply Module (120/240 VAC, 125 VDC) |
| IC693ALG220 | 4-Channel Analog Output Module |
| IC693MDL753 | 32-Point Relay Output Module |
| IC693CHS391 | 10-slot I/O Baseplate |
