Product Overview
The GE IC693MDL632 is a 24-Volt DC Positive Logic Output module from the GE Fanuc Series 90-30 PLC family. It is designed to provide 32 discrete output points organized in four groups of eight. These outputs are compatible with a variety of DC-powered devices, offering fast switching and reliable operation in industrial automation applications. Each group of outputs is isolated from the others, allowing for versatile wiring configurations and increased noise immunity.
With its compact design and robust electrical characteristics, the IC693MDL632 is ideal for use in distributed control systems and high-density installations where space-saving and efficiency are paramount.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | GE Fanuc |
| Product Type | Discrete Output Module |
| Series | Series 90-30 |
| Model Number | IC693MDL632 |
| Output Type | DC Positive Logic |
| Output Voltage | 24 VDC Nominal (range: 5–30 VDC) |
| Number of Outputs | 32 |
| Output Grouping | 4 groups of 8 outputs |
| Internal Power Consumption | 0.83 Watts |
| Module Type | Sink/Source (Positive Logic) |
| Diagnostics | Blown fuse indication |
| Connector Type | Removable terminal block |
| Weight | 0.2 kg |
| Dimensions | 33 × 119 × 70 mm |
| Operating Temperature | 0 to 60 °C |
| Storage Temperature | –40 to 85 °C |
| Mounting | DIN-rail or panel mount |
Applications
The GE IC693MDL632 is widely used in various industries for controlling output signals in:
-
Automated manufacturing systems
-
Packaging and assembly lines
-
Material handling systems
-
Energy and utility plant control
-
Water treatment facilities
-
OEM machinery and robotics
Its 32-point density allows for controlling multiple outputs from a single module, which is particularly beneficial in complex industrial processes.
Product Advantages
-
High Density Output: 32 outputs in a single module reduce panel space and cost.
-
Fast Switching: With sub-millisecond response time, it supports high-speed applications.
-
Group Isolation: Enhances electrical isolation for safer, flexible wiring.
-
Compact Design: Suitable for space-constrained applications.
-
Reliability: Proven durability in demanding industrial environments.
-
Compatibility: Fully integrates into GE Series 90-30 systems.
Frequently Asked Questions (FAQ)
Q1: What type of load is the IC693MDL632 suitable for?
A1: It is ideal for resistive or inductive DC loads such as solenoids, relays, and indicator lamps.
Q2: Can the module handle different voltages across output groups?
A2: Yes, each group is isolated, allowing separate voltage sources.
Q3: Does the module offer short-circuit protection?
A3: No internal protection; external fusing is recommended.
Q4: What is the maximum current per output channel?
A4: Each channel supports up to 0.5 A.
Q5: How is the module installed?
A5: It can be mounted via DIN rail or panel mount within a Series 90-30 rack.
Q6: Is configuration via software required?
A6: No configuration is required; it is recognized automatically in the system.
Q7: Can I mix this with AC modules in the same rack?
A7: Yes, it is compatible with AC and DC modules in a single rack.
Q8: Is this module hot-swappable?
A8: No, the power must be turned off before replacing the module.
Q9: Does it include diagnostic LEDs?
A9: Yes, it has LED indicators for output status monitoring.
Q10: What certifications does it comply with?
A10: The module meets CE and UL industrial automation standards.
Related or Compatible GE Models (Same/Related Series)
| Model Number | Description |
|---|---|
| IC693MDL634 | 32-Point DC Positive Logic Output, 12/24 VDC |
| IC693MDL645 | 32-Point DC Negative Logic Output, 24 VDC |
| IC693MDL340 | 16-Point AC Output, 120 VAC |
| IC693MDL241 | 8-Point Relay Output Module |
| IC693MDL930 | 8-Point Isolated Output, 120 VAC |
| IC693MDL731 | 16-Point DC Positive Logic Input, 24 VDC |
