GE IC693MDL733 Negative Logic Output Module

Product Introduction

The GE IC693MDL733 is a 24VDC Negative Logic Output Module from the GE Fanuc Series 90-30 family, engineered for reliable and efficient output control in industrial automation systems. It features 8 output points configured for negative logic (sinking) operation, meaning it provides a return path to ground for connected loads. This module is typically used in control systems that interface with field devices requiring a sinking output configuration.

Designed with industrial robustness in mind, the IC693MDL733 offers electrical isolation between the field side and the logic side, protecting the controller from potential faults in the field. Each output is equipped with LED status indicators for easy visual diagnostics. With its compatibility across a wide range of GE Fanuc PLC systems, it serves as a versatile and dependable output module for many control applications.


Product Specifications

Parameter Details
Product Type DC Output Module
Model Number IC693MDL733
Series GE Fanuc Series 90-30
Number of Outputs 8
Output Logic Negative (Sinking)
Output Voltage Range 5–30 VDC
Nominal Output Voltage 24 VDC
Max Output Current per Point 0.5 A
Max Output Current per Module 4.0 A (total for all points)
Output Leakage Current < 1 mA at 30 VDC
Output Type Transistor (sinking)
Isolation 1500 V (Field side to Logic side)
LED Indicators Yes (one per channel)
Power Consumption 80 mA from +5 VDC logic power
Response Time 0.2 ms ON / 0.2 ms OFF (typical)
Operating Temperature 0°C to 60°C
Storage Temperature -40°C to +85°C
Humidity Range 5% to 95% (non-condensing)
Dimensions (H x W x D) 150 × 100 × 70 mm
Weight 0.4 kg
Mounting Style DIN rail or panel mounting
Certifications UL, CE, CSA

Product Applications

  • Industrial Process Automation: Suitable for controlling solenoids, signal lamps, small relays, or DC contactors.

  • Packaging Equipment: Offers reliable output control for machinery actuators, motors, or other end devices.

  • Discrete Manufacturing Systems: Commonly used in automotive, electronics, and consumer goods production lines.

  • Conveyor and Sorting Systems: Interfaces with sensors and actuators to control material flow and routing.

  • HVAC and Building Control Systems: Controls auxiliary equipment such as fans, dampers, or valves.

  • Water Treatment and Utility Control: Ensures accurate control of field equipment like pumps and alarms.


Product Advantages

  • Simplified Wiring for Sinking Loads: Direct compatibility with negative logic (sinking) field devices.

  • Built-in Status LEDs: Visual feedback on the status of each output simplifies monitoring and troubleshooting.

  • Compact and Modular: Fits seamlessly into Series 90-30 systems without requiring extra panel space.

  • Reliable Electrical Isolation: Provides 1500 V isolation to protect internal circuits from field-level faults.

  • High-Speed Response: Quick switching capability meets the demands of time-critical control systems.

  • Cost-Effective for Smaller Loads: Ideal for controlling smaller devices while maintaining output granularity.


Frequently Asked Questions (FAQ)

  1. Q: What type of output logic does the IC693MDL733 use?
    A: It uses negative logic (sinking) output.

  2. Q: Can this module operate at voltages other than 24VDC?
    A: Yes, it supports a range from 5 to 30 VDC, though it is optimized for 24 VDC.

  3. Q: How many output points does it provide?
    A: The module offers 8 discrete outputs.

  4. Q: Is it possible to use this module with inductive loads?
    A: Yes, but it is recommended to use external snubbers or flyback diodes.

  5. Q: Does this module include short-circuit protection?
    A: No built-in short-circuit protection; external protection is advised.

  6. Q: What is the maximum load per output point?
    A: Each output can handle up to 0.5 A.

  7. Q: How are the outputs grouped?
    A: All 8 outputs are individually isolated but share a common return path.

  8. Q: Is it compatible with other Series 90-30 modules?
    A: Yes, it integrates seamlessly into the GE Fanuc 90-30 series rack.

  9. Q: What is the isolation voltage between logic and field sides?
    A: 1500 V of electrical isolation.

  10. Q: Can this module be replaced without shutting down the system?
    A: No, the system should be powered down for safe installation or removal.
