The GE IC693MDL740J is a 12/24 VDC Positive Logic Output Module from the GE Series 90-30 programmable logic controller (PLC) family. It is designed for applications that require digital discrete control using sourcing-type output logic. With 16 output points, this module delivers reliable and fast switching for field devices such as relays, contactors, solenoids, indicator lights, and motor starters that require positive logic DC control.

The MDL740J operates by providing voltage to the load (sourcing) when turned ON and is highly efficient in installations where consistent logic behavior and output response are crucial. The 16 outputs are divided into two groups of eight, each with a separate common for wiring flexibility. Additionally, the module is protected against overcurrent and includes status indicators for each output channel, simplifying monitoring and maintenance.

Built to last in harsh industrial environments, the MDL740J stands as a reliable workhorse in discrete output applications across industries.

---

Technical Specifications

Parameter	Specification
Manufacturer	GE Fanuc / GE Intelligent Platforms
Product Series	Series 90-30
Model Number	IC693MDL740J
Module Type	Discrete Output Module
Logic Type	Positive Logic (Sourcing)
Output Voltage Range	5 to 30 VDC (Nominal 12/24 VDC)
Number of Output Points	16
Output Grouping	2 groups of 8 points each, with separate commons
Maximum Load Current	0.5 A per point, 4 A per group
Inrush Current	5 A for 10 ms per output
Output Leakage (OFF)	< 1 mA
Turn-On Time	< 0.2 ms
Turn-Off Time	< 0.4 ms
Protection Features	Overcurrent protection, thermal shutdown
Status Indicators	Individual LEDs for each output point
Backplane Current Consumption	105 mA @ 5 VDC
Mounting	DIN rail or panel
Dimensions (H × W × D)	99 x 25 x 140 mm
Weight	0.322 kg
Operating Temperature	0°C to 60°C (32°F to 140°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Agency Certifications	UL, CE, CSA



---
