GE IC694CHS392 10-Slot Serial Expansion Backplane

Company Information
E-mail		[email protected]
Mobile		+8613666033393
Whatsapp		+8613666033393
WeChat		13666033393
Add		Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Introduction

The GE IC694CHS392 10-Slot Serial Expansion Backplane is a high-performance backplane designed for use with the GE PACSystems RX3i programmable automation controller family. It provides an efficient platform for connecting up to ten I/O and communication modules in a single rack configuration, offering both reliability and scalability for industrial control applications.

This backplane serves as a critical component in large automation systems, allowing for expansion beyond the primary CPU rack. Through its built-in serial expansion port, the IC694CHS392 enables seamless communication between the main rack and remote or auxiliary racks, ensuring consistent data flow and synchronized operations across distributed control systems.

Built to meet the demands of modern industrial environments, the backplane features a durable structure, gold-plated connectors for signal integrity, and intelligent grounding to minimize noise interference. Its design allows easy installation, maintenance, and module replacement, supporting high system uptime and flexibility for future upgrades.

---

Technical Specifications

---

Applications

The GE IC694CHS392 Backplane is used in industrial environments where system scalability, modularity, and reliable communication are critical. It provides a platform for expanding I/O capabilities, adding redundancy, or integrating additional communication modules in control systems. Typical applications include:

• Power Generation Plants: Expands control and monitoring capacity for turbine, generator, and auxiliary systems.

• Oil and Gas Facilities: Integrates additional process control modules for drilling, refining, and transport systems.

• Manufacturing Automation: Provides modular expansion for production lines and machine control networks.

• Water and Wastewater Treatment: Supports distributed control for pumps, valves, and treatment processes.

• Transportation Systems: Manages control logic for automated railway or airport systems.

• Building and Infrastructure Automation: Expands control functions for HVAC, lighting, and energy management.

The module’s robust design and easy expandability make it essential for large-scale, mission-critical control systems requiring high reliability and flexible architecture.

---

Advantages

• High System Expandability: Supports the addition of multiple I/O or communication modules without system redesign.

• Seamless Integration: Fully compatible with GE PACSystems RX3i CPUs and modules for easy system configuration.

• Reliable Data Communication: Serial expansion interface ensures fast and stable data transfer between racks.

• Durable and Industrial-Grade: Built to withstand harsh environments including temperature variations and vibration.

• Ease of Maintenance: Hot-swappable design enables quick module replacement with minimal system downtime.

• Noise Immunity: Gold-plated connectors and optimized grounding design reduce signal interference.

• Flexible Mounting Options: Can be mounted on racks or panels depending on installation requirements.

• Efficient Cooling: Natural convection cooling ensures silent and reliable operation.

• Comprehensive Diagnostics: Supports system fault monitoring through the PLC CPU interface.

• Future-Proof Design: Supports evolving automation systems by allowing scalable expansion as system demands grow.

---

FAQ

1. What is the primary function of the IC694CHS392 backplane?
   It serves as a 10-slot expansion platform for connecting additional I/O and communication modules to a PACSystems RX3i controller.

2. How does the backplane communicate with the main RX3i rack?
   It uses a dedicated serial expansion interface connected via an expansion cable to the primary CPU rack.

3. Can the IC694CHS392 support both I/O and communication modules?
   Yes, all slots are universal and can accommodate a mix of I/O, communication, and special function modules.

4. What power supply modules are compatible with this backplane?
   It supports standard RX3i power supplies that provide 5 VDC backplane power up to 2.0 A.

5. Does this backplane support redundancy or hot standby configurations?
   Yes, when used with a compatible RX3i CPU and redundancy modules, it supports redundant system architectures.

6. What is the isolation level between logic and field circuits?
   The backplane provides optical isolation to protect control logic from electrical noise and voltage transients.

7. Can the IC694CHS392 be mounted in any orientation?
   It is recommended to mount it vertically or horizontally on a panel or rack to ensure optimal cooling and accessibility.

8. What happens if the expansion cable is disconnected during operation?
   Communication with the modules on that rack will be lost, and the CPU will generate an expansion fault until the connection is restored.

9. Is there a limit to how many expansion racks can be added to an RX3i system?
   Yes, the number of expansion racks is limited by the CPU’s expansion capability, typically up to 7 racks depending on configuration.

10. Does the backplane require special configuration in the software?
    Yes, it must be defined in the RX3i configuration software to assign slot addresses and module types correctly.

---
