GE IC695CMX128 RX3i Control Memory Xchange Module

Product Introduction

The GE IC695CMX128 RX3i Control Memory Xchange (CMX) Module is an advanced high-speed data sharing module designed for GE’s PACSystems RX3i control platform. It provides a powerful mechanism for real-time deterministic data transfer between multiple controllers without the need for traditional communication protocols. The module allows direct memory-to-memory data exchange between connected controllers using reflective memory technology, ensuring data synchronization across distributed control systems with microsecond-level latency.

This module is typically used in high-performance industrial automation systems, where coordinated control and precise data synchronization between multiple controllers are required. Its large 128 MB reflective memory capacity enables fast and efficient communication in complex control architectures.

The IC695CMX128 supports fiber-optic communication over long distances, ensuring robust performance even in electrically noisy environments. It is ideal for applications such as power generation, turbine control, paper and pulp systems, and process industries, where system integrity and deterministic performance are critical.

---

Technical Specifications

---

Product Applications

The GE IC695CMX128 RX3i Control Memory Xchange Module is widely used in industrial and mission-critical automation systems that require high-speed deterministic data sharing between multiple controllers.

Key application areas include:

• Power Generation Systems: Synchronization between multiple turbines, generator control units, and distributed I/O systems.

• Aerospace and Defense Test Systems: High-speed data sharing for real-time hardware-in-the-loop (HIL) simulations.

• Pulp and Paper Industry: Coordinated control of multiple production lines for process consistency.

• Steel and Metal Processing: Real-time coordination between rolling mills, drives, and temperature control systems.

• Oil and Gas Refining: Distributed control and fault-tolerant architectures in critical production processes.

• High-availability Redundant Control Systems: Enables rapid synchronization for redundant CPU pairs and fault-tolerant PLC configurations.

---

Product Advantages

• High-Speed Deterministic Data Exchange: Reflective memory ensures consistent and predictable data sharing across all nodes.

• Large Data Capacity (128 MB): Accommodates extensive process variables and control data for complex applications.

• Low Latency Communication: Enables sub-microsecond synchronization, essential for time-critical control operations.

• Flexible Network Architecture: Supports ring or star topology, suitable for various plant layouts.

• High Reliability: Fiber-optic communication provides immunity to electrical noise and electromagnetic interference.

• Seamless Integration with RX3i Systems: Fully compatible with PACSystems RX3i architecture and programming tools.

• Enhanced System Redundancy: Ideal for redundant CPU configurations requiring high-speed data mirroring.

• Scalability: Allows up to 256 nodes, enabling easy expansion of distributed control systems.

• Robust Industrial Design: Designed to perform under harsh industrial conditions with stable operation.

• Simplified Configuration: Easy setup using standard GE configuration tools, minimizing commissioning time.

---

FAQ

1. What type of memory technology is used in the IC695CMX128 module?
   The IC695CMX128 uses reflective memory technology, allowing each node in the network to share and update data in real time.

2. How many nodes can be connected in one reflective memory network?
   Up to 256 nodes can be connected within a single CMX reflective memory network.

3. What is the typical data latency between nodes?
   The typical latency is less than 1.2 microseconds per node, depending on the network topology and fiber type.

4. Does the module support redundant network configurations?
   Yes, the module can be configured in redundant network topologies for fault-tolerant applications.

5. Which programming software supports the IC695CMX128?
   It is supported by GE’s Proficy Machine Edition software for configuration and integration.

6. What fiber types can be used with this module?
   Both single-mode and multimode fibers are supported, depending on the distance requirements of the application.

7. Can this module be mixed with other communication modules in the same backplane?
   Yes, it can coexist with other RX3i communication modules such as Ethernet, Profibus, or serial interfaces.

8. What is the maximum communication distance for the CMX network?
   Up to 10 km using single-mode fiber and up to 300 meters using multimode fiber.

9. Is synchronization handled automatically between nodes?
   Yes, data synchronization is fully automatic through the reflective memory mechanism.

10. Can the IC695CMX128 be used in redundant CPU configurations?
    Absolutely, it is commonly used for high-speed data sharing between redundant CPU pairs in critical control systems.

---
