GE IC697GDH701 Processor Module

Company Information
E-mail		[email protected]
Mobile		+8613666033393
Whatsapp		+8613666033393
WeChat		13666033393
Add		Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Introduction

The GE IC697GDH701 Processor Module is a high-performance digital signal and control processor designed for the Series 90-70 PLC system. It is specifically engineered to handle complex control algorithms, high-speed data acquisition, and real-time signal processing for demanding industrial environments.

This module integrates a dedicated coprocessor to assist the main CPU, providing enhanced computational power for process control, advanced automation, and critical monitoring tasks. The IC697GDH701 ensures accurate and rapid processing of input data from sensors, control loops, and communication interfaces, allowing optimized system performance and reliability.

Designed for seamless integration with the Series 90-70 system, the module can be installed in standard racks and works effectively with multiple CPU and I/O modules, ensuring scalability, flexibility, and maintainability in industrial applications.

---

Technical Specifications

---

Product Applications

The IC697GDH701 Processor Module is widely used in industrial automation systems where fast and accurate processing is required.

Typical Applications Include:

• Advanced Process Control: Supports complex multivariable PID loops and control algorithms.

• High-Speed Data Acquisition: Real-time monitoring of sensors and analog inputs.

• Signal Analysis: FFT, filtering, and computational analysis for vibration and process signals.

• Motor and Drive Control: Fast control for AC/DC drives, inverters, and rotational machinery.

• Power Generation and Distribution: Enhances system efficiency in energy control applications.

• SCADA Integration: Pre-processed data provided to supervisory control systems for analysis.

---

Product Advantages

• Enhanced Computation Power: Offloads complex operations from the main CPU to increase system efficiency.

• Real-Time Signal Processing: Supports FFT, PID, and filtering for precise control and monitoring.

• Compact Single-Slot Design: Saves valuable rack space while maintaining high performance.

• Seamless Integration: Fully compatible with Series 90-70 CPU and I/O modules.

• System Optimization: Reduces CPU load and improves overall response time.

• Robust Diagnostics: Provides real-time status indicators and error detection.

• Industrial Reliability: Operates reliably within standard industrial temperature and humidity ranges.

• Flexible Application: Suitable for advanced process control, energy management, and industrial automation.

• Reliable Backplane Communication: Ensures stable data transfer between CPU and module.

• Scalable System Performance: Allows expansion in complex automation environments.

---

FAQ

1. What type of processor is used in the IC697GDH701?
   It features a dedicated digital signal processor combined with control logic processing to handle high-speed computations and signal analysis.

2. Can the module operate independently from the main CPU?
   No, it functions as a coprocessor and requires integration with a Series 90-70 CPU module.

3. What types of signal processing tasks can it handle?
   It can perform FFT, filtering, PID calculations, and other real-time computational tasks for analog and digital signals.

4. Is this module compatible with all Series 90-70 CPUs?
   Yes, it integrates seamlessly with standard Series 90-70 CPU modules and expansion racks.

5. Does it require an external power source?
   No, the module draws 5 V DC power directly from the Series 90-70 backplane.

6. What environmental conditions can it operate under?
   It operates reliably from 0°C to 60°C, with humidity tolerance from 5% to 95%, non-condensing.

7. Can it support multivariable process control?
   Yes, its high-speed DSP allows multiple control loops to be processed simultaneously in real time.

8. How does it improve CPU performance?
   By handling complex mathematical and signal-processing tasks, it reduces the load on the main CPU, increasing overall system responsiveness.

9. Does it offer diagnostics and error detection?
   Yes, the module provides status LEDs and built-in error detection for operational monitoring.

10. Which industrial applications benefit most from this module?
    It is ideal for vibration monitoring, advanced process control, motor and drive control, energy management, and real-time data acquisition.

---
