GE IC697GDS701 Processor Module

Product Introduction

The GE IC697GDS701 Processor Module is a specialized digital signal processor module designed for the Series 90-70 PLC system, intended to augment the computational power of the main CPU in industrial automation applications. This module is engineered to offload complex mathematical operations, real-time signal processing, and high-speed control tasks, providing increased system responsiveness and reliability.

The IC697GDS701 incorporates a dedicated coprocessor for advanced signal processing and control algorithms. It is particularly effective in applications requiring precision data acquisition, fast analog/digital signal processing, and high-speed loop control. Designed for easy integration into Series 90-70 racks, the module enhances the system’s computational capabilities without requiring additional space or major system modifications.

Technical Specifications

Product Applications

The IC697GDS701 is used in industrial automation environments where rapid, precise data processing and control is essential.

Key Applications Include:

• Advanced Process Control: Supports multiple simultaneous PID loops and high-speed algorithms.

• Real-Time Signal Processing: Analyzes analog and digital input signals in real time.

• Vibration and Condition Monitoring: Processes data for machinery health and performance.

• Motor and Drive Control: Provides precise, fast control for AC/DC drives and rotating machinery.

• Energy and Power Management: Enhances control and monitoring in power generation and distribution.

• SCADA and HMI Integration: Supplies pre-processed data to supervisory control systems efficiently.

Product Advantages

• High-Performance DSP: Handles complex computational tasks to reduce CPU load.

• Real-Time Processing: Supports PID, FFT, filtering, and multivariable control loops.

• Compact Design: Single-slot module saves space in Series 90-70 racks.

• Seamless Integration: Compatible with all Series 90-70 CPUs and I/O modules.

• System Optimization: Improves overall response times and control precision.

• Robust Diagnostics: Provides LEDs for activity and fault indication.

• Industrial Reliability: Operates across standard industrial temperature and humidity ranges.

• Flexible Application: Suitable for advanced automation, condition monitoring, and power management.

• Efficient Backplane Communication: Ensures stable data transfer between CPU and module.

• Scalable Performance: Enables system expansion for complex industrial automation needs.

FAQ

1. What type of processor is included in the IC697GDS701?
   It contains a high-speed digital signal processor designed for real-time calculations and control logic acceleration.

2. Does the module operate independently of the CPU?
   No, it functions as a coprocessor and must be integrated with a Series 90-70 CPU module.

3. What types of tasks can this module handle?
   It supports FFT, PID control, filtering, multivariable control loops, and other high-speed signal processing tasks.

4. Is the module compatible with all Series 90-70 racks?
   Yes, it can be installed in standard Series 90-70 racks alongside compatible CPU and I/O modules.

5. Does the module require an external power source?
   No, it draws 5 V DC power directly from the Series 90-70 backplane.

6. What environmental conditions can the IC697GDS701 operate in?
   It operates reliably from 0°C to 60°C with 5% to 95% non-condensing humidity.

7. Can it support multiple control loops simultaneously?
   Yes, its high-speed DSP allows concurrent processing of multiple control loops in real time.

8. How does this module improve overall CPU performance?
   By offloading complex mathematical and signal-processing tasks, it reduces CPU load and improves system response.

9. Are diagnostics provided on the module?
   Yes, it features status LEDs and error detection capabilities for operational monitoring.

10. Which industrial applications benefit most from this module?
    It is ideal for vibration monitoring, advanced process control, motor and drive control, and real-time data acquisition.
