GE IC697MDL710 Relay Output Module

Company Information
E-mail		[email protected]
Mobile		+8613666033393
Whatsapp		+8613666033393
WeChat		13666033393
Add		Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Introduction

The GE IC697MDL710 Relay Output Module is a robust and versatile output module designed for the GE Fanuc Series 90-70 PLC system. This module provides 16 relay output channels, allowing the control of a wide range of field devices such as motors, solenoids, pilot lights, alarms, and other industrial actuators.

The IC697MDL710 supports both AC and DC loads, and each relay is individually isolated, ensuring reliable operation and minimizing interference between outputs. Its design is suitable for applications where mechanical switching is preferred over solid-state outputs, providing high inrush handling capabilities and excellent compatibility with legacy systems.

This relay output module is designed for easy integration into Series 90-70 racks, offering high reliability, flexible control, and precise switching for critical automation systems. Its solid-state control logic combined with mechanical relay outputs allows the system to handle both high and low current loads efficiently.

---

Technical Specifications

---

Product Applications

The IC697MDL710 Relay Output Module is suitable for a wide range of industrial applications requiring mechanical relay control:

• Factory Automation: Driving solenoids, actuators, pilot lights, and alarm systems.

• Process Control: Switching control valves, heaters, and pumps in chemical and oil & gas plants.

• Power Generation: Activating auxiliary systems, protective relays, and load management devices.

• Material Handling: Controlling motors, conveyor drives, and automated equipment.

• Building Automation: Operating lighting, alarms, and HVAC actuators.

• Safety and Alarm Systems: Provides isolation and reliable switching for safety-critical signals.

The relay outputs are capable of handling high inrush currents, making this module suitable for loads that require higher startup current without damaging the output device.

---

Product Advantages

The IC697MDL710 offers several technical and operational benefits:

• 16 Individually Isolated Relays: Each output is isolated, reducing cross-talk and improving system reliability.

• High Inrush Capacity: Capable of handling loads with high startup currents, up to 10 times the rated current.

• AC/DC Load Compatibility: Can switch both AC and DC devices efficiently.

• LED Status Indicators: Provides immediate visual feedback for each output channel.

• Modular and Compact Design: Fits neatly in Series 90-70 I/O racks for easy expansion.

• Reliable Mechanical Switching: Ideal for applications where mechanical contact is required.

• Flexible Control: Supports various industrial actuators and devices.

• Durable Industrial Components: Engineered for continuous industrial operation.

• Seamless Integration: Works with Series 90-70 PLC CPUs, input modules, and communication modules.

• Certified Compliance: CE, UL, and CSA approvals ensure global safety standards.

---

FAQ

1. How many relay outputs are available on the IC697MDL710?
   The module provides 16 individually isolated relay outputs capable of controlling AC or DC loads.

2. What types of loads can the module switch?
   It can switch both AC loads up to 240V and DC loads up to 30V, including motors, solenoids, and pilot lights.

3. What is the maximum current per output?
   Each relay output can handle up to 2 A resistive load, with high inrush capacity for startup currents.

4. Are the relay outputs isolated?
   Yes, each of the 16 relay outputs is electrically isolated to prevent interference between channels.

5. Does the module provide visual status indicators?
   Yes, each output channel has a dedicated LED showing ON/OFF status.

6. Is the module compatible with Series 90-70 CPUs?
   Yes, it integrates seamlessly with all Series 90-70 PLC CPUs and other compatible I/O modules.

7. Can it handle high inrush loads?
   Yes, each relay can handle inrush currents up to 10 times its rated capacity without damage.

8. What is the operating temperature range for this module?
   It operates reliably between 0°C and 60°C (32°F to 140°F).

9. Can multiple IC697MDL710 modules be installed in the same rack?
   Yes, multiple modules can be installed depending on rack space and backplane power capacity.

10. What types of devices are best suited for this relay output module?
    It is ideal for switching mechanical actuators, pilot lights, solenoids, alarm devices, and any industrial load that requires mechanical contact.

---
