GE IC697MDL940 Relay Output Module

Company Information
E-mail		[email protected]
Mobile		+8613666033393
Whatsapp		+8613666033393
WeChat		13666033393
Add		Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Introduction

The GE IC697MDL940 Relay Output Module is a high-performance, 16-point relay output module designed for the GE Fanuc Series 90-70 PLC system. This module is engineered to deliver reliable switching and control of both AC and DC loads, making it a versatile solution for industrial automation and process control systems.

The IC697MDL940 is capable of switching loads up to 16 amps per point and supports voltage ranges of 120/240 VAC or 5/24/125 VDC, making it suitable for a wide range of control tasks such as solenoid valves, contactors, and motor starters. Each output point is individually isolated to ensure robust operation and to prevent electrical interference between circuits.

The relay outputs are configured to handle 480 VA for AC loads and 60 watts for DC loads, providing high power-handling capability while maintaining stable performance. This design allows it to control inductive or resistive loads effectively in harsh industrial environments.

---

Technical Specifications

---

Product Applications

The IC697MDL940 Relay Output Module is widely used in industrial automation systems where reliable and high-current switching is required. Its versatility makes it suitable for controlling both AC and DC loads across multiple sectors.

Key applications include:

• Manufacturing automation systems controlling conveyors, actuators, and process equipment.

• Power generation systems for controlling auxiliary equipment and protection devices.

• Oil and gas control systems, managing solenoids, relays, and pumps.

• Water treatment and distribution, operating valves and pumps.

• Material handling systems, managing motors, drives, and contactors.

• Building automation, controlling lighting and HVAC systems.

---

Product Advantages

The GE IC697MDL940 stands out for its durability, flexibility, and high electrical capacity. Designed for industrial-grade environments, it provides dependable operation even under continuous duty.

Key advantages include:

• High Current Capacity – Each point can switch up to 16 amps, ideal for heavy-duty applications.

• Wide Voltage Compatibility – Handles both AC (120/240 VAC) and DC (5/24/125 VDC) loads.

• Independent Isolation – Each group is isolated, preventing noise coupling and improving system safety.

• Long Relay Life – Industrial-grade relays provide excellent endurance under high load switching.

• Status LEDs for Each Output – Easy visual troubleshooting and system monitoring.

• Flexible Configuration – Supports a wide range of devices such as solenoids, contactors, and indicators.

• Rugged Design – Withstands mechanical vibration and electrical noise typically found in industrial environments.

• Backplane Integration – Seamlessly integrates into the GE Series 90-70 PLC platform.

---

FAQ

1. What types of loads can the IC697MDL940 control?
   The IC697MDL940 is capable of controlling both AC and DC loads, such as solenoids, lamps, contactors, and small motors. It efficiently manages inductive and resistive loads within industrial automation systems.

2. Can the module handle high inrush currents during startup?
   Yes, the relay contacts are designed to withstand high inrush currents, allowing it to control inductive devices like motors and solenoids without contact damage.

3. Does the module provide isolation between output groups?
   The IC697MDL940 features four isolated groups of four points each. This design prevents electrical interference and ensures that each group operates independently.

4. How are output statuses visually indicated on the module?
   Each output point has an individual LED indicator that clearly shows the ON or OFF status, simplifying system diagnostics and field maintenance.

5. What is the typical operating delay for the relay outputs?
   The relays have an average operate or release time of around 10 milliseconds, ensuring fast and dependable response in industrial control operations.

6. Can AC and DC loads be used on the same module simultaneously?
   Yes, AC and DC loads can be used on the same module, provided they are assigned to separate isolated groups to prevent cross-interference or grounding issues.

7. What protection is recommended for inductive load switching?
   For inductive loads such as coils and motors, external suppression components like diodes or RC snubbers should be installed to minimize contact arcing and extend relay life.

8. How is field wiring performed on the IC697MDL940 module?
   The module includes removable terminal blocks for easy field wiring. Proper wire gauge and torque specifications should be followed to ensure secure and reliable electrical connections.

9. What is the power consumption from the PLC backplane?
   The module draws approximately 0.7 A from the 5 VDC backplane supply, which must be considered during system power budgeting.

10. Is the IC697MDL940 compatible with redundant PLC configurations?
    Yes, it can be deployed in redundant or fail-safe GE Fanuc Series 90-70 PLC systems to enhance reliability and ensure continuous control in mission-critical applications.

---
