Product Introduction
The GE IC697VDQ120 is a highly reliable digital output module designed for use with the GE Series 90-30 PLC. This module enables precise control of digital output signals in various industrial automation systems, making it ideal for applications that require switching high-current loads like motors, solenoids, or relays. With 16 output channels, it offers excellent flexibility for managing output signals in automation and control systems. The module supports a wide range of industrial applications, including process control, machinery automation, and factory monitoring systems.
Specifications
The following table outlines the key specifications of the GE IC697VDQ120 Digital Output Module:
| Specification | Details |
|---|---|
| Model Number | IC697VDQ120 |
| Dimensions (L × W × H) | 200 × 40 × 150 mm |
| Weight | 1.36 kg |
| Output Channels | 16 Channels |
| Output Type | DC Voltage Outputs |
| Output Voltage Range | 24 V DC |
| Output Current | 0.5 A per channel |
| Isolation | 1500 V RMS |
| Power Consumption | 5 W |
| Operating Temperature | 0 to 60°C |
| Compatibility | Compatible with Series 90-30 PLCs |
Applications
The GE IC697VDQ120 Digital Output Module is designed for applications requiring precise control over digital outputs in industrial settings. Some key applications include:
-
Process Control Systems: Used to control industrial equipment, such as actuators, relays, and valves, in automated production lines or processing plants.
-
Machine Automation: Ideal for controlling machines, conveyors, robotics, and other equipment in manufacturing processes.
-
Factory Monitoring: Enables switching of external devices like alarms, lights, or motors based on input signals from sensors or PLC controllers.
-
Control of High-Current Loads: The module is capable of managing high-power devices and circuits, such as motors, pumps, and industrial machinery.
-
Safety Systems: Suitable for use in safety-critical applications, where controlling outputs to external systems ensures the proper operation and safety of machinery.
Advantages
-
High Output Flexibility: The IC697VDQ120 supports 16 individual output channels, allowing for control of multiple devices simultaneously.
-
Robust Protection: With 1500 V RMS isolation, the module ensures that sensitive control systems are protected from voltage spikes and electrical interference.
-
High Current Capacity: Each output channel can handle up to 0.5 A of current, making it capable of driving high-power industrial devices.
-
Fast Response Time: Provides quick response times, ensuring real-time control in applications where rapid switching of outputs is necessary.
-
Compact and Space-Efficient: The module’s compact size (200 × 40 × 150 mm) allows for easy installation in spaces with limited room for equipment.
-
Energy-Efficient: With a low power consumption of only 5 W, the module ensures minimal energy usage while maintaining excellent performance.
FAQ
1. How many output channels does the IC697VDQ120 support?
The IC697VDQ120 provides 16 output channels, allowing control of multiple external devices simultaneously.
2. What is the maximum output current per channel for the module?
Each output channel can handle a maximum current of 0.5 A, which is suitable for driving medium-power industrial devices.
3. What is the isolation voltage of the IC697VDQ120?
The module has an isolation rating of 1500 V RMS, providing protection against electrical interference and power surges.
4. What type of output signals does the module provide?
The IC697VDQ120 generates DC voltage output signals, ideal for controlling external devices like relays, solenoids, and actuators.
5. What is the power consumption of the module?
The module consumes 5 W of power during operation, making it energy-efficient while maintaining high performance.
6. Is the IC697VDQ120 compatible with other GE PLC models?
Yes, the module is fully compatible with GE Series 90-30 PLCs, and it integrates seamlessly into GE’s automation systems.
7. What is the operating temperature range of the module?
The IC697VDQ120 operates within a temperature range of 0°C to 60°C, ensuring reliable performance in various industrial environments.
8. What is the voltage range supported by the IC697VDQ120?
The module supports 24 V DC output signals, which is the standard for many industrial control systems.
9. Can the IC697VDQ120 drive high-power devices?
Yes, the module is capable of driving medium-power devices, with each output channel supporting up to 0.5 A of current.
10. How does the IC697VDQ120 module help in industrial automation?
By providing 16 digital output channels, the IC697VDQ120 enables precise control of various devices like motors, sensors, and other equipment, facilitating automation in manufacturing and industrial processes.
Related Models
The following table lists other related models and their descriptions:
| Model Number | Description |
|---|---|
| IC697VDQ120 | 16-channel digital output module for Series 90-30 PLCs |
| IC697VDQ110 | 8-channel digital output module for smaller applications |
| IC697VDQ130 | 32-channel high-density digital output module |
| IC697VDQ140 | High-current digital output module for industrial use |
| IC697VDQ150 | 16-channel digital output module with enhanced isolation |
| IC697VDQ160 | Digital output module with diagnostics and status LEDs |
Popular Models from GE
The following table highlights other popular products from GE’s industrial automation range:
| Model Number | Description |
|---|---|
| IC200ALG260 | VersaMax analog input module |
| IC200MDL640 | VersaMax digital output module |
| IC200CHS022 | VersaMax communication module |
| IC200UDR001 | VersaMax universal digital input module |
| IC200PWR001 | VersaMax power supply module |
| IC200ACC406 | VersaMax accumulator module |
