Product Introduction
The GE IS220PDIAH1BC Discrete Contact Input Terminal Board is a robust module designed for use in GE’s IS200 I/O system. It provides reliable discrete input capabilities, converting field device signals into digital signals for the control system. Engineered for high reliability and industrial-grade performance, this terminal board ensures accurate signal transmission and seamless integration with GE automation controllers. It is widely used in power plants, process control systems, and other industrial automation environments.
Product Advantages
-
High signal integrity with minimal electrical noise interference
-
Supports a wide range of discrete input devices
-
Easy integration with GE IS200 series controllers
-
Compact design facilitating efficient cabinet layout
-
Robust industrial-grade construction for high reliability in harsh environments
-
Simplified wiring and maintenance with clearly labeled terminals
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | IS220PDIAH1BC |
| Type | Discrete Contact Input Terminal Board |
| Input Type | Dry Contact / Discrete Input |
| Number of Channels | 16 Channels per module |
| Input Voltage Range | 24–125 VDC |
| Response Time | ≤10 ms |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 5% to 95%, non-condensing |
| Isolation | Channel-to-channel and channel-to-system |
| Dimensions | 159 x 178 mm |
| Weight | 0.8 kg |
| Mounting | DIN Rail / Panel Mounting |
Product Applications
-
Industrial automation systems
-
Power generation and distribution monitoring
-
Process control systems in oil & gas, chemical, and petrochemical plants
-
Remote monitoring of field devices and sensors
-
Signal acquisition for SCADA systems
-
Integration with programmable logic controllers (PLCs)
FAQ
Q1: What types of input signals does the IS220PDIAH1BC support?
A1: It supports dry contacts and discrete voltage inputs ranging from 24 to 125 VDC.
Q2: Can this module handle high-speed signal changes?
A2: Yes, the response time is ≤10 ms, making it suitable for fast discrete signal acquisition.
Q3: Is the module compatible with other GE I/O systems outside IS200?
A3: It is designed primarily for the IS200 series; compatibility with other systems may require adapter modules.
Q4: What isolation features are included?
A4: The module provides channel-to-channel and channel-to-system electrical isolation to reduce noise and prevent signal interference.
Q5: How does it indicate input status?
A5: The module provides LED indicators for each channel, showing the real-time input status.
Q6: Can multiple modules be stacked or connected together?
A6: Yes, multiple modules can be installed in the same I/O rack with proper wiring and configuration.
Q7: What kind of maintenance does the module require?
A7: Periodic visual inspection and cleaning of terminals are recommended. Electrical maintenance is minimal due to robust design.
Q8: Is it compatible with SCADA systems?
A8: Yes, when connected through GE IS200 controllers, it can provide discrete input data to SCADA systems.
Q9: Can the module operate in high-humidity environments?
A9: Yes, it operates safely within 5% to 95% relative humidity, non-condensing.
Q10: Does the module support redundancy for critical applications?
A10: While the module itself does not provide redundancy, it can be integrated into redundant I/O architectures with GE controllers.
