Product Introduction
The GE IS220PTCCH2B Thermocouple Input Module is a high-performance, reliable component used to measure temperature from thermocouple sensors. As part of GE’s Mark VIe control system, this module provides precise and accurate temperature readings for various industrial applications, ensuring efficient and safe operation of critical machinery.
This module is designed for industrial systems that require temperature monitoring of equipment such as turbines, generators, and other machinery operating at extreme temperatures. The IS220PTCCH2B module supports various thermocouple types (such as Type K, J, T, and more), making it versatile for use in a wide range of temperature-sensing applications. It ensures seamless integration with GE’s Mark VIe system, allowing real-time monitoring, data collection, and communication with other system components.
The IS220PTCCH2B module is essential for industrial processes where precise temperature control is crucial, ensuring safety, performance, and operational efficiency. Its compact size, 82.6 x 41.9 mm, and low weight (0.8 kg) make it an ideal solution for systems with space constraints, while still providing reliable temperature measurement capabilities.
Product Specifications
| Feature | Specification |
|---|---|
| Total Dimensions | 82.6 x 41.9 mm |
| Weight | 0.8 kg |
| Module Type | Thermocouple Input Module |
| Supported Thermocouple Types | Type K, J, T, E, R, S, B, N |
| Number of Channels | 8 Analog Inputs |
| Input Range | -200°C to 1800°C |
| Power Supply | 24V DC |
| Communication Interface | Serial (RS-485), Ethernet |
| Mounting Type | DIN Rail Mounting |
| Protection Class | IP20 |
| Status Indicators | LED Status Indicators |
Applications
The GE IS220PTCCH2B Thermocouple Input Module is suitable for a wide range of applications, particularly in industries that require accurate and reliable temperature monitoring. Some common applications include:
-
Power Generation: The module is essential in turbine and generator control systems, where temperature measurements are critical for ensuring the safe operation of power plants.
-
Industrial Process Control: Used in chemical, petrochemical, and refining industries, the module helps monitor temperature during various processes such as distillation, heating, and chemical reactions.
-
Energy Production: In energy production facilities, it ensures efficient monitoring of heat exchangers, boilers, and other temperature-sensitive equipment.
-
Manufacturing and Fabrication: The module is used for temperature monitoring in manufacturing systems, where maintaining specific temperatures is crucial for product quality.
-
HVAC Systems: The IS220PTCCH2B module integrates with HVAC systems, helping to ensure the temperature remains within the desired operating range.
-
Research and Testing: In research labs and testing environments, precise temperature measurement is crucial for experimental accuracy, making this module an ideal choice for research institutions.
Product Advantages
-
Wide Thermocouple Support: The IS220PTCCH2B module supports a wide variety of thermocouple types (including Types K, J, T, E, R, S, B, and N), providing flexibility in temperature sensing across various industrial applications.
-
High Temperature Range: With a measurement range of -200°C to 1800°C, the module can be used in both low and high-temperature environments, making it versatile for different industries.
-
Compact and Space-Efficient: At 82.6 x 41.9 mm and weighing only 0.8 kg, the module is small enough to fit into compact control systems, ensuring easy integration even in space-constrained environments.
-
Reliable Communication: The module supports RS-485 serial and Ethernet communication interfaces, ensuring reliable and fast data transfer between the input module and control systems.
-
Easy Integration: The module integrates seamlessly with GE’s Mark VIe and other control systems, allowing for easy configuration and data synchronization across all system components.
-
Real-Time Monitoring: Continuous temperature monitoring allows for early detection of potential problems, preventing overheating or damage to critical components.
-
DIN Rail Mounting: The module is designed for DIN rail mounting, making it easy to install, secure, and maintain within control panels or electrical cabinets.
-
IP20 Protection Class: The IP20 protection rating ensures that the module is safe from solid objects larger than 12mm, making it suitable for industrial environments where dust or moisture are not major concerns.
FAQ
1. What types of thermocouples are supported by the GE IS220PTCCH2B module?
The IS220PTCCH2B module supports various thermocouple types, including Type K, Type J, Type T, Type E, Type R, Type S, Type B, and Type N.
2. What is the temperature range of the IS220PTCCH2B module?
The module supports a temperature measurement range from -200°C to 1800°C, making it suitable for a wide range of industrial temperature monitoring applications.
3. What communication interfaces does the IS220PTCCH2B module support?
The module supports RS-485 serial and Ethernet communication interfaces, allowing seamless integration with control systems.
4. How many input channels does the IS220PTCCH2B module support?
The IS220PTCCH2B module supports 8 analog input channels, providing enough capacity for multiple temperature measurements simultaneously.
5. What is the power supply requirement for the IS220PTCCH2B module?
The IS220PTCCH2B module requires a 24V DC power supply to operate.
6. How is the IS220PTCCH2B module mounted?
The module is designed for DIN rail mounting, making it easy to integrate into control panels or industrial enclosures.
7. What protection class does the IS220PTCCH2B module have?
The module has an IP20 protection class, meaning it is protected against solid objects larger than 12mm but is not resistant to water or dust.
8. What are the main advantages of using the IS220PTCCH2B module in industrial systems?
The IS220PTCCH2B module offers wide thermocouple support, high temperature range, compact design, and reliable communication, making it a versatile and reliable choice for industrial temperature monitoring.
9. Can the IS220PTCCH2B module be used in high-temperature applications?
Yes, the IS220PTCCH2B module can measure temperatures up to 1800°C, making it suitable for high-temperature environments like furnaces, boilers, and heat exchangers.
10. How does the IS220PTCCH2B module enhance system performance?
By providing accurate and real-time temperature data, the IS220PTCCH2B module helps operators detect temperature anomalies early, ensuring that the system operates within safe limits and preventing potential damage to equipment.
