Product Introduction
The HIMA F60 AI 8 01 (Part No. 982200214) is an 8-channel analog input module specifically designed for use within HIMA’s safety-related automation systems. It belongs to the HIMax and HIQuad X series architecture, offering high-integrity data acquisition for critical process variables such as temperature, pressure, level, and flow.
Engineered to meet the rigorous demands of functional safety, this module ensures SIL 3 compliance in accordance with IEC 61508. The F60 AI 8 01 supports a variety of analog signal types, including current and voltage, and is designed for hot swapping and redundancy, making it suitable for high-availability environments such as oil & gas, chemical, power generation, and transportation.
Its robust construction and intelligent diagnostics capabilities ensure safe operation, reduce downtime, and contribute to maintaining system reliability over long lifecycles.
Product Specifications
| Parameter | Details |
|---|---|
| Model Number | F60 AI 8 01 |
| Part Number | 982200214 |
| Manufacturer | HIMA Paul Hildebrandt GmbH |
| Input Channels | 8 analog input channels |
| Input Type | Voltage (0–10 V), Current (0/4–20 mA), Thermocouple, RTD (PT100) |
| Input Signal Range | ±10 V / 0–10 V / 0–20 mA / 4–20 mA |
| Resolution | 16-bit resolution |
| Isolation | Galvanically isolated per channel |
| Redundancy Support | Yes (in HIMax systems) |
| Diagnostic Functions | Channel diagnostics, wire-break detection, signal monitoring |
| Safety Integrity Level | SIL 3 (IEC 61508) |
| Hot Swappable | Yes |
| Operating Voltage | 24 V DC (nominal) |
| Power Consumption | Approx. 4.5 W |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Protection Class | IP20 (with enclosure) |
| Mounting Type | DIN rail, compatible with HIMA racks |
| Compliance | IEC 61508, CE, RoHS, ATEX |
| Dimensions (W x H x D) | 150 x 140 x 80 mm |
| Weight | 0.24 kg |
Applications
The HIMA F60 AI 8 01 analog input module is trusted in safety-critical applications where reliable analog signal acquisition is crucial. Its typical applications include:
-
Oil & Gas Industry: Monitoring wellhead pressures, pipeline flow rates, and tank levels in offshore and onshore platforms.
-
Chemical Processing Plants: Acquiring temperature and pH levels in reactor systems and distillation columns.
-
Power Generation: Monitoring turbine speed, temperature, boiler pressure, and fuel levels.
-
Railway Signaling Systems: Gathering environmental data for safety logic systems.
-
Pharmaceutical Manufacturing: Monitoring pressure and temperature in batch processing under GMP compliance.
-
Water & Wastewater Plants: Acquiring sensor data for flow and turbidity in treatment systems.
Advantages
-
High Safety Compliance: SIL 3 certified module that supports safety-critical automation systems.
-
Multi-Signal Input: Accepts a variety of signal types (current, voltage, thermocouples), eliminating the need for multiple module types.
-
Channel Diagnostics: Each channel is equipped with diagnostics for broken wires, short circuits, and signal failure.
-
Hot Swap Capability: Allows module replacement without shutting down the system, reducing downtime.
-
Galvanic Isolation: High-level channel-to-channel isolation protects control systems from electrical noise and surges.
-
Compact Size: Slim profile allows high-density I/O installations in limited cabinet space.
-
Designed for Redundancy: Fully supports redundant configurations for mission-critical operations.
-
Long-Term Reliability: Engineered for 24/7 use in extreme industrial environments.
-
Ease of Integration: Seamlessly connects with HIMA’s HIMax and HIQuad X platforms.
-
Regulatory Approved: Certified to global standards including CE, RoHS, and ATEX for hazardous locations.
Frequently Asked Questions (FAQ)
-
What type of signals can the F60 AI 8 01 module receive?
It supports analog voltage, current, RTDs, and thermocouple inputs. -
Is the module SIL-certified?
Yes, it is SIL 3 certified per IEC 61508, ideal for safety-critical systems. -
Can I install this module in hazardous locations?
Yes, it complies with ATEX and other certifications allowing use in hazardous environments. -
Does it support redundancy?
Absolutely. The module is designed to operate in redundant HIMA systems. -
Is hot swapping supported?
Yes, modules can be replaced during operation without system shutdown. -
What diagnostic features are included?
Channel diagnostics include wire-break detection, signal loss, and short circuit alerts. -
How is the module mounted?
It is DIN rail-mountable and designed for use with HIMA HIMax and HIQuad X racks. -
What is the resolution of the analog inputs?
The inputs are 16-bit resolution for precise analog signal capture. -
How many input channels does this module have?
It has 8 analog input channels. -
What’s the difference between this and digital input modules from HIMA?
This module handles continuous analog signals, whereas digital modules handle discrete on/off signals.
Related or Same Series Models (F60 or Analog Input)
| Model | Description | Channels | Signal Type | Dimensions (mm) | Weight |
|---|---|---|---|---|---|
| F60 AI 4 01 | 4-channel analog input module | 4 | Analog (V/mA) | 30 × 130 × 120 | 270 g |
| F60 AI 8 02 | 8-channel AI module with extended diagnostics | 8 | Analog (V/mA) | 30 × 130 × 120 | 285 g |
| F60 AI 16 01 | 16-channel analog input module | 16 | Analog (V/mA) | 50 × 130 × 120 | 360 g |
| F60 AI 8 TC | 8-channel thermocouple input module | 8 | Thermocouple | 30 × 130 × 120 | 280 g |
| F60 AI 4 RTD | 4-channel RTD input module | 4 | PT100/PT1000 | 30 × 130 × 120 | 275 g |
| F60 AI 8 HART | 8-channel analog input with HART communication | 8 | Analog + HART | 30 × 130 × 120 | 290 g |
Popular Models from HIMA (Other Categories)
| Model | Description | Type | Key Feature | Dimensions (mm) | Weight |
|---|---|---|---|---|---|
| F60 DI 16 01 | 16-channel digital input module | Digital Input | High-density DI | 30 × 130 × 120 | 260 g |
| F60 DO 8 01 | 8-channel digital output module | Digital Output | SIL 3-rated, relay output | 30 × 130 × 120 | 270 g |
| F35 CPU 01 | Main processor module for HIMax systems | CPU/Controller | Central processing for safety logic | 130 × 130 × 120 | 520 g |
| F8650X | HIMax Safety Controller | Safety System | SIL 3 logic solver | 270 × 200 × 180 | 3.2 kg |
| F60 PS 01 | Power supply module for HIMax platform | Power Supply | 24 V DC input, monitored output | 60 × 130 × 120 | 450 g |
| F6705 | Communication module (Profibus DP/Redundant) | Communication Interface | Dual bus capability | 60 × 130 × 120 | 500 g |
