Product Introduction
The HIMA F6214 Analog Input Module is a highly reliable and precise input module designed for safety-critical applications in industrial automation. As part of HIMA’s advanced safety systems, the F6214 plays a crucial role in monitoring analog signals from field instruments, such as temperature sensors, pressure transmitters, and flow meters.
This module is widely used in process industries like oil & gas, chemical plants, and power generation. It ensures high availability and safety compliance, making it an essential component in functional safety and emergency shutdown (ESD) systems.
The HIMA F6214 is built to withstand harsh industrial environments, offering high accuracy, fast response times, and robust signal processing capabilities.
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | HIMA F6214 |
| Product Type | Analog Input Module |
| Number of Channels | 8 Analog Input Channels |
| Input Signal Types | 0-10V, 4-20mA, RTD, Thermocouple |
| Resolution | 16-bit |
| Sampling Rate | High-Speed Sampling (configurable) |
| Accuracy | ±0.1% Full Scale |
| Isolation | Galvanic Isolation between Channels and System |
| Power Supply | 24V DC |
| Operating Temperature | -20°C to +70°C |
| Humidity Range | 5% to 95% (non-condensing) |
| Communication Interface | HIMA Safety Bus |
| Redundancy Support | Yes (for high-availability applications) |
| Environmental Protection | Conformal Coating for Harsh Environments |
| Mounting Type | DIN Rail Mount |
| Dimensions | 120 × 80 × 30 mm |
| Weight |
0.35 kg |
Applications
The HIMA F6214 Analog Input Module is designed for industrial safety and automation applications where high-precision analog data acquisition is required. Some key applications include:
-
Emergency Shutdown Systems (ESD) – Used to monitor critical parameters in oil & gas refineries, chemical plants, and power stations.
-
Process Control Systems – Ensuring accurate measurement of temperature, pressure, and flow for regulatory compliance.
-
Industrial Safety Systems – Integrated into fail-safe controllers to prevent hazardous conditions.
-
SCADA & DCS Integration – Enables real-time monitoring and remote control.
-
Power Generation & Distribution – Used in turbine control systems and switchgear monitoring.
-
Pharmaceutical Industry – Helps maintain precise environmental conditions in GMP-compliant manufacturing.
Product Advantages
-
High Accuracy & Resolution – 16-bit ADC ensures precise signal conversion for safety-critical applications.
-
Wide Signal Compatibility – Supports 0-10V, 4-20mA, RTD, and thermocouple inputs.
-
Industrial-Grade Reliability – Designed for continuous operation in harsh environments.
-
Fail-Safe & Redundant Design – Ensures uninterrupted system operation in mission-critical applications.
-
Galvanic Isolation – Provides electrical isolation between field devices and the control system.
-
Fast Response Time – Supports real-time data acquisition for high-speed control loops.
-
Robust EMI/EMC Protection – Minimizes interference in electrically noisy environments.
-
Scalability & Flexibility – Easily integrates with HIMA safety controllers and distributed control systems (DCS).
-
Extended Temperature Range – Operates reliably in extreme conditions (-20°C to +70°C).
-
Compliance with Safety Standards – Meets IEC 61508 (SIL 3), ATEX, and other industrial safety standards.
