Product Introduction
The HIMA Z7127 Cable Plug is a precision-engineered connector designed specifically for high-reliability industrial and safety-critical applications. Known for its robust design and secure connection capability, this cable plug is a key component in HIMA’s safety instrumented systems (SIS), providing dependable signal transmission in harsh environments.
Built to withstand extreme mechanical and environmental stresses, the Z7127 cable plug offers easy installation and ensures optimal performance for control and automation systems. Its construction emphasizes durability, electrical integrity, and ease of maintenance, making it an essential accessory for wiring safety-critical communication and power lines.
Product Specifications
| Parameter | Details |
|---|---|
| Model Number | Z7127 |
| Product Type | Cable Plug |
| Compatible Systems | HIMA Safety Instrumented Systems |
| Connector Type | Circular, multi-pin connector |
| Number of Contacts | 12 pins |
| Contact Material | Gold-plated copper alloy |
| Cable Diameter Range | 7 mm to 12 mm |
| Operating Voltage | Up to 250 V AC/DC |
| Current Rating | 5 A per contact |
| Ingress Protection | IP67 (when mated) |
| Operating Temperature | -40°C to +85°C |
| Material (Housing) | High-grade aluminum alloy with corrosion resistance |
| Weight | 0.15 kg |
| Space Requirements | 4 TE |
| Mounting Type | Panel mount or cable end |
| Certifications | CE, UL, IECEx, SIL 3 certified for safety use |
Product Applications
The HIMA Z7127 Cable Plug is utilized extensively in sectors demanding high safety and reliability standards:
-
Safety Instrumented Systems: Integral to the wiring of SIS used in process industries such as oil & gas, chemical, and petrochemical.
-
Power Plants: Facilitates secure connections for control and monitoring systems in nuclear, thermal, and hydro power plants.
-
Railway Signaling: Ensures reliable data and power transmission in signaling and control equipment.
-
Aerospace and Defense: Supports ruggedized connections in ground and airborne safety systems.
-
Manufacturing Automation: Used in robotic assembly lines and critical automation machinery requiring high integrity connections.
-
Marine and Offshore Installations: Withstands harsh environmental conditions for control systems on ships and offshore platforms.
Product Advantages
-
High Durability: Built with corrosion-resistant aluminum housing and gold-plated contacts to ensure longevity and stable electrical performance.
-
Environmental Protection: IP67 rating guarantees protection against dust ingress and water immersion, suitable for harsh industrial environments.
-
Safety Certified: Meets stringent SIL 3 standards, confirming its reliability in safety-critical applications.
-
Robust Contact System: Gold-plated contacts provide low-resistance, stable connections reducing signal loss and interference.
-
Ease of Installation: Designed for straightforward panel mounting and cable termination, minimizing installation time.
-
Wide Operating Range: Functions reliably across a broad temperature range, from -40°C to +85°C.
-
Mechanical Stability: Secure locking mechanism prevents accidental disconnection even under vibration or mechanical shock.
-
Compatibility: Seamlessly integrates with HIMA’s extensive product range for simplified system design.
-
Maintenance Friendly: Simple disconnection and reconnection capabilities allow easy servicing without compromising system integrity.
Frequently Asked Questions (FAQ)
-
What type of connector is the HIMA Z7127?
It is a circular multi-pin cable plug designed for industrial use. -
How many pins does this cable plug have?
The Z7127 features 12 pins. -
What protection rating does the cable plug offer?
It provides IP67 protection when mated, making it dust-tight and water-resistant. -
Is this cable plug suitable for safety instrumented systems?
Yes, it is certified to SIL 3 standards, making it ideal for SIS. -
What is the maximum operating temperature for this plug?
It operates reliably between -40°C and +85°C. -
What materials are used for the plug housing and contacts?
The housing is aluminum alloy with corrosion resistance; contacts are gold-plated copper alloy. -
Can it be used in explosive environments?
Yes, it holds IECEx certification suitable for hazardous locations. -
What is the typical current rating per contact?
Each contact is rated for up to 5 A. -
How is the plug installed?
It can be panel-mounted or terminated directly at the cable end with a secure locking mechanism. -
Is the plug compatible with other manufacturers’ systems?
It is primarily designed for HIMA systems; compatibility with other brands may vary.
Related or Similar Models from HIMA
| Model | Description | Pin Count | Connector Type | Typical Use |
|---|---|---|---|---|
| Z7128 | Cable Plug, 16-pin circular | 16 | Circular multi-pin | Safety instrumented wiring |
| Z7129 | Cable Socket, 12-pin | 12 | Circular multi-pin | Panel connection |
| Z7130 | Cable Plug, 24-pin | 24 | Circular multi-pin | Complex signal wiring |
| Z7140 | Cable Plug, 8-pin | 8 | Circular multi-pin | Smaller control applications |
| Z7150 | Cable Connector, 20-pin | 20 | Circular multi-pin | Industrial automation |
| Z7160 | Heavy-duty Cable Plug, 12-pin | 12 | Circular multi-pin | Harsh environment use |
Popular HIMA Models
| Model | Description | Category | Certification | Primary Use |
|---|---|---|---|---|
| HIMA HIMax | Safety PLC, high availability | Programmable Logic Controller | SIL 3 | Safety-critical automation |
| HIMA HIMatrix | Modular safety system | Safety Instrumented System | SIL 3 | Process control |
| HIMA Pilz PNOZ | Safety relay module | Safety Relay | SIL 3 | Emergency stop and safety loops |
| HIMA Z7010 | Safety I/O Module | Input/Output Module | SIL 3 | Signal conditioning and wiring |
| HIMA Z7100 | Cable Socket, 16-pin | Connector | IECEx | Wiring in hazardous areas |
| HIMA Z7200 | Safety Controller | Safety Controller | SIL 3 | Critical infrastructure |
