Product Introduction:
The HIMA Z7138/3330/C15/S2088 Cable Plug is a high-reliability industrial connector developed by HIMA, a globally renowned manufacturer specializing in safety-related automation solutions. This cable plug is engineered to interface securely with HIMA’s programmable safety systems and field devices, ensuring uninterrupted communication and power transmission even in critical environments.
Constructed with rugged materials and precision contacts, the Z7138/3330/C15/S2088 is built for demanding industrial sectors such as petrochemical plants, power generation facilities, and safety-instrumented systems (SIS). It provides secure electrical connectivity, electromagnetic compatibility (EMC), and excellent mechanical durability. Its modular design allows for flexibility in wiring and easy field termination, making it a preferred choice for OEMs and maintenance engineers alike.
Product Specifications:
| Parameter | Details |
|---|---|
| Product Name | Z7138/3330/C15/S2088 |
| Manufacturer | HIMA |
| Product Type | Industrial Cable Plug |
| Connector Type | Multipole Plug |
| Number of Poles | 15-pole |
| Contact Type | Crimp Contacts / Screw Terminals |
| Rated Voltage | 250 V AC/DC |
| Rated Current | Up to 10 A (per contact) |
| Insulation Resistance | > 10⁹ Ohms |
| Dielectric Strength | 2.5 kV AC (1 min) |
| Mechanical Durability | > 500 mating cycles |
| EMC Shielding | Yes (360° shielding) |
| Material (Housing) | Zinc Alloy, nickel-plated |
| Material (Insulation) | Thermoplastic (UL94-V0) |
| Cable Entry | PG11 / PG13.5 |
| Operating Temperature Range | -40°C to +85°C |
| Storage Temperature Range | -55°C to +90°C |
| Degree of Protection | IP65 (mated condition) |
| Cable Length | 15 meters |
| Weight | 0.25 kg |
| Certifications | CE, RoHS, IEC 61984, UL-compliant |
Product Applications:
-
Process Automation: Used to connect field devices to safety controllers in chemical and oil refining plants.
-
Power Generation: Facilitates communication between turbines, monitoring devices, and relay protection systems.
-
Factory Safety Systems: Integrated into emergency shutdown systems and fire/gas detection interfaces.
-
Railway and Transportation: Applied in onboard and station-level signal communication systems.
-
Marine and Offshore: Withstands vibration and corrosive environments for shipboard automation.
-
Pharmaceutical Manufacturing: Supports cleanroom-grade equipment interconnection with compliance-grade materials.
Product Advantages:
-
Secure Signal Transmission: Ensures high-integrity data and power transfer under harsh conditions.
-
Durable Construction: Withstands environmental stress, mechanical wear, and chemical exposure.
-
High Contact Reliability: Gold-plated contacts prevent signal loss and improve long-term performance.
-
Compact Form Factor: Fits into control cabinets and field junction boxes without spatial constraints.
-
Ease of Maintenance: Detachable and serviceable on-site with standard tools.
-
EMC Compliant: Prevents interference in sensitive environments with high electromagnetic fields.
-
Flexible Cable Entry: Supports multiple cable diameters and field termination methods.
-
Safety-Certified: Meets stringent industrial standards for reliability and fail-safe operation.
-
Modular Compatibility: Interconnects seamlessly with HIMA’s Z and HIMax series modules.
-
Cost-Efficient: Reduces downtime and replacement costs with long service life and minimal failure rate.
