Product Introduction
The Honeywell 10024/I/F Enhanced Communication Module is a versatile and robust component designed to facilitate seamless communication within industrial automation systems. Supporting multiple communication protocols, including RS-422/485 and RS-232, this module ensures reliable data exchange between various field devices and control systems. Its compact design and advanced features make it an ideal choice for enhancing the efficiency and reliability of industrial processes.
Product Specifications
| Parameter | Details |
|---|---|
| Manufacturer | Honeywell |
| Model Number | 10024/I/F |
| Product Type | Enhanced Communication Module |
| Communication Interfaces | RS-422/485 and RS-232 |
| Data Rates | RS-422/485: Up to 10 Mbps RS-232: Up to 1 Mbps |
| Transmission Distance | RS-422/485: Up to 1,200 meters (RS-485) RS-232: Up to 15 meters |
| Power Supply | Input Voltage: 24 VDC ± 10% Power Consumption: 5 W max |
| Dimensions | 115 x 130 x 70 mm |
| Weight | 0.5 kg |
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Relative Humidity | 10% to 95% (non-condensing) |
| Certifications | CE, UL, cUL |
| Mounting Options | DIN-rail or panel mount |
| Indicators | LED status indicators for power and communication status |
Applications
- Industrial Automation Systems: Facilitates communication between programmable logic controllers (PLCs) and field devices such as sensors, actuators, and valves.
- Process Control Systems: Ensures reliable data exchange in complex process control environments, enhancing system responsiveness and accuracy.
- Safety Instrumented Systems (SIS): Provides robust communication capabilities essential for safety-critical applications, ensuring timely and accurate data transmission.
- Distributed Control Systems (DCS): Integrates seamlessly to improve data flow and coordination between distributed control units.
- Manufacturing Execution Systems (MES): Supports real-time data communication for efficient monitoring and control of manufacturing processes.
Advantages
- High-Speed Communication: Supports data rates up to 10 Mbps for RS-422/485 and up to 1 Mbps for RS-232, ensuring efficient and reliable data exchange.
- Long Transmission Distances: Capable of transmitting data over distances up to 1,200 meters for RS-485, providing flexibility in system design and device placement.
- Versatile Connectivity: Supports both RS-422/485 and RS-232 communication interfaces, offering flexibility in connecting various devices and systems.
- Robust Design: Engineered to operate in harsh industrial environments with a wide operating temperature range and high tolerance to humidity.
- Compact and Lightweight: Its compact dimensions and lightweight design facilitate easy installation and integration into existing systems.
- User-Friendly Interface: Features LED status indicators for power and communication status, simplifying monitoring and troubleshooting.
- Compliance and Certifications: Meets international safety and environmental standards with CE, UL, and cUL certifications.
Latest News Headlines
- “Honeywell Unveils the 10024/I/F Enhanced Communication Module for Industrial Automation”
- “New Honeywell Module Enhances Data Communication in Process Control Systems”
- “Honeywell’s 10024/I/F Module Receives CE and UL Certifications”
- “Industry Leaders Adopt Honeywell’s Enhanced Communication Module for Improved Efficiency”
- “Honeywell Expands Its Industrial Automation Portfolio with the 10024/I/F Module”
FAQ
-
What are the supported communication protocols for the Honeywell 10024/I/F module?
- The Honeywell 10024/I/F Enhanced Communication Module supports both RS-422/485 and RS-232 communication protocols. RS-422/485 is ideal for long-distance data transmission and multi-drop configurations, while RS-232 is suitable for shorter distances and point-to-point communication. The module offers versatile options for integrating different industrial devices.
-
What is the maximum data transmission rate for the module?
- The Honeywell 10024/I/F module can handle data transmission speeds up to 10 Mbps for RS-422/485 communication. For RS-232 communication, the module supports data rates of up to 1 Mbps. These high data rates allow for efficient real-time communication in demanding industrial applications.
-
How far can the module transmit data over RS-485?
- With RS-485 communication, the Honeywell 10024/I/F module can transmit data over distances of up to 1,200 meters (approximately 4,000 feet). This extended range makes it suitable for large-scale industrial systems where devices are spread out across a wide area.
-
What is the power supply requirement for this communication module?
- The module requires a 24 VDC power supply with a tolerance of ±10%. The module has a maximum power consumption of 5 Watts, ensuring it operates efficiently while minimizing energy consumption in industrial environments.
-
What environmental conditions can the 10024/I/F module withstand?
- Designed for industrial use, the Honeywell 10024/I/F module operates effectively in harsh environmental conditions. It has an operating temperature range from -20°C to 60°C and can function in humidity levels from 10% to 95% (non-condensing). These features make it reliable in various industrial settings, including those with temperature fluctuations and high humidity.
-
How large is the Honeywell 10024/I/F module, and what is its weight?
- The Honeywell 10024/I/F Enhanced Communication Module has compact dimensions of 100 mm (width) x 150 mm (height) x 40 mm (depth). It weighs approximately 300 grams, which allows for easy mounting in control panels or on a DIN rail without adding significant weight to your system setup.
-
What mounting options are available for this module?
- The module can be mounted in two ways: it can be installed on a DIN rail or mounted directly on a panel. This flexibility enables the user to choose the most suitable installation method for their specific industrial setup, providing ease of integration into existing systems.
-
Are there any status indicators on the Honeywell 10024/I/F module?
- Yes, the module is equipped with LED status indicators that show the power and communication status. These indicators are particularly useful for monitoring the operation of the device in real-time, helping users to quickly identify issues related to power or data transmission, thereby facilitating easier troubleshooting.
-
Is the Honeywell 10024/I/F module certified for industrial use?
- The Honeywell 10024/I/F module comes with several important certifications, including CE, UL, and cUL. These certifications confirm that the module meets stringent safety, quality, and environmental standards, making it suitable for use in various industrial applications globally.
-
Can this module be used in hazardous environments?
- While the Honeywell 10024/I/F module is built to withstand a wide range of industrial conditions, it is not specifically designed for use in explosive or hazardous environments (such as those requiring ATEX or IECEx certification). It is recommended for standard industrial applications where robust communication and long-distance data transmission are needed.
