Product Introduction
The Honeywell 51202329-734 Violet Drop Cable is an industrial-grade signal transmission cable designed specifically for Honeywell TDC 3000 Distributed Control Systems (DCS) and other advanced process automation environments. This drop cable ensures reliable communication between control modules, I/O interfaces, and network nodes in complex and demanding applications.
Designed with tinned copper twisted pair conductors and dual-layer shielding (aluminum foil and copper braid), the cable offers excellent protection against electromagnetic interference (EMI). Its violet outer jacket follows Honeywell’s color-coding scheme, aiding in system segmentation and cable identification across large installations.
With flame-retardant, abrasion-resistant, and chemical-resistant PVC insulation, the 51202329-734 is optimized for long-term reliability in harsh environments, including oil refineries, chemical plants, and manufacturing automation lines.
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | 51202329-734 |
| Product Type | Violet Drop Cable |
| Manufacturer | Honeywell |
| Jacket Color | Violet (Purple) |
| Conductor Type | Twisted Pair |
| Conductor Material | Tinned Copper |
| Conductor Size | 22 AWG |
| Shielding | Foil + Braided Copper Shielding |
| Insulation Material | Flame-retardant PVC |
| Outer Jacket Material | Industrial PVC |
| Nominal Voltage | 300V |
| Characteristic Impedance | 150 Ohms ±10% |
| Operating Temperature | -40°C to +85°C |
| Flame Rating | UL Flame-Rated |
| Certifications | UL, CSA, CE |
| Outer Diameter | 7.5 mm |
| Package Weight | 3 kg |
| Cable Length | 48 inches |
| Application System | Honeywell TDC 3000, Experion PKS, and related control units |
Applications
The Honeywell 51202329-734 Violet Drop Cable is engineered for use in critical industrial control systems where communication reliability is essential. Common applications include:
-
Distributed Control Systems (DCS)
Used for connecting processors, interface modules, and remote I/O in Honeywell TDC 3000 platforms. -
Chemical and Petrochemical Plants
Supports signal transmission in areas with high chemical exposure and temperature fluctuations. -
Oil & Gas Refineries
Performs reliably in explosive and corrosive environments, ensuring safety and data accuracy. -
Power Generation Units
Ideal for turbine controls, control loop feedback, and networked monitoring systems. -
Factory Automation Panels
Allows easy routing in tight cabinet spaces due to its flexibility and moderate outer diameter. -
Process Control Networks
Enables clear network zoning using color-coded cabling, improving fault identification and system organization.
Product Advantages
-
Dual Shielding for Maximum EMI Protection
Combination of foil and braid shielding offers strong resistance to electrical noise and interference. -
Color-Coded Jacket for Easy Identification
Violet outer jacket helps maintenance teams trace signals quickly during installation or troubleshooting. -
Flexible and Durable Design
Easily routed through trays and conduits while maintaining high tensile and environmental resistance. -
Reliable Over Long Distances
Low capacitance and 150-ohm impedance allow for stable data transmission over extended cable runs. -
Resistant to Oil, Moisture, and Chemicals
Industrial-grade PVC jacket protects against environmental hazards in rugged plant environments. -
Safety Compliant and Flame-Retardant
Fully certified under UL, CSA, and CE, and designed to meet fire safety codes for enclosed spaces.
Frequently Asked Questions (FAQ)
1. What is the intended use of the Honeywell 51202329-734 cable?
It is designed to transmit data and control signals between DCS components, particularly in Honeywell TDC 3000 systems.
2. What does the violet jacket color signify?
Violet indicates control signal cabling in Honeywell’s color-coded schemes, helping with network organization and maintenance.
3. Does this cable support analog or digital signals?
It is suitable for both analog and digital communication, depending on the control system configuration.
4. What kind of shielding does it have?
It features foil and braided copper shielding to prevent EMI and ensure signal integrity.
5. Can it be used in outdoor or corrosive environments?
Yes, the cable’s PVC jacket is chemical- and moisture-resistant, making it reliable for harsh industrial applications.
6. Is the cable flame-retardant?
Yes, it meets UL flame-resistance standards, making it safe for use in enclosed areas.
7. What systems is this cable compatible with?
Primarily Honeywell TDC 3000, Experion PKS, and any other system requiring a 150-ohm, shielded, 22 AWG twisted pair cable.
8. Can it be installed in narrow conduits or tight panels?
Yes, the cable’s 7.5 mm diameter and flexibility allow easy installation in compact spaces.
9. How long is a standard roll of this cable?
Cable length is 48 inches.
10. What approvals does this cable carry?
The cable is UL listed, CSA approved, and CE marked for compliance with international safety standards.
Related or Compatible Models (Same Series or Function)
| Model Number | Description |
|---|---|
| 51202329-600 | Violet Drop Cable for TDC 3000 Standard Installations |
| 51202329-412 | Violet Drop Cable with Enhanced Flexibility |
| 51202329-614 | Violet Drop Cable for Process Control Applications |
| 51202329-615 | Violet Drop Cable for Compact Industrial Cabinets |
| 51202329-113 | High-Temperature Variant of Violet Drop Cable |
| 51400990-100 | Shielded ControlNet Cable for Data Transmission |
Popular Honeywell Models (Same Brand – High Demand)
| Model Number | Description |
|---|---|
| CC-TDIL01 | Digital Input Module for Experion PKS |
| FC-TSAI-1620 | Analog Input Module for Safety Manager Systems |
| MU-TD0D12 | Digital Output Module for TDC 3000 Series |
| CC-PDOB01 | Digital Output Module with High Output Capacity |
| TC-CCR013 | Control Processor Module for C300 Systems |
| 51401437-100 | Fiber Optic Ethernet Cable for Industrial Networks |
