Product Introduction
The Honeywell 8C-PAIHA1 Analog Input Module (P/N: 51454470-275) is a high-performance module designed to integrate seamlessly within the Honeywell Experion Process Knowledge System (PKS) and C300 Controllers. This analog input module is tailored for use in high-demand industrial environments where signal accuracy, reliability, and durability are crucial for ensuring smooth and consistent process control.
With 16 high-density channels, the 8C-PAIHA1 provides support for analog signals such as 4-20mA and 0-10V. It also features HART communication protocol, enabling remote configuration and diagnostics for connected devices. This module’s high-resolution capability ensures precision in reading and converting field signals, even in complex industrial systems.
Designed with built-in redundancy and electrical isolation, this module is perfect for industries such as chemical processing, oil and gas, power generation, and water treatment, where uninterrupted performance is paramount. Additionally, the module’s compact form factor and hot-swap capability make it a preferred choice for operations requiring minimal downtime during maintenance or replacement.
Technical Specifications
| Specification | Details |
|---|---|
| Model | 8C-PAIHA1 |
| Part Number | 51454470-275 |
| Manufacturer | Honeywell |
| Input Type | 4-20 mA, 0-10V, HART-enabled |
| Number of Channels | 16 channels (single-ended or differential) |
| Resolution | 16-bit |
| Input Accuracy | ±0.1% of full scale |
| HART Communication Support | Yes (for field device configuration and diagnostics) |
| Scan Rate | 100 ms (typical) |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5%–95% non-condensing |
| Power Consumption | < 4 W |
| Mounting | Vertical mounting on DIN Rail |
| Dimensions (H x W x D) | 220 x 120 mm |
| Weight | 0.3 kg |
| Redundancy | Yes, supports fault-tolerant configurations |
| Compliance | CE, UL, FM, CSA, ATEX (depending on configuration) |
Applications
The 8C-PAIHA1 Analog Input Module is designed for use in a variety of industrial sectors where precise analog input signal acquisition is essential. These include:
-
Chemical and Petrochemical Plants
-
Oil and Gas Production
-
Pharmaceutical and Biotechnology Manufacturing
-
Water and Wastewater Treatment
-
Power Generation Plants
-
Food and Beverage Processing
-
Mining and Metal Processing
-
Environmental Monitoring Systems
Whether dealing with temperature, pressure, flow, or level signals, this module is capable of handling diverse process variables, delivering accuracy and operational stability.
Product Advantages
High Channel Density
With 16 input channels, it provides ample analog signal capacity in a compact form, saving space and wiring.
HART Protocol Support
Enables remote configuration, diagnostics, and optimization of connected field devices.
Built-In Redundancy
Ensures continued operation and high availability in mission-critical environments, reducing the risk of downtime.
High Accuracy and Precision
The module’s 16-bit resolution ensures precise signal processing for critical applications.
Hot-Swap Capability
Allows for maintenance or replacement without the need to shut down the process, minimizing operational interruptions.
Electrical Isolation
Channel-to-channel and channel-to-ground isolation protect against electrical noise and surges, enhancing reliability.
Wide Operating Temperature Range
Capable of functioning in extreme temperatures, making it versatile across various industrial environments.
