Product Introduction
The Honeywell 8C-PAIMA1 51454473-175 is a high-performance low-level analog input module engineered for accurate and reliable temperature sensing using Resistance Temperature Detectors (RTDs). As part of the Experion Process Knowledge System (PKS) and integrated into the C300 control system, this module is specially designed to meet the demands of precise temperature measurement in industrial environments.
Capable of interfacing with a range of RTD types including Pt100, Ni100, and others, the 8C-PAIMA1 offers multi-channel support with high accuracy and built-in diagnostics. Its differential signal processing and advanced noise rejection capabilities make it suitable for harsh and electromagnetically noisy environments.
The module operates within a redundant, modular architecture that supports fast channel scanning, HART device pass-through (if applicable), and complete integration into Honeywell’s Experion PKS. It is ideal for critical control applications in process industries such as petrochemical, energy, pharmaceutical, and food processing.
Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | 8C-PAIMA1 |
| Part Number | 51454473-175 |
| Type | Low-Level Analog Input Module (RTD) |
| Input Type | RTD (e.g., Pt100, Pt1000, Ni100, Cu10, etc.) |
| Number of Channels | 8 differential channels |
| Signal Processing | Differential measurement with EMI noise rejection |
| Input Resolution | 16-bit |
| Input Accuracy | ±0.05% of full scale |
| Input Range | Configurable per RTD type (e.g., -200°C to +850°C) |
| RTD Excitation Current | Programmable, optimized for accuracy |
| Scan Time | Configurable, typically 10 ms/channel |
| Isolation | Channel-to-bus and channel-to-channel |
| Redundancy | Supported |
| Operating Temperature Range | -40°C to +70°C |
| Storage Temperature Range | -40°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
| Certifications | CE, UL, CSA, ATEX, IECEx |
| Mounting Method | Pluggable onto IOTA base |
| System Compatibility | Honeywell Experion PKS, C300 Controller |
| Built-in Diagnostics | Open wire, short circuit, out-of-range detection |
| Dimensions (H × W × D) | 157 x 106 x 35 mm |
| Weight | 0.45 kg |
Product Applications
-
Petrochemical and Refining Plants
Accurate temperature sensing for reactors, furnaces, and pipelines where precision is critical to maintaining safe and efficient operations. -
Power Generation Facilities
Monitoring of turbine casing temperatures, boiler wall temperatures, and bearing metal temperatures with high reliability. -
Pharmaceutical Industry
Precise thermal control is vital in drug synthesis and storage, making this module ideal for GxP and FDA-regulated environments. -
Food and Beverage Processing
Ensures consistent process temperature control in pasteurization, fermentation, and cold chain logistics. -
Pulp and Paper Industry
Enables reliable temperature monitoring in drying and bleaching processes, which require robust automation and redundancy. -
Water and Wastewater Plants
Used in the control of biological and chemical reaction processes where temperature feedback optimizes treatment efficiency.
Product Advantages
-
Precision Temperature Measurement
Supports high-accuracy RTDs with 16-bit resolution for critical applications requiring tight thermal control. -
Multiple RTD Compatibility
Offers broad compatibility with industry-standard RTD sensors, reducing integration complexity. -
Robust Electrical Isolation
Provides strong immunity to electrical noise and prevents ground loop interference across channels. -
Modular Redundant Design
Designed to support redundant configurations, ensuring continuous operation in the event of module failure. -
Comprehensive Diagnostics
Onboard health monitoring functions help proactively identify wiring faults, sensor issues, or out-of-range conditions. -
Compact Form Factor
High channel density in a small footprint helps reduce cabinet space and wiring complexity. -
Seamless Integration
Fully interoperable with Honeywell’s C300 controller and Experion PKS architecture for plug-and-play deployment.
Frequently Asked Questions (FAQ)
-
What types of RTDs are compatible with the 8C-PAIMA1 module?
It supports Pt100, Pt1000, Ni100, Cu10, and other standard RTD types. -
How many channels does the module support?
The module offers 8 differential input channels for RTD signals. -
Can I use this module for temperature-critical pharmaceutical applications?
Yes, the module provides the accuracy and diagnostics required for GxP-compliant environments. -
Does it support open-wire detection for RTDs?
Yes, open wire and short circuit diagnostics are built-in for each channel. -
What is the measurement accuracy of the module?
It offers up to ±0.05% of full-scale accuracy, suitable for precision applications. -
Is the module hot-swappable or redundant?
It supports redundancy when installed in a redundant architecture but is not hot-swappable by itself. -
Can I mix different RTD types on the same module?
No, all channels must be configured for the same RTD type to maintain accuracy. -
Does this module support HART communication?
No, this specific RTD module does not support HART pass-through; it is strictly for RTD analog input. -
What kind of environment is it suitable for?
It’s designed for industrial conditions with wide temperature ranges and robust EMC protection. -
How is the module mounted within the control system?
It is installed on a dedicated IOTA base and integrated into Honeywell’s C300 control chassis.
