Product Introduction
The Honeywell 8C-TAIX51 (51306979-175) is a robust Analog Input Module designed for integration into Honeywell’s Experion Process Knowledge System (PKS) and other Distributed Control Systems (DCS). This module acts as a critical interface for digital field signals, converting discrete on/off inputs from field devices such as switches, contacts, and relays into reliable, process-ready digital signals. Engineered for demanding industrial environments, the 8C-TAIX51 ensures high signal integrity and fast response times critical for effective control and monitoring in complex automation systems.
Built with durable components and advanced electrical isolation, this module supports efficient signal processing while protecting the control system from electrical noise and interference common in industrial settings. Its compact design and standardized mounting options allow for flexible and convenient installation in control cabinets or racks.
Product Specifications
Parameter | Details |
---|---|
Model Number | 8C-TAIX51 (51306979-175) |
Module Type | Analog Input Module |
Input Signal Type | Discrete ON/OFF signals (contacts, switches, relays) |
Number of Input Channels | 16 channels |
Input Voltage Range | 24 V DC nominal (typical), 12-30 V DC operational |
Input Current | 4-8 mA per channel (typical) |
Response Time | < 10 milliseconds |
Electrical Isolation | Optical isolation between inputs and system |
Wiring Type | Screw terminal blocks |
Mounting | DIN rail or panel mount |
Operating Temperature Range | -20°C to +70°C |
Storage Temperature Range | -40°C to +85°C |
Relative Humidity | 5% to 95% non-condensing |
Dimensions (W × H × D) | 220 x 120 x 152.4 mm |
Weight | 0.3 kg |
Certifications | CE, UL (dependent on configuration) |
Compatible Systems | Honeywell Experion PKS, DCS |
Applications
The 8C-TAIX51 Analog Input Module finds its applications in a broad spectrum of industrial automation fields, including:
-
Process Control: Capturing on/off statuses from safety switches, limit switches, and control relays in oil & gas, refining, and petrochemical plants.
-
Power Plants: Monitoring discrete inputs from breakers, alarms, and interlocks for turbine and generator control.
-
Water and Wastewater Management: Integration of flow switches, level switches, and valve positions for automated plant management.
-
Pharmaceutical Manufacturing: Reliable input signal acquisition from various on/off field devices in cleanroom and controlled environments.
-
Food & Beverage Industry: Discrete input monitoring for process safety and automation control.
-
Chemical Processing: Control and monitoring of digital signals from emergency shutdown systems and safety instrumented systems.
Advantages
-
High Reliability: Designed for continuous operation in harsh industrial environments with stable digital input detection.
-
Fast Response: Minimal delay in signal transmission ensures timely process control reactions.
-
Robust Electrical Isolation: Optical isolation protects the system from transient voltages and electrical noise.
-
Secure Wiring: Screw terminals provide secure and easy connections resistant to vibration.
-
Flexible Installation: Suitable for DIN rail or panel mounting to fit various control cabinet layouts.
-
Wide Operating Range: Operates efficiently across a broad temperature and humidity spectrum.
-
Compatibility: Fully integrates with Honeywell’s Experion PKS and other DCS platforms.
-
Compact Form Factor: Saves space in control cabinets while providing multiple input channels.
-
Industry Certifications: Meets necessary industrial standards ensuring safe and compliant operations.
-
Simplified Maintenance: Clear labeling and straightforward wiring reduce troubleshooting time.
Frequently Asked Questions (FAQ)
-
What is the input voltage range of the 8C-TAIX51?
The module typically operates at 24 V DC nominal, with an operational range between 12 to 30 V DC. -
How many digital inputs does this module support?
It supports 16 discrete input channels. -
What type of signals can it accept?
It accepts discrete ON/OFF signals from devices such as switches, relays, and contacts. -
Is the module electrically isolated?
Yes, it provides optical isolation between inputs and the control system to prevent noise interference. -
What are the physical dimensions and weight?
The module measures 220 x 120 x 152.4 mm, and weighs around 0.3 kg. -
Can it be mounted on DIN rails?
Yes, the module supports both DIN rail and panel mounting. -
What is the typical response time?
The response time is less than 10 milliseconds, allowing rapid signal processing. -
Is this module compatible with Honeywell Experion PKS?
Yes, it is fully compatible and optimized for Experion PKS and other Honeywell DCS systems. -
What certifications does this product hold?
It is CE and UL certified, depending on the specific configuration. -
How does the module handle harsh environmental conditions?
It is designed to operate within -20°C to +70°C temperature range and withstands humidity from 5% to 95% non-condensing.
