Honeywell 8C-TDIL11 51306858-175 Digital Input Module

Manufacturer:Honeywell

Product Number:8C-TDIL11 51306858-175

Product Type:Digital Input Module

Origin:USA

Dimensions:51 x 267 x 178 mm

Weight:0.5 kg

Views:111

Payment Methods:T/T, PayPal, Western Union

Condition:New & In Stock

Shipping Port:Xiamen, China

Warranty:1 Year

Lead Time:1-3 Working Days

Certificate:COO

Courier partners:DHL, UPS, TNT, FedEx and EMS.

Business hours:7*24


  • Product Details
  • FAQs
  • Related
  • Contact Us
  • Packing & Delivery
  • Product Ratings
Company Information
E-mail [email protected]
Mobile +8613666033393
Whatsapp +8613666033393
WeChat 13666033393
Add Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Honeywell 8C-TDIL11 51306858-175 Digital Input Module

Product Introduction

The Honeywell 8C-TDIL11 (Part Number: 51306858-175) is a rugged and high-density digital input module used within Honeywell’s Experion PKS control systems, particularly the C300 controller platform. It is designed to monitor and collect 32 discrete field input signals from on-site devices such as contact switches, safety interlocks, proximity sensors, and other binary output equipment.

Tailored for critical industrial applications, the module operates using a 24V DC nominal signal and offers channel-level isolation to ensure protection and signal integrity across harsh environments. Each input point is clearly monitored through diagnostic features and LED indicators for easy identification of real-time signal states. The 8C-TDIL11 is widely implemented in continuous process industries where operational reliability and signal accuracy are essential.


Product Specifications

Parameter Description
Model Number 8C-TDIL11
Part Number 51306858-175
Input Channels 32 Digital Inputs
Input Signal Type 24V DC (Sourcing)
Input Current ~5 mA typical @ 24V DC
Input Impedance Approx. 4.7 kΩ
Debounce Time Configurable (default 4 ms)
Channel Status LEDs Yes, per channel
Internal Diagnostics Yes (short/open detection, module health)
Power Supply Voltage Supplied via I/O chassis
Power Consumption Approx. 4.8 W
Isolation Voltage 1500 V RMS (Channel to Backplane)
Operating Temperature 0°C to +60°C (32°F to 140°F)
Storage Temperature -40°C to +85°C (-40°F to 185°F)
Humidity Range 5% to 95% RH, non-condensing
Mounting Type DIN Rail (Modular Chassis Mount)
Redundancy Support Yes (in redundant system configurations)
System Compatibility C300 Controller, Experion PKS
Dimensions (H × W × D) 51 x 267 x 178 mm
Weight 0.5 kg
Certifications CE, UL, CSA, ATEX-compliant (system dependent)

Applications

The Honeywell 8C-TDIL11 module is a versatile solution used across multiple industrial sectors:

  • Oil & Gas Refineries – Interfaces with limit switches and valve feedback devices in hazardous zones.

  • Chemical Processing Plants – Tracks binary sensor signals in reaction and batch units.

  • Metals & Mining – Captures operational status of heavy equipment, conveyors, and safety systems.

  • Food & Beverage Industry – Monitors machine door sensors, emergency buttons, and bin full indicators.

  • Power Plants – Used for turbine control, relay status inputs, and protection system interfacing.

  • Pharmaceutical Manufacturing – Ensures precision in automated batch controls and cleanroom applications.


Product Advantages

  • High Channel Density: Supports up to 32 inputs, helping reduce rack space and simplify installation.

  • Robust Signal Integrity: Built-in isolation and diagnostics protect against electrical noise and signal failures.

  • System-Wide Integration: Seamlessly connects with Honeywell’s Experion PKS architecture, minimizing engineering efforts.

  • Fault Detection: Features diagnostics for channel health, allowing proactive maintenance.

  • Redundant Compatibility: Works in redundant setups to support uninterrupted operation.

  • Compact Design: Space-saving format suitable for large-scale I/O deployments.

  • Field Troubleshooting Support: LED status indicators for each channel enable quick issue identification without special tools.


Frequently Asked Questions (FAQ)

  1. Q: What is the maximum number of inputs supported by the 8C-TDIL11?
    A: The module supports 32 discrete digital inputs.

  2. Q: What type of signal is required for input?
    A: It requires a nominal 24V DC signal for operation.

  3. Q: Can this module detect wiring faults like shorts or opens?
    A: Yes, it has internal diagnostic capabilities for fault detection.

  4. Q: Is the module hot-swappable?
    A: Yes, in systems designed with redundancy and appropriate safety configurations.

  5. Q: Are channel status indicators available?
    A: Yes, each channel has an associated LED for signal status display.

  6. Q: Can this module be used in a hazardous environment?
    A: Yes, provided the entire system meets the necessary ATEX or safety standards.

  7. Q: How is the module mounted in a system?
    A: It is installed on a DIN rail within a compatible I/O chassis.

  8. Q: What is the minimum operating temperature of the module?
    A: The minimum operating temperature is 0°C.

  9. Q: Is it compatible with older Honeywell controllers?
    A: It is designed for use with the C300 controller and newer Experion PKS environments.

  10. Q: How much does the module weigh?
    A: 0.5 kg.


Related Models (Same Series or Functionality)

Model Number Description Channels Signal Type System Compatibility
8C-TDIL01 Digital Input Module (Standard) 32 24V DC C300 / Experion PKS
8C-TDOD51 Digital Output Module 32 24V DC C300 / Experion PKS
8C-PAIH51 Analog Input Module 16 4–20 mA C300 / Experion PKS
8C-PAONA1 Analog Output Module 8 4–20 mA C300 / Experion PKS
8U-TDILA1 Fail-Safe Digital Input Module 16 24V DC (Fail-safe) Safety Manager Systems
8C-TAIX61 Thermocouple Input Module 16 TC Inputs C300 / Experion PKS

Popular Honeywell Models (Other Categories)

Model Number Description Function System
CC-PDOB01 Digital Output Module Output Control C300 / Experion PKS
CC-PAIH01 Analog Input Module Input Sensing C300 / Experion PKS
FC-TPSU02 Power Supply Module Redundant Power Safety Manager
TK-FTEB01 Ethernet Bridge Module Network Redundancy Experion PKS / Safety
MC-TAMR03 Analog Input Module High Accuracy Inputs TDC 3000 / C200
TC-PRR021 Redundant Processor Module CPU Redundancy TDC 3000 Platform

Frequently Asked Questions (FAQ)

  1. Q: What is the maximum number of inputs supported by the 8C-TDIL11?
    A: The module supports 32 discrete digital inputs.

  2. Q: What type of signal is required for input?
    A: It requires a nominal 24V DC signal for operation.

  3. Q: Can this module detect wiring faults like shorts or opens?
    A: Yes, it has internal diagnostic capabilities for fault detection.

  4. Q: Is the module hot-swappable?
    A: Yes, in systems designed with redundancy and appropriate safety configurations.

  5. Q: Are channel status indicators available?
    A: Yes, each channel has an associated LED for signal status display.

  6. Q: Can this module be used in a hazardous environment?
    A: Yes, provided the entire system meets the necessary ATEX or safety standards.

  7. Q: How is the module mounted in a system?
    A: It is installed on a DIN rail within a compatible I/O chassis.

  8. Q: What is the minimum operating temperature of the module?
    A: The minimum operating temperature is 0°C.

  9. Q: Is it compatible with older Honeywell controllers?
    A: It is designed for use with the C300 controller and newer Experion PKS environments.

  10. Q: How much does the module weigh?
    A: 0.5 kg.

Related Models (Same Series or Functionality)

Model Number Description Channels Signal Type System Compatibility
8C-TDIL01 Digital Input Module (Standard) 32 24V DC C300 / Experion PKS
8C-TDOD51 Digital Output Module 32 24V DC C300 / Experion PKS
8C-PAIH51 Analog Input Module 16 4–20 mA C300 / Experion PKS
8C-PAONA1 Analog Output Module 8 4–20 mA C300 / Experion PKS
8U-TDILA1 Fail-Safe Digital Input Module 16 24V DC (Fail-safe) Safety Manager Systems
8C-TAIX61 Thermocouple Input Module 16 TC Inputs C300 / Experion PKS

Popular Honeywell Models (Other Categories)

Model Number Description Function System
CC-PDOB01 Digital Output Module Output Control C300 / Experion PKS
CC-PAIH01 Analog Input Module Input Sensing C300 / Experion PKS
FC-TPSU02 Power Supply Module Redundant Power Safety Manager
TK-FTEB01 Ethernet Bridge Module Network Redundancy Experion PKS / Safety
MC-TAMR03 Analog Input Module High Accuracy Inputs TDC 3000 / C200
TC-PRR021 Redundant Processor Module CPU Redundancy TDC 3000 Platform
