Product Introduction
The Honeywell 8C-TPOX01 (Part No. 51307022-175) is a PROFIBUS Gateway Module specifically engineered to integrate seamlessly within Honeywell’s Experion PKS and TPS systems. Designed to enable communication between field devices and the control system, it serves as a reliable and efficient communication interface supporting PROFIBUS DP protocol. The module ensures optimal connectivity in complex automation environments and facilitates real-time data exchange between field devices and control nodes. Ideal for both new installations and retrofit upgrades, the 8C-TPOX01 delivers high-performance data communication in a compact and robust format.
Product Specifications
| Parameter | Description |
|---|---|
| Model Number | 8C-TPOX01 |
| Part Number | 51307022-175 |
| Communication Protocol | PROFIBUS-DP (RS485-based) |
| Interface Type | Optical/Isolated serial PROFIBUS-DP |
| Mounting Type | Rack-mounted (I/O module chassis) |
| Baud Rate | Up to 12 Mbps |
| Bus Interface | 1 x PROFIBUS DP, 9-pin D-sub connector |
| Status Indicators | LEDs for power, fault, and communication status |
| Redundancy Support | Yes (when paired with appropriate Honeywell redundancy modules) |
| Compatible Systems | Experion PKS, TPS, C300 Controller |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 5% to 95% non-condensing |
| Power Consumption | Approx. 5W |
| Dimensions (H x W x D) | 51 x 267 x 178 mm |
| Weight | 0.5 kg |
| Certification/Compliance | CE, UL, RoHS |
Product Applications
-
Process Automation: Used in industries such as oil & gas, chemicals, and petrochemicals where real-time data from sensors and actuators must be transmitted to the DCS system.
-
Power Generation: Interfaces field devices like pressure transmitters, temperature sensors, and actuators with turbine control systems.
-
Pharmaceutical Manufacturing: Enables regulatory-compliant control by ensuring reliable field-level communication.
-
Food & Beverage Automation: Facilitates precise, repeatable control in fast-paced production environments.
-
Paper & Pulp Industries: Supports legacy and modern PROFIBUS-enabled instruments for robust process control.
Product Advantages
-
Reliable PROFIBUS-DP Connectivity: Facilitates stable, high-speed communication between field devices and control system networks.
-
Easy Integration: Natively supported within Honeywell’s control platforms, reducing setup and configuration time.
-
Compact & Rugged Design: Built for long-term reliability in harsh industrial conditions.
-
Redundancy & Diagnostics: Supports fault-tolerant configurations and offers diagnostic indicators for fast troubleshooting.
-
Energy Efficient: Low power consumption ensures minimal heat generation and energy use.
-
Future-Proofing: Supports both current and legacy systems, helping extend the lifecycle of existing installations.
Frequently Asked Questions (FAQ)
-
What type of network does the 8C-TPOX01 support?
It supports PROFIBUS-DP, which is a high-speed serial fieldbus for automation applications. -
Can this module be used in redundant configurations?
Yes, it supports redundancy when used with the appropriate Honeywell components. -
Is the 8C-TPOX01 compatible with Experion PKS?
Absolutely. It is specifically designed to integrate with Experion PKS and TPS control systems. -
What is the data transmission speed?
It supports up to 12 Mbps, depending on the network configuration. -
What are the dimensions of the module?
The module measures 51 x 267 x 178 mm. -
Does the module require a separate power supply?
No, it receives power through the system’s I/O chassis. -
Can I use this module for device diagnostics?
Yes, it includes LEDs and software diagnostics tools for status and troubleshooting. -
Is this module field-upgradable?
Firmware updates can be applied via Honeywell’s engineering tools if needed. -
Is the module CE certified?
Yes, it complies with CE, UL, and RoHS standards. -
What’s the average lifespan of the 8C-TPOX01?
With proper environmental conditions, the average lifespan can exceed 10 years.
