Product Introduction
The Honeywell 8C-ZP0101 Digital Output Module is part of the ControlEdge and Experion series, designed to deliver reliable, high-speed digital output control within industrial automation and process control systems. Engineered for Honeywell’s safety and control systems, the 8C-ZP0101 module provides robust and deterministic output capabilities, making it a vital component in Distributed Control Systems (DCS) and Programmable Logic Controllers (PLC).
The module is utilized primarily to interface with field actuators and devices such as solenoids, relays, alarms, and motor starters. With its compact design and adherence to stringent industrial standards, the 8C-ZP0101 helps improve operational continuity and system integrity in high-demand environments such as oil and gas, chemical, power generation, and water treatment facilities.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 8C-ZP0101 |
| Function | Digital Output Module |
| Number of Channels | 16 isolated output channels |
| Output Type | Digital (Sink/Source Configurable) |
| Output Voltage | 24V DC nominal |
| Output Current per Channel | Up to 0.5 A |
| Response Time | < 1 ms |
| Isolation Voltage | 1500 V RMS between channels and system |
| Diagnostics | Channel-level diagnostics with fault indication |
| Hot Swap Capability | Yes |
| Redundancy Support | Yes (with compatible base and backplane) |
| Operating Temperature Range | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Dimensions (H × W × D) | 130 x 30 x 145 mm |
| Weight | 0.35 kg |
| Mounting | DIN Rail or Panel Mount (via baseplate) |
| Certifications | CE, UL, CSA, ATEX (for hazardous environments) |
Applications
-
Oil & Gas: For controlling digital actuators and emergency shutdown systems in upstream and midstream operations.
-
Chemical Processing: Ideal for managing digital valve actuators, pumps, and interlock systems.
-
Power Generation: Used in turbine control panels and boiler management for output control.
-
Water & Wastewater Treatment: Suits pump and valve automation, as well as safety control outputs.
-
Pharmaceutical Manufacturing: Ensures precision control of batch and continuous process actuators.
Product Advantages
-
Industrial Grade Reliability: Designed for continuous operation in extreme industrial environments.
-
High Channel Density: 16 digital outputs in a compact form factor reduce cabinet space.
-
Advanced Diagnostics: Built-in health monitoring and fault reporting reduce downtime.
-
Redundant Architecture Support: Enables high system availability with hot-swap and redundancy features.
-
Flexible Output Configuration: Sink/source support allows adaptation to a wide range of field devices.
-
Global Compliance: Certifications for use in hazardous environments ensure broad applicability.
Frequently Asked Questions (FAQ)
-
What is the maximum current the 8C-ZP0101 can handle per channel?
Up to 0.5 A per channel at 24V DC. -
Can this module be used in redundant configurations?
Yes, it supports redundancy when installed with the appropriate Honeywell base and backplane. -
Is the module hot-swappable?
Yes, it supports hot-swapping for maintenance without shutting down the entire system. -
What types of field devices can be connected to the 8C-ZP0101?
Devices like relays, alarms, solenoids, and digital actuators can be connected. -
Does it support channel-level diagnostics?
Yes, it offers per-channel diagnostics and fault indication for enhanced troubleshooting. -
What certifications does the module have for hazardous environments?
It carries CE, UL, CSA, and ATEX certifications. -
Can the output type be configured as sink or source?
Yes, it is configurable for either sink or source output types. -
What is the recommended installation method?
It can be mounted on a DIN rail or via a panel-mounted baseplate. -
What is the typical application in a power plant?
It is often used for controlling boiler and turbine actuators and alarms. -
Is this module compatible with Honeywell’s Experion system?
Yes, it is fully compatible with Honeywell Experion PKS and ControlEdge platforms.
Recommended Related Models (Same Series or Functionality)
| Model | Description | Channels | Voltage Range | Hot Swap |
|---|---|---|---|---|
| 8C-ZP0102 | Digital Output Module, Enhanced Diagnostics | 16 | 24V DC | Yes |
| 8C-ZP0601 | Digital Input Module | 16 | 24V DC | Yes |
| 8C-ZP0401 | Analog Output Module | 8 | 0-20 mA | Yes |
| 8C-ZP0201 | Mixed I/O Module (8 In / 8 Out) | 16 | 24V DC | Yes |
| 8C-ZP0501 | Relay Output Module | 8 | 120/240V AC | No |
| 8C-PAI021 | Isolated Analog Input Module | 16 | 4-20 mA | Yes |
Popular Honeywell Models (Across Product Lines)
| Model | Product Type | Application | Compatibility |
|---|---|---|---|
| CC-PAIH01 | Analog Input Module | Field sensing & process monitoring | Experion PKS, ControlEdge |
| CC-TAIX01 | Analog Input Termination | Process signal termination | Experion I/O |
| CC-TDIL01 | Digital Input Module | Discrete input processing | Safety Manager, Experion |
| CC-TDOR01 | Digital Output Relay Module | Relay-driven device actuation | Safety Manager |
| CC-PDIL01 | High-Speed Digital Input | Critical fast input detection | ControlEdge |
| FC-TDIO11 | Mixed Digital I/O Module | Compact hybrid I/O deployments | Field Control Platform (FCP) |
