Product Introduction
The Honeywell CC-PAON01 51410070-176 Analog Output Module is a critical component designed for industrial control systems, responsible for converting digital control signals into precise analog current outputs. This module is widely used in Honeywell’s Experion PKS and other process control environments, enabling accurate manipulation of control devices such as valves, actuators, and other field instruments.
Built to deliver reliable 4-20 mA analog signals across multiple channels, the CC-PAON01 51410070-176 supports effective process automation with high precision and stability. Its robust design ensures long-term performance in demanding industrial environments. The module includes diagnostic functions for real-time health monitoring of output signals, helping prevent unexpected failures and supporting continuous plant operation.
This module is particularly valuable in industries such as oil and gas, power generation, chemical processing, water treatment, and pharmaceuticals, where tight control over processes is essential.
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | CC-PAON01 51410070-176 |
| Module Type | Analog Output Module |
| Number of Channels | 8 channels |
| Output Signal Range | 4–20 mA current output |
| Output Resolution | 16-bit DAC |
| Load Resistance | Up to 1000 Ω |
| Accuracy | ±0.1% of span |
| Response Time | < 10 ms |
| Power Supply | 24 V DC (from control system rack) |
| Operating Temperature Range | 0°C to 60°C |
| Storage Temperature Range | -40°C to 85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Dimensions (W × H × D) | 100 x 60 x 20 mm |
| Weight | 0.2 kg |
| Mounting | Rack-mounted in Honeywell control chassis |
| Certifications | CE, UL, CSA |
Product Applications
-
Process Control Systems: Provides precise analog output signals to control valves, actuators, and other field devices in process industries.
-
Power Plants: Regulates output signals to manage turbines, boilers, and other critical power equipment.
-
Oil and Gas Industry: Controls valves and flow control devices in pipelines, refineries, and petrochemical plants.
-
Chemical Manufacturing: Enables precise dosing and control for chemical reactions and blending processes.
-
Water and Wastewater Treatment: Supports pump and valve control for efficient water management.
-
Pharmaceutical Production: Maintains strict process control to ensure product quality and compliance.
Product Advantages
-
High Accuracy: Provides stable analog output with ±0.1% of span accuracy, ensuring reliable process control.
-
Multiple Channels: 8 output channels offer flexibility for complex control system configurations.
-
Fast Response: Sub-10 millisecond response time enables quick adaptation to process changes.
-
Durable Design: Built to operate reliably in harsh industrial conditions with wide temperature and humidity tolerance.
-
Diagnostic Monitoring: Built-in diagnostics help detect faults early, reducing maintenance and downtime.
-
Easy Integration: Seamlessly integrates into Honeywell Experion PKS systems and other Honeywell control architectures.
-
Compact Form Factor: Space-saving module design allows efficient rack utilization.
-
Stable Signal Output: Advanced noise reduction ensures clean analog signals even in electrically noisy environments.
Frequently Asked Questions (FAQ)
-
What type of output signals does the CC-PAON01 51410070-176 support?
It supports 4-20 mA current analog output signals. -
How many output channels are available on this module?
The module includes 8 independent analog output channels. -
What is the accuracy of the analog output?
The output accuracy is ±0.1% of the signal span. -
Is this module compatible with Honeywell Experion PKS?
Yes, it is designed for compatibility with Experion PKS and similar control systems. -
What is the operating temperature range of this module?
It operates between 0°C and 60°C. -
Does the module feature diagnostic capabilities?
Yes, it includes diagnostic functions for monitoring output health and faults. -
What power supply does the module require?
The module runs on a 24 V DC power supply sourced from the control rack. -
What are the physical dimensions of the CC-PAON01 51410070-176?
Dimensions are 100 x 60 x 20 mm. -
What is the response time for the output signals?
The response time is less than 10 milliseconds. -
Can this module be used in safety-related applications?
While it can be part of a safety system, appropriate safety certifications and configurations must be confirmed.
