Honeywell CC-PDIL01 51405040-176 Digital Input Modules

Product Overview

The Honeywell CC-PDIL01 51405040-176 is a high-performance Digital Input Module designed for integration into Honeywell’s industrial control systems. It allows seamless connection with a variety of field devices, such as sensors, switches, and other digital equipment, enabling precise and reliable signal acquisition for process monitoring and control.

Engineered to handle the demands of industrial environments, this module offers an excellent combination of robust design, high noise immunity, and flexibility. It is ideal for use in industries such as manufacturing, power generation, oil & gas, and other critical sectors that require real-time digital input processing.

The module is designed to integrate easily into Honeywell’s control systems like Experion and Safety Manager, ensuring efficient, high-quality performance.

Key Features

• Wide Input Voltage Range: The module accepts input voltages from 10 V DC to 30 V DC, providing flexibility for various field devices.

• Galvanic Isolation: Ensures electrical isolation between input channels and the control system, protecting the integrity of the data and system.

• High Noise Immunity: Designed to work effectively in high-electrical-noise environments typical of industrial settings.

• Status Indicators: Each input channel is equipped with its own LED indicator to easily monitor input status in real time.

• Flexible Integration: Designed for seamless integration with Honeywell’s Experion and Safety Manager control systems.

• Compact and Robust Design: The module is built for durability and space efficiency, making it suitable for environments where reliability and size are critical.

• Extended Temperature Range: Operates efficiently in a wide temperature range from -20°C to +60°C, suitable for industrial and outdoor applications.

• Modular Installation: Easy installation via DIN rail or panel mount, enhancing flexibility and simplifying system setup.

• Compliance: Meets industry standards, including CE, UL, RoHS, and IEC 61508 for safe operation in critical systems.

Technical Specifications

Industry Applications

• Manufacturing – Ideal for automated manufacturing processes where reliable signal acquisition from machines, sensors, and switches is essential.

• Oil & Gas – Used for safety systems and process control in hazardous locations, ensuring accuracy and reliability in critical operations.

• Power Generation – Perfect for monitoring digital signals from devices in power plants, contributing to operational efficiency and safety.

• Chemical Processing – Suitable for the monitoring of digital inputs from safety devices and field sensors in chemical plants.

• Water & Wastewater Treatment – Ensures reliable monitoring of field sensors in water treatment facilities.

• Automotive – Helps with monitoring assembly line processes by reading signals from sensors and control switches.

Product Advantages

• Wide Compatibility – Compatible with a broad range of field devices, from simple switches to complex sensors.

• High Noise Immunity – Ideal for environments with high electrical noise, ensuring stable and accurate data processing.

• Seamless Integration – Easily integrates with Honeywell Experion and Safety Manager control systems, streamlining process control and monitoring.

• Space-Efficient – The compact design reduces the need for excessive panel space in control systems.

• Reliable and Durable – The module is engineered for high reliability in critical industrial applications, ensuring long-term operation without failure.

• Real-Time Feedback – With LED indicators for each input channel, operators can quickly assess the health of the inputs in real time.

Frequently Asked Questions (FAQ)

1. What types of devices can be connected to the CC-PDIL01 module?
   The CC-PDIL01 can be connected to devices such as dry contacts, switch closures, and 24 V DC sources, making it compatible with a wide range of field devices.

2. How many channels are available on the module?
   The CC-PDIL01 features 16 channels, arranged in 4 groups of 4 inputs.

3. What is the operating temperature range of the module?
   The module can operate in environments ranging from -20°C to +60°C, making it suitable for most industrial settings.

4. Is there any feedback on the input status?
   Yes, each input channel has an LED indicator for easy monitoring of the signal status.

5. What is the input voltage range of the module?
   The CC-PDIL01 supports an input voltage range of 10 V DC to 30 V DC.

6. Does this module integrate with Honeywell control systems?
   Yes, it seamlessly integrates with Honeywell’s Experion and Safety Manager control systems.

7. What certifications does the module have?
   The CC-PDIL01 is certified to CE, UL, RoHS, IEC 61131-2, and IEC 61508 standards.

8. How is the module installed?
   The module can be easily mounted using DIN rail or panel mounting methods, offering flexible installation options.

9. What is the weight of the module?
   The CC-PDIL01 weighs approximately 0.4 kg.

10. Can the module be used in hazardous environments?
    The module is not specifically rated for explosive environments, but it meets high safety standards (IEC 61508), ensuring safe operation in critical control systems.
