Product Introduction
The Honeywell CC-PFE221 Fiber Optic Extender Module is an advanced communication module engineered to extend high-speed data transmission over fiber optic networks within Honeywell’s Experion PKS and C300 Process Control Systems. Designed to meet the demanding requirements of modern industrial environments, this module ensures robust, noise-immune, and long-distance communication between distributed control nodes and remote I/O stations.
Its integration enhances system flexibility by overcoming the limitations of traditional copper wiring, providing immunity to electromagnetic interference (EMI) and enabling installations across expansive sites such as refineries, chemical plants, and manufacturing facilities. The CC-PFE221 is optimized for reliability, durability, and seamless compatibility with Honeywell’s robust control architecture.
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | CC-PFE221 |
| Function | Fiber Optic Extender Module |
| Supported System | Honeywell Experion PKS, C300 Controller |
| Communication Interface | Fiber Optic (Single-mode or Multi-mode) |
| Data Transfer Rate | Up to 1 Gbps |
| Maximum Transmission Distance | Up to 2 km (Multi-mode), 10 km (Single-mode) |
| Supported Fiber Type | 62.5/125 µm Multi-mode, 9/125 µm Single-mode |
| Connectors | LC or SC (system dependent) |
| Power Supply | 24 VDC typical |
| Power Consumption | Approx. 4 W |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -25°C to +70°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Dimensions (W x H x D) | 63.5 x 124.46 x 307.34 mm |
| Weight | 0.3 kg |
| Mounting | Rack-mounted, modular |
| Compliance | CE, FCC, UL |
Applications
The CC-PFE221 Fiber Optic Extender Module is used extensively across industrial applications where reliable, long-distance, and EMI-resistant communication is essential:
-
Oil & Gas Industry:
Extends fiber links between offshore platforms and central control stations, eliminating signal degradation in harsh marine environments. -
Chemical and Petrochemical Plants:
Maintains robust control network performance across complex and widely spread plant infrastructures. -
Power Generation:
Connects remote turbines, transformers, and control stations with central DCS systems using interference-free fiber optic communication. -
Pharmaceutical Manufacturing:
Facilitates secure and reliable data links across facilities subject to strict compliance and validation requirements. -
Water and Wastewater Treatment:
Provides reliable communication across extensive treatment plants where EMI could otherwise disrupt traditional cabling. -
Mining and Metals Processing:
Supports reliable control networks in environments with heavy electromagnetic noise and challenging physical conditions.
Advantages
-
Extended Communication Distance:
Enables fiber optic communication up to 10 km for single-mode and 2 km for multi-mode fibers. -
High Data Throughput:
Supports data rates up to 1 Gbps, ensuring real-time process control and monitoring. -
Immunity to EMI and RFI:
Provides robust, interference-free communication in electrically noisy industrial environments. -
Reliable and Durable Design:
Built for 24/7 operation in demanding industrial environments with a wide temperature and humidity tolerance. -
Seamless Integration:
Fully compatible with Honeywell Experion PKS and C300 controllers, facilitating easy upgrades and system expansion. -
Compact and Modular Form Factor:
Optimized for installation in Honeywell racks with minimal space requirements. -
Low Power Consumption:
Efficient design reduces operating costs and thermal load on enclosures. -
Compliance with Global Standards:
CE, FCC, and UL compliance ensures global applicability and safety. -
Minimized Maintenance Requirements:
Fiber optic design reduces wear and degradation compared to copper networks, lowering lifecycle maintenance costs. -
Enhanced System Flexibility:
Simplifies network architecture, supporting modular expansions across large plant footprints.
Frequently Asked Questions (FAQ)
-
What is the main function of the CC-PFE221 module?
It extends the communication range of control networks using fiber optic cables, enabling EMI-resistant, long-distance connections. -
Which Honeywell control systems does it support?
The CC-PFE221 is fully compatible with Honeywell Experion PKS and C300 process controllers. -
What fiber types are supported?
Both single-mode (9/125 µm) and multi-mode (62.5/125 µm) fibers are supported. -
What is the maximum transmission distance?
Up to 2 km with multi-mode fiber and up to 10 km with single-mode fiber. -
What are the module’s dimensions?
The unit measures 63.5 x 124.46 x 307.34 mm. -
How much does the CC-PFE221 weigh?
0.3 kg. -
Is the module resistant to EMI?
Yes, fiber optic communication is naturally immune to electromagnetic and radio frequency interference. -
Does the unit require special cooling?
No special cooling is needed; it operates reliably within 0°C to +60°C ambient temperature. -
Can it be installed in existing Honeywell racks?
Yes, it is designed for easy rack-mounted installation within Honeywell system architecture. -
Does it require extensive maintenance?
No, fiber optic networks have minimal maintenance needs compared to traditional copper wiring.
