Product Introduction
The Honeywell CC-PWRB01 Power Supply is a reliable and efficient power module designed to provide stable and continuous electrical power to Honeywell control systems and industrial automation equipment. Engineered with durability and performance in mind, the CC-PWRB01 ensures that critical control modules operate without interruption, protecting sensitive electronics from power fluctuations and outages.
This power supply module is an integral component in many Honeywell systems, providing the necessary voltage and current regulation to support various process controllers and peripheral devices. Its robust design is suitable for industrial environments where consistency and reliability are paramount.
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | CC-PWRB01 |
| Input Voltage | 100-240 V AC, 50/60 Hz |
| Output Voltage | 24 V DC nominal |
| Output Current | 5 A maximum |
| Power Output | 120 W nominal |
| Efficiency | >85% |
| Operating Temperature | -20°C to +60°C (-4°F to +140°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Humidity | 5% to 95% non-condensing |
| Dimensions (WxHxD) | 160 x 130 x 40 mm |
| Weight | 1.2 kg |
| Mounting | DIN rail |
| Certifications | CE, UL, CSA |
Applications
The CC-PWRB01 power supply is utilized in a variety of industrial and commercial applications, including:
-
Industrial Automation: Provides stable power to Honeywell controllers and modules in manufacturing lines, ensuring continuous operation.
-
Process Control Systems: Powers distributed control systems (DCS) in chemical, oil and gas, and pharmaceutical plants.
-
Building Automation: Supplies power for HVAC control systems and building management solutions.
-
Energy Management: Supports instrumentation in power generation and distribution facilities.
-
Safety Systems: Powers critical safety instrumented systems (SIS) requiring reliable and uninterrupted power sources.
-
Transportation Systems: Used in control cabinets for rail, traffic, and airport infrastructure management.
Advantages
-
Reliable Power Delivery: Provides consistent and stable 24 V DC output suitable for sensitive industrial electronics.
-
Wide Input Range: Accepts universal AC input voltage from 100 to 240 V, accommodating global power standards.
-
High Efficiency: Operates at greater than 85% efficiency, reducing energy waste and heat generation.
-
Compact and Space-Saving: Small footprint allows for convenient installation in dense control panels.
-
Robust Build: Designed to withstand industrial conditions with wide temperature and humidity tolerance.
-
Easy Installation: DIN rail mounting simplifies integration and maintenance.
-
Overload and Short Circuit Protection: Enhances safety and prevents damage to connected devices.
-
Certified Quality: Meets international safety and performance standards, ensuring dependable operation.
-
Low Noise Operation: Designed to minimize electrical noise, protecting sensitive instrumentation.
-
Long Service Life: High-quality components and design extend operational lifespan under continuous use.
Frequently Asked Questions (FAQ)
-
What is the output voltage and current rating of the CC-PWRB01?
It provides a 24 V DC output with a maximum current of 5 A. -
Can the power supply operate with different AC voltages?
Yes, it supports a wide AC input range from 100 to 240 V at 50/60 Hz, suitable for worldwide use. -
What are the typical applications for this power supply?
It is used primarily in industrial automation, process control, building management, and safety systems. -
How is the CC-PWRB01 mounted in control cabinets?
It is designed for easy DIN rail mounting. -
Does the power supply have any protective features?
Yes, it includes overload and short circuit protection to safeguard connected equipment. -
What is the operating temperature range?
It operates reliably between -20°C and +60°C. -
Is this power supply compatible with all Honeywell control systems?
It is compatible with most Honeywell modules requiring 24 V DC power. -
How much space does it require for installation?
The unit measures 160 x 130 x 40 mm, fitting compactly into control panels. -
What certifications does the CC-PWRB01 hold?
It meets CE, UL, and CSA certifications for safety and quality. -
What maintenance is required for this power supply?
Regular visual inspections and ensuring proper ventilation are recommended to maintain optimal performance.
Recommended Related Models (Same Series or Similar Function)
| Model Number | Function | Dimensions (WxHxD) mm | Weight (kg) | Notes |
|---|---|---|---|---|
| CC-PWRB02 | Power Supply, 24 V DC, 10 A | 140 x 100 x 65 | 1.2 | Higher current rating |
| CC-PWRB03 | Redundant Power Supply | 130 x 90 x 60 | 1.0 | Supports power redundancy |
| CC-PWRB04 | Power Supply, 12 V DC, 5 A | 120 x 85 x 55 | 0.8 | Lower voltage output |
| CC-PWRB05 | Power Supply with Battery Backup | 150 x 110 x 70 | 1.5 | Includes UPS features |
| CC-PWRB06 | High Efficiency Power Supply | 130 x 90 x 60 | 0.9 | Improved energy efficiency |
| CC-PWRB07 | DIN Rail Power Supply, 24 V DC | 125 x 90 x 55 | 0.9 | Similar compact design |
