Product Overview – Honeywell CC-TCNT01 51308307-175
The Honeywell CC-TCNT01 51308307-175 is a Network Interface Module (NIM) designed for integration within Honeywell’s Experion Process Knowledge System (PKS) and C300 controller infrastructure. It serves as a communication interface, enabling seamless data exchange between the control system and the network backbone. This module supports high-speed deterministic communications and provides robust integration capabilities for distributed control applications in demanding industrial environments such as refining, power generation, petrochemical, and chemical processing.
Built with industrial-grade reliability, the CC-TCNT01 ensures the high availability and fault tolerance required for modern process automation. It is engineered to manage real-time data, reduce network latency, and integrate seamlessly into Honeywell’s Fault Tolerant Ethernet (FTE) architecture.
Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | CC-TCNT01 51308307-175 |
| Product Type | Network Interface Module (NIM) |
| System Compatibility | Honeywell C300 Controller / Experion PKS |
| Network Support | Fault Tolerant Ethernet (FTE) |
| Protocols | Ethernet, TCP/IP, FTE |
| Communication Ports | Dual RJ-45 Ethernet Ports |
| Data Rate | 10/100 Mbps |
| Power Consumption | < 5 W |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Humidity | 5% to 95% non-condensing |
| Mounting | Horizontal/Vertical DIN Rail Mount |
| Dimensions | 63.5 x 124.46 x 307.34 mm |
| Weight | 0.5 kg |
| Certifications | CE, UL, CSA, RoHS compliant |
Product Applications
The Honeywell CC-TCNT01 51308307-175 is extensively used across various industries that require high-reliability control and communication infrastructure:
-
Oil & Gas Processing Plants
-
Power Generation Facilities
-
Chemical and Petrochemical Industries
-
Pulp and Paper Manufacturing
-
Water Treatment Plants
-
Pharmaceutical Production Systems
Its ability to integrate seamlessly with C300 controllers makes it ideal for real-time automation and secure data transmission across distributed systems.
Product Advantages
-
Fault-Tolerant Design: Supports dual Ethernet connections, ensuring redundancy and communication continuity.
-
High Availability: Critical for industries that require 24/7 operation and fail-safe communication.
-
Seamless Integration: Native compatibility with Honeywell’s C300 controllers and Experion PKS.
-
Compact Size: Designed for space-efficient DIN rail mounting.
-
Long Lifecycle: Industrial-grade components ensure durability and extended operational life.
-
Reduced Downtime: Hot-swap capabilities and redundancy improve maintenance efficiency.
-
Security Support: Meets modern security standards to protect process networks.
10 Frequently Asked Questions (FAQs)
Q1: What is the main function of the CC-TCNT01 module?
A1: It acts as a network interface for C300 controllers, facilitating communication over Fault Tolerant Ethernet networks.
Q2: Can the CC-TCNT01 be used in non-Honeywell systems?
A2: It is specifically designed for Honeywell Experion systems and is not intended for third-party systems.
Q3: How many Ethernet ports are available on this module?
A3: It has two RJ-45 Ethernet ports to support redundant FTE connections.
Q4: Is the CC-TCNT01 hot-swappable?
A4: Yes, the module can be replaced without shutting down the entire system.
Q5: Does the CC-TCNT01 support diagnostics?
A5: Yes, it includes built-in diagnostics for communication and health status monitoring.
Q6: What is the rated voltage or power input?
A6: It is powered through the backplane of the controller, typically consuming less than 5 W.
Q7: How does the CC-TCNT01 enhance system reliability?
A7: Through dual Ethernet ports, it ensures communication continuity in case one network path fails.
Q8: Can it operate in outdoor or harsh environments?
A8: It is designed for industrial use with a wide temperature range but must be housed in protective enclosures.
Q9: Is firmware upgradeable?
A9: Yes, firmware updates are supported via Honeywell tools to improve functionality or security.
Q10: How do I confirm compatibility with my control system?
A10: Compatibility is assured with Honeywell’s Experion PKS and C300 systems; check system revision levels in documentation.
Recommended Related Models (Same Series or Function)
| Model | Description |
|---|---|
| CC-TDIL01 | Digital Input Module, 24VDC, 16 Channels |
| CC-TDOR01 | Digital Output Module, Relay Output, 8 Channels |
| CC-PAOH01 | Analog Output Module, 4 Channels |
| CC-PDIL01 | Digital Input, Pulse Count Capable |
| CC-TAOX01 | Analog Output, Isolated Channels |
| CC-PAIH01 | Analog Input Module, High Density |
Popular Honeywell Modules (Same Brand)
| Model | Description |
|---|---|
| CC-PUI01 | Universal Input Module for temperature/voltage |
| CC-PDOB01 | Digital Output Module, 24VDC |
| CC-TDIL01 | High-speed Digital Input Module |
| CC-TDOR01 | Relay-based Digital Output Module |
| CC-TAIX01 | Analog Input Module, Isolated Channels |
| CC-TCF901 | FTE Control Firewall Module |
