Honeywell DC-TPOX01 51307770-176 Pulse Backplane Module

Company Information
E-mail		sales@xmjzjsgs.com
Mobile		+8613666033393
Whatsapp		+8613666033393
WeChat		13666033393
Add		Room 1004, No. 62 Xiangxiu Li, Siming District, Xiamen City, Fujian Province, China

Product Introduction

The Honeywell DC-TPOX01 51307770-176 Pulse Backplane Module is an advanced industrial I/O component specifically designed for Honeywell’s Series C I/O architecture within Experion PKS and C300 controller environments.

This module serves as a specialized pulse backplane interface, enabling precise, reliable signal transfer between pulse-based field devices (such as flow meters, energy meters, turbine meters, and rotating equipment sensors) and the system controller. It is engineered for high-frequency pulse signal acquisition, making it ideal for use in advanced metering and process control applications where pulse accuracy, isolation, and integrity are paramount.

Built with a rugged construction and designed for high-reliability operation in harsh industrial environments, the DC-TPOX01 helps plants achieve accurate flow, energy, and production measurement while seamlessly integrating into Honeywell’s comprehensive control platform. The module also supports redundancy and diagnostics, ensuring system uptime and ease of maintenance.

Commonly found in industries such as oil & gas, chemical processing, power generation, water management, mining, and pulp & paper, this module is vital for systems that rely on fast, precise counting and accumulation of discrete pulses.

---

Product Specifications

---

Applications

• High-speed pulse counting for turbine meters and flow meters

• Energy metering in utilities, chemical, and refining industries

• Accurate production measurement and accumulation

• Metering of liquid and gas flows in oil & gas pipelines

• Steam flow measurement in power plants

• Monitoring of rotating machinery speeds and position

• Integration of third-party metering devices into Experion PKS

• Control and monitoring in district heating and cooling systems

• Batch processing metering in food & beverage production

• Water distribution and wastewater treatment monitoring

---

Product Advantages

• High-frequency pulse acquisition: Supports pulse rates up to 20 kHz, providing exceptional accuracy

• Versatile pulse input support: Handles contact closure, open collector, and voltage pulse types

• Channel isolation: Full galvanic isolation between channels and to system logic for reliable operation

• Built-in diagnostics: Module-level and per-channel diagnostics simplify fault detection and maintenance

• Wide industry application: Suitable for a broad range of process industries requiring pulse counting

• Seamless integration: Native compatibility with Honeywell Experion PKS and C300 architectures

• Compact design: Saves panel space and reduces installation complexity

• Rugged construction: Designed to withstand harsh industrial environments and temperature extremes

• Redundant power support: Increases system resilience and uptime

• Certified for hazardous areas: ATEX Zone 2 and IECEx certified for global industrial installations

---

Frequently Asked Questions (FAQ)

1. What is the primary function of the DC-TPOX01 module?
   It acts as a pulse interface module, acquiring high-frequency pulse signals from field devices and delivering them to the controller.

2. How many pulse input channels does it support?
   It supports 8 independent pulse input channels.

3. What is the maximum pulse frequency supported?
   The module supports up to 20 kHz pulse frequency per channel.

4. Which pulse types can the module handle?
   It handles contact closure, open collector, and voltage pulse inputs.

5. Is galvanic isolation provided?
   Yes — full galvanic isolation between channels and from channels to system logic.

6. Is it compatible with Honeywell Experion PKS?
   Yes — it integrates seamlessly with Experion PKS and C300 controllers.

7. Is the module suitable for hazardous areas?
   Yes — certified for ATEX Zone 2 and IECEx environments.

8. Does the module offer diagnostics?
   Yes — it includes both channel-level and module-level diagnostics with LED indicators.

9. What is the minimum pulse width that the module can detect?
   It can detect pulse widths as small as 25 μs.

10. What are the typical applications for this module?
    Applications include flow metering, energy metering, turbine flow measurement, production counting, speed monitoring, and more.

---
