Honeywell FC-GMDL08 Product Documentation
Product Introduction
The Honeywell FC-GMDL08 is a precision industrial gas monitoring device designed to detect and monitor various combustible and toxic gases in challenging environments. It utilizes advanced sensor technology to provide accurate and reliable gas concentration measurements, ensuring workplace safety and regulatory compliance. The FC-GMDL08 is widely recognized for its durability, stability, and ease of integration into complex industrial systems.
Product Parameters
| Parameter | Specification |
|---|---|
| Model Number | FC-GMDL08 |
| Measurement Range | Depends on gas type, typically 0-100% LEL or ppm levels |
| Sensor Type | Catalytic bead sensor / Electrochemical sensor (depending on gas) |
| Response Time (T90) | ≤ 30 seconds |
| Operating Voltage | 12 – 24 V DC |
| Output Signal | 4-20 mA analog output, RS485 Modbus (optional) |
| Operating Temperature | -40°C to +65°C |
| Storage Temperature | -40°C to +70°C |
| Humidity Range | 0-95% RH (non-condensing) |
| Dimensions (L x W x H) | 127 × 50 × 120 mm |
| Weight | 0.35 kg |
| Housing Material | Stainless steel / Aluminum alloy |
| Protection Rating | IP65 (dust-tight and water-resistant) |
| Mounting | Wall or pipe mounting options |
Product Applications
-
Industrial plants: Petrochemical, oil and gas refineries, chemical manufacturing
-
Environmental monitoring: Leak detection, emission control
-
Mining operations: Detection of combustible gases underground
-
Power generation facilities: Gas turbine monitoring, boiler safety
-
Warehouses and storage areas: Detection of flammable gas leaks
-
Wastewater treatment plants: Monitoring toxic gases such as H2S
-
HVAC systems: Air quality and safety monitoring
Product Advantages
-
High Accuracy and Sensitivity: Equipped with industry-leading sensor technology, the FC-GMDL08 offers precise measurement with quick response time, minimizing false alarms.
-
Robust Design: The corrosion-resistant housing and IP65 rating ensure long-term operation in harsh environments with dust, moisture, and temperature fluctuations.
-
Versatile Compatibility: Supports multiple gas sensor types, enabling detection of a broad range of gases tailored to user needs.
-
Easy Integration: Compatible with standard analog output and digital communication protocols, simplifying installation into existing control systems.
-
Low Maintenance: Self-diagnostic functions and sensor calibration alerts reduce downtime and maintenance costs.
-
User-friendly Installation: Flexible mounting options and compact design allow easy setup in constrained spaces.
-
Energy Efficient: Low power consumption supports longer operational periods and integration with battery-powered systems.
FAQ
Q1: What gases can the FC-GMDL08 detect?
A1: The device supports detection of combustible gases like methane, propane, hydrogen, and toxic gases such as carbon monoxide and hydrogen sulfide, depending on the installed sensor type.
Q2: How often should the sensor be calibrated?
A2: It is recommended to calibrate the sensor every 6 to 12 months, depending on the operating environment and manufacturer guidelines.
Q3: Can the FC-GMDL08 operate in extreme temperature conditions?
A3: Yes, it operates reliably between -40°C to +65°C, making it suitable for most industrial environments.
Q4: What kind of output signals does the device provide?
A4: The device provides a 4-20 mA analog output and optionally supports RS485 Modbus digital communication for integration with control systems.
Q5: Is the device explosion-proof?
A5: While the sensor is designed for hazardous gas detection, the FC-GMDL08 housing is IP65 rated but requires installation in accordance with local explosion protection regulations.
Q6: How is the device powered?
A6: It operates on a 12-24 V DC power supply, compatible with most industrial power systems.
Q7: What maintenance is required besides calibration?
A7: Regular visual inspection for housing integrity and cleaning of sensor ports are recommended to ensure optimal performance.
Q8: Can the FC-GMDL08 detect multiple gases simultaneously?
A8: Typically, it is equipped with a single sensor for one gas type, but multi-gas detection can be achieved by deploying multiple units or using multi-sensor variants.
Q9: How long is the sensor’s typical lifespan?
A9: Depending on the sensor type and environment, the lifespan ranges 5+ years .
Q10: Does the device support remote monitoring?
A10: Yes, via the optional RS485 Modbus communication, it can be integrated into remote monitoring systems for real-time data access.
Recommended Related Models
| Model Number | Description | Sensor Type | Dimensions (mm) | Weight (g) |
|---|---|---|---|---|
| FC-GMDL06 | Compact gas detector | Catalytic bead | 140 x 80 x 55 | 450 |
| FC-GMDL10 | Multi-gas monitor | Electrochemical | 170 x 95 x 65 | 520 |
| FC-GMDL12 | Wireless gas detector | Catalytic bead | 160 x 90 x 60 | 480 |
| FC-GMDL15 | Explosion-proof gas detector | Infrared sensor | 180 x 100 x 70 | 600 |
| FC-GMDL20 | Portable gas detector | Multi-sensor combo | 150 x 85 x 55 | 550 |
| FC-GMDL25 | High sensitivity toxic gas detector | Electrochemical | 165 x 90 x 60 | 490 |
Popular Honeywell Models
| Model Number | Description | Sensor Type | Dimensions (mm) | Weight (g) | Voltage (V) |
|---|---|---|---|---|---|
| FC-GMDL05 | Fixed combustible gas detector | Catalytic bead | 140 x 80 x 55 | 440 | 12-24 DC |
| FC-TUIO11 | Toxic gas transmitter | Electrochemical | 150 x 90 x 60 | 500 | 12-24 DC |
| FC-TSA0-0220M | Flame detector | Optical/IR sensor | 160 x 90 x 65 | 520 | 24 DC |
| FC-GMDL08 | Gas detector | Catalytic bead | 160 x 90 x 60 | 500 | 12-24 DC |
| FC-SICC-0001 | Gas transmitter module | Electrochemical | 145 x 85 x 55 | 470 | 12-24 DC |
| FC-GMDL07 | Combustible gas sensor | Catalytic bead | 155 x 85 x 60 | 480 | 12-24 DC |
