Product Introduction
The Honeywell FC-SDO-0824 is an advanced Safety Digital Output Module designed to deliver fast and reliable digital outputs for critical safety applications. As part of the Honeywell Safety Manager system, this module ensures that safety systems respond effectively to emergencies, activating key safety devices such as emergency shutdown valves, alarms, and safety interlocks. The FC-SDO-0824 is ideal for industrial environments where safety is of utmost importance, including sectors like oil & gas, power generation, petrochemical, and chemical manufacturing.
The module is engineered to meet the most stringent safety standards, including SIL 3 (Safety Integrity Level 3) certification, ensuring its high performance and reliability in safety-critical systems. Its robust design, flexible communication capabilities, and wide operating temperature range make it a versatile solution for controlling safety systems across a variety of industrial applications.
With its 8 digital outputs, the Honeywell FC-SDO-0824 provides a powerful solution to activate safety devices based on system conditions. The module’s compact size and easy integration into existing systems make it an ideal choice for enhancing industrial safety management.
Product Parameters
| Parameter | Specification |
|---|---|
| Model Number | FC-SDO-0824 |
| Dimensions | 100 × 160 × 20.32 mm |
| Weight | 0.5 kg |
| Digital Outputs | 8 Digital Outputs |
| Power Supply | 24 VDC |
| Operating Temperature | -40°C to +70°C (-40°F to +158°F) |
| Communication Protocol | Modbus, Profibus, HART |
| Mounting Type | DIN Rail Mounting |
| Hazardous Area Approval | ATEX, IECEx |
| System Compatibility | Honeywell Safety Manager System |
| Certification | SIL 3 Certified |
| Output Type | Open-collector type (digital) |
| LED Indicators | Diagnostic LEDs for each output channel |
Product Applications
The Honeywell FC-SDO-0824 safety digital output module is designed for use in industries that require the highest levels of safety and reliability. Some of the key applications include:
-
Emergency Shutdown Systems (ESD): In the event of a hazardous situation, the FC-SDO-0824 triggers emergency shutdown devices, such as valves and pumps, ensuring rapid response and minimizing potential damage.
-
Fire and Gas Detection Systems: The module integrates with fire and gas detection systems to trigger alarms and activate safety measures like shutdown valves or ventilation systems during dangerous conditions.
-
Industrial Process Control: The module can control essential processes in manufacturing and production systems by activating output devices that ensure the safe operation of critical equipment.
-
Chemical and Petrochemical Industry: Used in chemical plants to control safety devices that prevent leaks, spills, and other hazardous incidents, ensuring compliance with safety and environmental regulations.
-
Power Generation: In power plants, it provides safety outputs to activate alarms and shutdown systems, preventing equipment failure and ensuring a safe working environment.
-
Oil & Gas Industry: The module helps monitor and control critical safety devices in oil refineries, offshore rigs, and pipeline systems, where safety is vital to protect against leaks, explosions, and other hazards.
Product Advantages
The Honeywell FC-SDO-0824 safety digital output module offers several key advantages that make it an essential part of a safety management system:
-
SIL 3 Certified: The module is certified to Safety Integrity Level 3 (SIL 3), meeting the highest industry standards for reliability and safety in critical systems.
-
Fast Response Times: The FC-SDO-0824 delivers fast and reliable digital outputs, ensuring safety devices are activated quickly in response to hazardous events.
-
Compact Design: The module has dimensions of 100 × 160 × 20.32 mm, making it compact and easy to install in environments with limited space, while maintaining high performance.
-
Wide Operating Temperature Range: With an operating temperature range of -40°C to +70°C, the module is suitable for use in both hot and cold environments, ensuring reliable performance in challenging conditions.
-
Multiple Communication Protocols: The FC-SDO-0824 supports Modbus, Profibus, and HART communication protocols, making it compatible with a wide range of industrial control systems.
-
Hazardous Area Certifications: The module is approved for use in hazardous environments with ATEX and IECEx certifications, ensuring it can be safely deployed in explosive atmospheres.
-
Low Power Consumption: The 24 VDC power supply ensures low power consumption, contributing to energy efficiency and reducing operational costs.
-
Diagnostic LEDs: The module includes diagnostic LEDs for each output channel, providing real-time visibility of system health and aiding in troubleshooting.
-
Easy Integration and Installation: With DIN rail mounting, the module is easy to integrate into existing safety systems, reducing installation time and minimizing downtime.
-
Enhanced Safety: The FC-SDO-0824 helps enhance operational safety by activating crucial safety systems and controlling key devices in real time during emergency situations.
Frequently Asked Questions (FAQs)
-
What is the power supply requirement for the Honeywell FC-SDO-0824 module?
The module operates on 24 VDC, providing an efficient power solution. -
How many digital outputs does the FC-SDO-0824 have?
The module provides 8 digital outputs, enabling it to control multiple safety devices. -
What is the operating temperature range of the FC-SDO-0824?
The module operates in a temperature range of -40°C to +70°C (-40°F to +158°F), making it suitable for use in extreme environments. -
What type of output does the FC-SDO-0824 provide?
The module provides open-collector type digital outputs, ideal for controlling external safety devices. -
Can the FC-SDO-0824 be used in hazardous environments?
Yes, the module is ATEX and IECEx certified, ensuring its safe operation in hazardous areas. -
Is the FC-SDO-0824 SIL certified?
Yes, the module is certified to SIL 3, ensuring it meets the highest safety integrity standards. -
What communication protocols does the FC-SDO-0824 support?
The module supports Modbus, Profibus, and HART protocols, making it compatible with various industrial control systems. -
What are the dimensions of the Honeywell FC-SDO-0824?
The module has compact dimensions of 100 × 160 × 20.32 mm, allowing for easy installation in tight spaces. -
How is the FC-SDO-0824 installed?
The module features DIN rail mounting, which makes installation quick and easy. -
Can the FC-SDO-0824 be integrated with Honeywell Safety Manager systems?
Yes, the module is fully compatible with Honeywell Safety Manager Systems for enhanced safety management.
