Product Introduction
The Honeywell FC-TRO-1024 Relay Output Module is designed to provide reliable relay output control for industrial automation and process control systems. It allows seamless integration with Honeywell controllers and field devices, enabling precise signal switching and remote control of actuators, alarms, and other equipment. The module is engineered for robust performance in harsh industrial environments and ensures consistent operational reliability.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | FC-TRO-1024 |
| Type | Relay Output Module |
| Number of Channels | 16 |
| Output Type | Dry Contact Relay |
| Rated Voltage | 24 VDC / 120 VAC / 230 VAC |
| Maximum Switching Current | 2 A per channel |
| Response Time | ≤10 ms |
| Isolation Voltage | 1500 VAC |
| Communication Interface | Honeywell FC Bus |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% – 95% non-condensing |
| Mounting Type | DIN Rail / Panel Mount |
| Dimensions | 120 x 130 x 35 mm |
| Weight | 0.3 kg |
Applications
-
Industrial automation systems
-
Process control systems
-
Remote switching of field devices such as pumps, valves, and solenoids
-
Alarm and signaling circuits in manufacturing plants
-
Integration with Honeywell FC series controllers for monitoring and control
-
Building management systems for HVAC control
Advantages
-
High Reliability: Durable relay contacts for consistent switching in industrial environments
-
Flexible Integration: Compatible with Honeywell FC series controllers and other field devices
-
Compact Design: Small footprint for easy DIN rail or panel mounting
-
Fast Response: Relay switching time ≤10 ms ensures timely control actions
-
Wide Voltage Compatibility: Supports both DC and AC voltage ranges
-
Rugged Performance: Operates reliably in extreme temperatures and high-humidity conditions
FAQ
Q1: How many relay channels does the FC-TRO-1024 support?
A1: The module supports 16 independent relay output channels.
Q2: What is the maximum current per relay channel?
A2: Each channel can handle up to 2 A of switching current.
Q3: What types of loads can the module switch?
A3: It can switch dry contact loads, including AC and DC devices like solenoids, lamps, and small motors.
Q4: What is the response time for relay activation?
A4: The relay activation response time is ≤10 milliseconds.
Q5: How is the module powered and controlled?
A5: The module is powered via 24 VDC and communicates through the Honeywell FC Bus interface.
Q6: Can the module be mounted on a DIN rail?
A6: Yes, it supports both DIN rail and panel mounting.
Q7: Is the FC-TRO-1024 suitable for high-humidity environments?
A7: Yes, it operates reliably within 5%–95% non-condensing humidity levels.
Q8: What is the isolation voltage of the relay contacts?
A8: The isolation voltage is rated at 1500 VAC.
Q9: Can it switch both AC and DC loads?
A9: Yes, the module can switch 24 VDC, 120 VAC, and 230 VAC loads.
Q10: What temperature ranges can the module operate in?
A10: The operating temperature range is -20°C to +70°C.
