Product Introduction
The Honeywell FC-TSDL-16UNI is a high-performance, multi-functional signal conditioner designed for industrial automation and process control applications. It provides reliable signal conversion, isolation, and amplification, ensuring accurate data transmission between field devices and control systems. This unit is widely used in harsh environments due to its robust construction and compatibility with various input/output signals.
Product Parameters
| Parameter | Specification |
|---|---|
| Input Signal | 0-10V, 0-20mA, 4-20mA, RTD, Thermocouple |
| Output Signal | 0-10V, 0-20mA, 4-20mA |
| Isolation Voltage | 1500V AC/DC (input to output to power) |
| Accuracy | ±0.1% of full scale |
| Operating Temperature | -20°C to +70°C |
| Power Supply | 24V DC (18-32V DC range) |
| Dimensions (W x H x D) | 22.5 x 100 x 115mm |
| Weight | 0.2 kg |
| Mounting | DIN rail or panel mount |
| Certifications | CE, ATEX, IECEx, SIL2 |
Product Applications
The FC-TSDL-16UNI is ideal for:
-
Process Control Systems: Signal conditioning for sensors and transmitters.
-
Industrial Automation: Interface between PLCs and field devices.
-
Oil & Gas: Safe signal isolation in hazardous areas.
-
Power Plants: Reliable signal conversion for critical measurements.
-
Water Treatment: Monitoring and control of flow, pressure, and temperature.
Product Advantages
-
High Accuracy: ±0.1% precision ensures reliable data.
-
Wide Compatibility: Supports multiple input/output signal types.
-
Robust Isolation: 1500V isolation protects against noise and surges.
-
Compact Design: Space-saving DIN rail mounting.
-
Certified Safety: Complies with ATEX, IECEx, and SIL2 standards.
-
Durability: Operates in extreme temperatures (-20°C to +70°C).
Frequently Asked Questions (FAQ)
Q1: What input signals does the FC-TSDL-16UNI support?
A1: It accepts 0-10V, 0-20mA, 4-20mA, RTD, and thermocouple inputs.
Q2: Is this device suitable for hazardous areas?
A2: Yes, it is ATEX and IECEx certified for use in explosive environments.
Q3: What is the isolation voltage rating?
A3: 1500V AC/DC between input, output, and power supply.
Q4: Can it be mounted on a DIN rail?
A4: Yes, it supports DIN rail or panel mounting.
Q5: What is the operating temperature range?
A5: -20°C to +70°C.
Q6: Does it require external power?
A6: Yes, it operates on 24V DC (18-32V range).
Q7: What is the accuracy of the device?
A7: ±0.1% of full scale.
Q8: Is calibration required?
A8: Factory-calibrated, but field calibration is possible if needed.
Q9: What certifications does it have?
A9: CE, ATEX, IECEx, and SIL2.
Q10: What is the warranty period?
A10: Typically 1 years, subject to Honeywell’s terms.
