Product Introduction
The Honeywell FS-SCSBP212 is a critical system backplane module designed for the Safety Manager Series within Honeywell’s renowned Fail Safe Controller (FSC) platform. It serves as a core component in safety-related control systems, offering high reliability and seamless integration within redundant or high-integrity architectures.
This backplane enables the interconnection of various I/O modules and processors, facilitating efficient communication and power distribution in a compact, structured format. With robust design standards, the FS-SCSBP212 is tailored for mission-critical applications, such as emergency shutdown (ESD), fire and gas (F&G), burner management systems (BMS), and more.
Its durability and industrial-grade construction allow it to withstand harsh operating environments, meeting stringent safety integrity level (SIL) requirements as part of a TÜV-certified safety solution.
Product Specifications
| Parameter | Specification |
|---|---|
| Model Number | FS-SCSBP212 |
| Product Type | System Backplane for Safety Manager |
| Function | Signal and power distribution for I/O modules |
| Compatible Modules | FSC I/O cards, CPU cards, Power Supplies |
| Slot Configuration | 12 module slots |
| Mounting Type | Panel mounting (Horizontal or Vertical) |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Shock Resistance | 30G, 11ms |
| Vibration Resistance | 1.0G, 10–500Hz |
| Cable length | 1 m |
| Weight | 0.5 kg |
| Voltage Rating | Supports module power requirements (24 VDC) |
| Compliance | SIL3 (IEC 61508), CE, UL, TÜV |
| Material | High-grade industrial polymer and metal alloy |
Product Applications
The Honeywell FS-SCSBP212 is deployed across various safety and critical process environments. Its applications include:
-
Emergency Shutdown Systems (ESD) – Ensures immediate process halt during hazardous conditions.
-
Fire and Gas Detection (F&G) – Enables safe system response to fire or gas leaks.
-
Burner Management Systems (BMS) – Supports safe start-up, operation, and shutdown of burner units.
-
High-Integrity Pressure Protection Systems (HIPPS) – Provides rapid isolation in overpressure situations.
-
Refineries and Petrochemical Plants – For process safety layers in high-risk installations.
-
Power Generation Facilities – In turbine safety and boiler protection systems.
Product Advantages
-
Modular Expandability: Supports up to 12 modules, allowing customized I/O configurations based on project demands.
-
Industrial Durability: Built to withstand mechanical vibration, electrical noise, and thermal extremes.
-
Certified Safety: Fully compliant with SIL3 certification, ensuring it meets international safety standards.
-
Efficient Wiring and Maintenance: Structured layout and accessible slots improve ease of installation and reduce downtime.
-
High Reliability: Optimized for continuous operation in mission-critical settings with minimal failure risk.
-
Seamless Integration: Compatible with a wide range of Honeywell FSC modules, making system upgrades or replacements easy.
Frequently Asked Questions (FAQ)
Q1: What is the FS-SCSBP212 used for?
A1: It serves as the primary backplane in Honeywell Safety Manager systems, connecting power and signal lines between control modules.
Q2: How many modules can the FS-SCSBP212 support?
A2: It supports up to 12 modules in a single backplane configuration.
Q3: Is this backplane compatible with non-Honeywell modules?
A3: No, it is specifically designed for Honeywell FSC modules and may not function properly with third-party equipment.
Q4: What power voltage does the FS-SCSBP212 require?
A4: It typically operates with modules that require 24 VDC supplied via integrated or external power supplies.
Q5: What safety standards does this model meet?
A5: It meets IEC 61508 standards and is certified for SIL3 applications by TÜV.
Q6: Is it suitable for outdoor installation?
A6: Not directly. It must be installed within protective enclosures suitable for environmental conditions.
Q7: Can I use multiple FS-SCSBP212 backplanes in one system?
A7: Yes, systems requiring more I/O can use multiple interconnected backplanes.
Q8: How is the FS-SCSBP212 mounted?
A8: It is typically panel-mounted in a horizontal or vertical orientation inside control cabinets.
Q9: What happens if one module fails on the backplane?
A9: The design allows individual module replacement without affecting the rest of the system, supporting hot-swap in some cases.
Q10: Is there a standard maintenance schedule for this component?
A10: Regular inspections for dust accumulation, connector integrity, and thermal condition are advised, typically on a quarterly basis.
Recommended Models (Same Series or Related)
-
Honeywell FS-CPU201 – Processor module for FSC systems
-
Honeywell FS-IOO-16 – Digital input/output module
-
Honeywell FS-PWR-P210 – Power supply module
-
Honeywell FS-AI-110 – Analog input module
-
Honeywell FS-DI-111 – Digital input module
-
Honeywell FS-DO-112 – Digital output module
Popular Honeywell Models (With Parameters)
| Model | Function | Dimensions (mm) | Weight (kg) | Voltage |
|---|---|---|---|---|
| FS-CPU201 | Safety Manager CPU | 190 x 130 x 40 | 0.6 | 24 VDC |
| FS-AI-110 | Analog Input Module | 130 x 115 x 35 | 0.5 | 24 VDC |
| FS-DI-111 | Digital Input Module | 130 x 115 x 35 | 0.4 | 24 VDC |
| FS-DO-112 | Digital Output Module | 130 x 115 x 35 | 0.4 | 24 VDC |
| FS-PWR-P210 | Power Supply Module | 200 x 120 x 50 | 1.2 | 24 VDC |
| FS-NTD-D010 | Network Interface Device | 150 x 110 x 40 | 0.6 | 24 VDC |
| FS-SDO-0824 | Safety Digital Output Module | 130 x 115 x 35 | 0.4 | 24 VDC |
| FS-TDO-1624 | Trip Digital Output Module | 130 x 115 x 35 | 0.4 | 24 VDC |
