Product Introduction
The Honeywell FS-SICC-0001/L9 is a high-performance I/O communication interface card designed specifically for the Fail-Safe Controller (FSC) platform within Honeywell’s TDC 3000 or Experion PKS safety systems. As part of a robust and secure architecture, this module facilitates seamless, reliable, and redundant communication between safety-critical input/output modules and the main controller, enabling deterministic control and monitoring of process safety applications.
The FS-SICC-0001/L9 is engineered for critical industrial environments where SIL-rated safety integrity and continuous operation are essential, such as in oil & gas, petrochemical, and power generation industries. It plays a pivotal role in ensuring safe shutdown procedures, emergency protection, and compliance with industry safety standards.
Product Advantages
-
High Reliability for Safety Systems
Designed to meet stringent safety system requirements and capable of SIL3 compliance in accordance with IEC 61508 standards. -
Deterministic Communication
Ensures time-bound and secure communication with minimal latency between controller and field devices. -
Redundant Support
Supports dual-redundant configurations for improved system availability and fault tolerance. -
Extended Service Life
Industrial-grade components ensure high endurance and long operational life in harsh conditions. -
Easy Integration
Seamless integration into Honeywell FSC architecture, reducing engineering time and simplifying lifecycle maintenance. -
Hot-Swappable Design
Enables replacement without system shutdown, ensuring high uptime and minimal disruption.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | FS-SICC-0001/L9 |
| Description | Safety System I/O Communication Card |
| System Compatibility | Honeywell FSC, Experion PKS, TDC 3000 |
| Supported Protocols | Proprietary Honeywell Safety I/O Protocols |
| Redundancy Support | Yes, full duplex redundant support |
| Communication Ports | Dual high-speed serial interfaces |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% to 95% non-condensing |
| Power Consumption | ≤ 5W |
| Mounting Type | FSC Standard Chassis Mount |
| Cable length | 9 m |
| Weight | 3 kg |
| Compliance | SIL3 (IEC 61508), CE, UL, CSA |
| Hot Swap Capability | Yes |
| Cooling Requirement | Natural convection, no fan required |
Product Applications
-
Emergency Shutdown Systems (ESD)
Ensures rapid and reliable execution of critical shutdown operations in hazardous processes. -
Burner Management Systems (BMS)
Interfaces safely with ignition control and flame detection modules. -
Fire & Gas Detection Systems (F&G)
Relays fault-tolerant information between sensors and logic solvers. -
High-Integrity Pressure Protection Systems (HIPPS)
Enables secure data transfer to maintain process pressure limits and avoid catastrophic failures. -
Turbomachinery Control
Provides real-time, secure communication for safety-related aspects of turbomachinery systems. -
Offshore Oil & Gas Facilities
Deployed in platforms for control of flammable or explosive environments.
Installation Notes
-
Mounting: Install the FS-SICC-0001/L9 into the designated FSC rack slot. Ensure correct alignment with guide rails.
-
Power-Off Before Handling: Even though hot-swappable, always follow site safety procedures before removal or installation.
-
Redundancy: If redundancy is required, install two identical SICC modules in paired slots for automatic failover.
-
Cabling: Use shielded twisted-pair communication cables per Honeywell standards. Ensure grounding is intact.
-
Firmware Compatibility: Ensure the firmware of the SICC module matches the FSC controller firmware version.
-
Diagnostics: Use system diagnostic tools to validate communication integrity after installation.
FAQ (Frequently Asked Questions)
Q1: What is the main function of the FS-SICC-0001/L9?
A1: It provides the interface for reliable, deterministic communication between the Honeywell FSC controller and distributed I/O modules.
Q2: Is the module compatible with redundant system configurations?
A2: Yes, the module fully supports redundancy and can operate in dual configuration for fault tolerance.
Q3: Can the FS-SICC-0001/L9 be hot-swapped during operation?
A3: Yes, it supports hot-swapping, but proper safety procedures must still be followed.
Q4: What is the typical power consumption of this module?
A4: It consumes less than 5 watts during standard operation.
Q5: Which systems can this module be used with?
A5: It is designed for Honeywell FSC systems and integrates with Experion PKS and TDC 3000.
Q6: Does the card support diagnostics or self-checks?
A6: Yes, it has internal diagnostics and communicates errors or status via the system software.
Q7: What communication protocols are used by this module?
A7: It uses Honeywell’s proprietary safety communication protocols optimized for high-integrity data.
Q8: What is the physical size of the module?
A8: Its Cable length are 9 m .
Q9: What’s the environmental operating range for temperature?
A9: It operates safely between -20°C to +70°C.
Q10: Is there any special cooling requirement?
A10: No, it uses natural convection and does not require external fans or forced cooling.
Recommended Same Series or Related Models
| Model Number | Description |
|---|---|
| FS-SDO-0824 | Safety Digital Output Module, 24-channel |
| FS-SAI-1624 | Safety Analog Input Module, 16-channel |
| FS-SDI-1624 | Safety Digital Input Module, 16-channel |
| FS-CPU-2010 | Fail Safe Controller Main Processor |
| FS-PDC-IOEP3 | I/O Expansion Power Distribution Chassis |
| FS-BLIND-CHAS3HE | Blind Chassis for unused slots |
Popular Honeywell Models (Same Brand)
| Model Number | Description | Dimensions (mm) | Weight | Voltage |
|---|---|---|---|---|
| CC-PDIL01 | Pulse Input Module for ControlEdge | 110 x 130 x 30 | 260 g | 24 VDC |
| CC-TDIL01 | Digital Input Module, 16-ch | 130 x 130 x 30 | 280 g | 24 VDC |
| CC-TDOB01 | Digital Output Module, 16-ch | 130 x 130 x 30 | 290 g | 24 VDC |
| CC-PDOB01 | Pulse Output Module, 8-ch | 110 x 130 x 30 | 265 g | 24 VDC |
| 51204172-175 | Analog Output Module, Series C | 125 x 135 x 35 | 300 g | 24 VDC |
| 51454416-100 | FSC Power Supply Module | 140 x 150 x 40 | 1.2 kg | 24 VDC |
| FS-SDO-0824 | Safety Digital Output, 8-channel | 260 x 115 x 25 | 480 g | 24 VDC |
| FC-SDI-1624 | Digital Input Module for safety applications | 260 x 115 x 25 | 450 g | 24 VDC |
