Product Introduction
The Honeywell FS-UCOM-HSE High Speed Ethernet Switch is a robust, industrial-grade networking component designed to provide reliable, high-speed communication for safety and process automation systems. It plays a critical role in ensuring seamless data exchange between controllers, I/O modules, and higher-level monitoring platforms.
This Ethernet switch is specifically engineered for mission-critical environments, offering deterministic communication, redundancy mechanisms, and secure data transfer. It supports both standard and safety-certified communication channels, making it a central element in Honeywell’s Fail-Safe Controller (FSC) platform and other safety-related applications.
With rugged construction and high electromagnetic compatibility (EMC) resistance, the FS-UCOM-HSE delivers long-term stability even in harsh process conditions, such as oil & gas, power generation, and chemical industries.
Product Specifications
| Parameter | Description |
|---|---|
| Model | Honeywell FS-UCOM-HSE |
| Function | High-Speed Industrial Ethernet Switch |
| Ports | 8 × 10/100 Mbps RJ-45 + 2 × Gigabit uplink (fiber/copper options) |
| Switching Capacity | 3.2 Gbps |
| Forwarding Rate | 2.4 Mpps |
| VLAN Support | IEEE 802.1Q compliant |
| Redundancy | Rapid Spanning Tree Protocol (RSTP), ring redundancy |
| Protocols Supported | TCP/IP, UDP, Modbus/TCP, Safety protocols |
| Diagnostics | LED indicators for link/activity, system health monitoring |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5% – 95% non-condensing |
| Power Supply | 24 VDC nominal (redundant power input supported) |
| Housing Material | Ruggedized metal enclosure |
| Mounting | DIN rail or panel mount |
| Dimensions | 180 × 140 × 45 mm |
| Weight | 0.95 kg |
Product Applications
-
Safety System Networking – Ensures reliable communication between Honeywell FSC safety controllers and I/O modules.
-
Process Control Integration – Provides deterministic data exchange in process automation environments.
-
Industrial Redundancy Networks – Supports redundant Ethernet ring topologies for uninterrupted communication.
-
Power Plants – Used in control rooms and substations for stable data networking.
-
Oil & Gas Facilities – Provides secure, high-speed networking for monitoring and shutdown systems.
-
Chemical Processing Units – Ensures robust data integrity in hazardous industrial environments.
Product Advantages
-
High Port Density – Supports multiple Ethernet connections with uplink flexibility.
-
Industrial Reliability – Built to withstand temperature extremes, EMC interference, and industrial vibration.
-
Enhanced Redundancy – Ring redundancy and RSTP prevent communication downtime.
-
Secure & Deterministic Communication – Essential for safety-critical networking.
-
Seamless Integration – Fully compatible with Honeywell FSC and other Honeywell safety platforms.
-
Compact Design – Space-saving installation with DIN rail mounting.
Frequently Asked Questions (FAQ)
-
How many Ethernet ports are available on the FS-UCOM-HSE?
The module provides 8 standard 10/100 Mbps ports and 2 Gigabit uplink ports, supporting both copper and fiber connections depending on configuration. -
Does the switch support redundancy for fault-tolerant communication?
Yes, it supports ring redundancy and RSTP protocols, ensuring communication remains active even if one network path fails. -
Can this switch handle both standard and safety-related communication?
Yes, it is designed to support regular process control data as well as SIL-rated safety communications within Honeywell safety networks. -
What is the maximum switching capacity of the device?
The switch has a switching capacity of 3.2 Gbps, ensuring smooth handling of high data throughput. -
Does the switch support VLAN segmentation?
Yes, the FS-UCOM-HSE is compliant with IEEE 802.1Q VLAN standards, allowing secure and segmented communication. -
Is there diagnostic feedback available for network health?
Yes, diagnostic LEDs provide real-time link/activity monitoring, and system-level health checks can be integrated with the Honeywell platform. -
What type of power input does this module require?
It operates on a nominal 24 VDC supply, with support for redundant power inputs to increase system availability. -
Is the FS-UCOM-HSE compatible with Modbus/TCP communication?
Yes, the switch supports Modbus/TCP as well as other industrial Ethernet protocols. -
What level of electrical isolation is provided for Ethernet ports?
Each port is galvanically isolated, minimizing interference and ensuring reliable performance in electrically noisy environments. -
Can this switch be panel mounted as well as DIN rail mounted?
Yes, it provides flexibility for both DIN rail and panel mount installations depending on application requirements.
