Product Introduction
The Honeywell MC-PAOX03 51309152-175 Analog Output Module is a high-performance component used in process automation systems. Designed for precision and stability, it provides analog output signals to control actuators, valves, and other field devices. This module is widely integrated in Honeywell’s Experion and TDC systems, ensuring seamless communication and reliable performance in critical industrial environments.
Product Advantages
-
High Accuracy: Ensures precise analog output signals for accurate process control.
-
Stability & Reliability: Engineered for long-term operation in harsh industrial conditions.
-
Seamless Integration: Fully compatible with Honeywell control systems.
-
Noise Immunity: Designed to minimize signal interference and maintain output integrity.
-
Redundancy Support: Provides fault tolerance to improve system reliability.
-
Compact Design: Space-efficient, easy to install and replace.
Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | MC-PAOX03 51309152-175 |
| Product Type | Analog Output Module |
| Output Channels | 8 Channels |
| Output Signal Range | 4–20 mA (configurable) |
| Resolution | 12-bit / 16-bit (depending on configuration) |
| Isolation | Channel-to-channel and system isolation |
| Power Supply | 24 VDC nominal |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | 127 × 40 × 150 mm |
| Weight | 0.45 kg |
| Mounting | DIN-rail / system rack installation |
| Certifications | CE, UL, CSA, and IEC compliance |
Product Applications
-
Process Control: Regulation of flow, pressure, temperature, and level in industrial systems.
-
Oil & Gas: Control of wellhead valves, compressors, and pipeline monitoring equipment.
-
Power Generation: Used in turbine and generator control loops.
-
Chemical & Petrochemical: Management of reactor and distillation processes.
-
Water & Wastewater: Monitoring and controlling pumps, valves, and treatment systems.
-
Manufacturing Automation: Precision output control for robotic and automated machinery.
FAQ
Q1: What type of output signals does the MC-PAOX03 provide?
A1: It provides analog current outputs, typically configurable in the 4–20 mA range.
Q2: Does the module support channel isolation?
A2: Yes, it features channel-to-channel and system isolation to prevent signal interference.
Q3: How many analog output channels are available?
A3: The module provides 8 independent analog output channels.
Q4: What resolution does the module offer?
A4: It supports up to 16-bit resolution depending on the configuration.
Q5: Can the module be hot-swapped in the system?
A5: Yes, it supports hot-swapping for ease of maintenance without system downtime.
Q6: Is redundancy supported for critical control applications?
A6: Yes, it can operate in redundant configurations to ensure high reliability.
Q7: What is the typical output load capacity?
A7: The module is designed to drive standard field devices with loads up to 750 ohms.
Q8: What diagnostic features are available?
A8: It provides self-diagnostics, error reporting, and channel health monitoring.
Q9: Can this module be configured remotely?
A9: Yes, configuration can be performed through the Honeywell control system software.
Q10: What communication backplane does the module use?
A10: It interfaces through the system backplane of Honeywell Experion/TDC racks.
