The Honeywell MC-PAOY22 80363969-150 is an industrial-grade analog output module designed to convert digital signals into precise analog outputs for process control systems. It plays a critical role in industrial automation by enabling the accurate control of valves, actuators, and other field devices that require analog input signals.
Built for durability and high performance, this module integrates seamlessly within Honeywell’s control systems, offering stable and reliable signal output. Its compact design ensures efficient use of panel space, while robust construction guarantees consistent operation under demanding industrial conditions.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | MC-PAOY22 80363969-150 |
| Module Type | Analog Output Module |
| Output Signal Types | 4-20 mA, 0-20 mA, 0-10 V |
| Number of Channels | Single channel |
| Accuracy | ±0.2% of full scale |
| Response Time | ≤ 50 ms |
| Dimensions (L x W x H) | 126 × 28 × 130 mm |
| Weight | 0.21 kg |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 0% to 95% non-condensing |
| Mounting | DIN rail or panel mount |
| Power Supply | 24 VDC |
| Communication Interface | Compatible with Honeywell control systems |
| Protection Features | Overload, short circuit, and open circuit protection |
Applications
The MC-PAOY22 analog output module is widely applied in industrial process control for precise and safe operation of field devices. Common application areas include:
-
Oil & Gas – Control of valve positioners and actuators to regulate flow and pressure.
-
Chemical and Petrochemical – Precise modulation of reactors and batch processes.
-
Power Generation – Output signal control for turbines and auxiliary equipment.
-
Water & Wastewater Treatment – Regulation of pumps and valve actuators in treatment processes.
-
Pharmaceutical – Ensuring accurate control in manufacturing and processing lines.
-
Food & Beverage – Managing analog control of processing machinery and instrumentation.
Key Advantages
-
High-Accuracy Output: Delivers precise and stable analog signals essential for accurate process control.
-
Compact Size: Measures just 126 × 28 × 130 mm and weighs 0.21 kg, saving panel space.
-
Durable Design: Built to withstand harsh industrial conditions including temperature extremes and humidity.
-
Fast Response: Provides output updates within 50 milliseconds for responsive control.
-
Multiple Signal Types: Supports common analog output standards (4-20 mA, 0-20 mA, 0-10 V).
-
Protective Features: Equipped with overload, short circuit, and open circuit protection to ensure reliability.
-
Flexible Mounting: Suitable for DIN rail or panel mounting to fit diverse installation needs.
-
Seamless Integration: Fully compatible with Honeywell’s process control systems for straightforward integration.
Frequently Asked Questions (FAQ)
-
What analog output signals does this module support?
It supports 4-20 mA, 0-20 mA, and 0-10 V output signals. -
How many output channels are available?
The module provides a single analog output channel. -
What is the accuracy of the analog output?
The accuracy is ±0.2% of full scale. -
What is the response time of the module?
Response time is 50 milliseconds or less. -
Can the module be mounted on a DIN rail?
Yes, it supports both DIN rail and panel mounting. -
What are the dimensions of the module?
Dimensions are 126 mm (L) × 28 mm (W) × 130 mm (H). -
What is the weight of the module?
The weight is approximately 0.21 kg. -
What is the operating temperature range?
The module operates between -20°C and +70°C. -
Does the module have built-in protection?
Yes, it includes overload, short circuit, and open circuit protection. -
Is it compatible with Honeywell control systems?
Yes, it is designed for compatibility with Honeywell process control architectures.
