The Honeywell MC-PHAO01 51403476-150 Analog Output Module is a key component of the Experion Process Knowledge System (PKS) and TDC3000 control systems. It is specifically designed to provide precise and stable analog output signals that can be used to drive actuators, control valves, and other process control elements. By ensuring reliable communication between the controller and the field devices, this module contributes to improved system stability, accuracy, and efficiency in industrial automation applications.
Product Parameters
| Parameter | Value |
|---|---|
| Product Type | Analog Output Module |
| Model Number | MC-PHAO01 51403476-150 |
| Output Channels | Multiple isolated analog outputs |
| Output Signal Range | 4–20 mA, 0–20 mA (configurable) |
| Accuracy | High precision with minimal drift |
| Isolation | Channel-to-channel and channel-to-bus |
| Operating Voltage | 24 VDC (nominal) |
| Power Consumption | Low power, energy efficient |
| Communication Protocol | Compatible with Honeywell I/O subsystems |
| Dimensions | 100 x 75 x 25 mm |
| Weight | 0.5 kg |
| Mounting Type | Rack-mounted within Honeywell system |
| Operating Temperature | -20 °C to +55 °C |
Product Applications
-
Petrochemical plants – controlling valves and pumps.
-
Power generation – managing actuators and turbines.
-
Pharmaceuticals – ensuring accurate dosing and mixing operations.
-
Food & beverage industry – process control in blending, heating, and storage systems.
-
Water treatment plants – regulating flow and chemical dosing.
-
Manufacturing automation – managing robotic arms, conveyor systems, and production lines.
Product Advantages
-
High Accuracy: Provides stable and precise analog outputs with minimal signal drift.
-
Robust Reliability: Designed for critical process industries requiring 24/7 uptime.
-
Flexible Configuration: Supports multiple output ranges for different applications.
-
Electrical Isolation: Ensures channel-to-channel protection, reducing noise and interference.
-
Easy Integration: Seamlessly integrates with Honeywell Experion and TDC3000 systems.
-
Compact Size: Optimized design with small footprint, ideal for dense system installations.
FAQ
Q1: How does the MC-PHAO01 handle channel isolation?
A1: Each output channel is galvanically isolated, ensuring noise immunity and preventing signal interference.
Q2: Can the output range be configured per channel?
A2: Yes, the module allows configuration for 4–20 mA or 0–20 mA depending on application needs.
Q3: What communication protocol does this module support?
A3: It is designed to work seamlessly with Honeywell I/O subsystem protocols within Experion PKS and TDC3000.
Q4: How is redundancy handled with this module?
A4: It supports redundant configurations by pairing with backup modules in the I/O subsystem, ensuring high availability.
Q5: What is the module’s response time for analog outputs?
A5: The response time is optimized for fast process control, typically in the millisecond range.
Q6: How does the module handle overcurrent protection?
A6: It features built-in electronic protection that safeguards output channels from short circuits and overloads.
Q7: Can this module be hot-swapped without shutting down the system?
A7: Yes, it supports hot-swapping within Honeywell chassis, minimizing downtime during maintenance.
Q8: How is calibration maintained over long-term operation?
A8: The module is factory-calibrated and uses temperature-compensated circuits to minimize drift over time.
Q9: What diagnostic features are available?
A9: It provides self-diagnostic functions including channel health monitoring, output status, and error reporting.
Q10: Is it compatible with older Honeywell control systems?
A10: Yes, it is backward-compatible with legacy Honeywell TDC3000 systems while also supporting modern Experion PKS.
