Honeywell MC-TAOX52 51304335-275 Analog Output Module

Product Introduction

The Honeywell MC-TAOX52 51304335-275 Analog Output Module is a high-precision 8-channel module designed for use within Honeywell’s Experion PKS, TDC 3000, and compatible distributed control systems. It provides reliable and accurate analog outputs to control field devices such as valves, actuators, and other industrial equipment.

Engineered for performance and stability, the MC-TAOX52 ensures precise voltage and current output signals with fast response times and minimal drift. Its design emphasizes reliability in critical process applications, supporting smooth integration into redundant and high-availability control system architectures.

The module features comprehensive diagnostics, including channel status monitoring, self-test routines, and communication error reporting, enabling proactive maintenance and minimal downtime. It is widely adopted in industries where precise analog control and long-term operational stability are essential.

Technical Specifications

Applications

The MC-TAOX52 8-channel Analog Output Module is used in industries requiring precise and stable analog control for process automation:

• Petrochemical and Refining Plants: Driving control valves and actuators for process loops.

• Power Generation: Controlling turbine and boiler auxiliary equipment requiring precise analog signals.

• Pharmaceutical Manufacturing: Supporting high-accuracy analog control of pumps and dosing systems.

• Chemical Production: Regulating critical process control parameters with stable output signals.

• Water and Wastewater Treatment: Providing precise control outputs to actuators and chemical dosing equipment.

• Laboratory and Pilot Plant Automation: Offering high-fidelity analog output for test and research environments.

Advantages

• High Precision Outputs: 16-bit DAC ensures accurate and repeatable voltage or current outputs.

• Flexible Configuration: Supports multiple ranges (0–20 mA, 4–20 mA, 0–10 V, ±10 V) per channel.

• Channel Isolation: Full galvanic isolation reduces interference and improves signal integrity.

• Reliable System Integration: Seamlessly fits Honeywell control racks with standard bus connectivity.

• Built-in Diagnostics: Monitors each channel for faults and communication errors, improving maintenance efficiency.

• Fast Response Time: 50 updates per second per channel allow responsive control in critical loops.

• Robust Design: Withstands industrial environmental conditions including vibration, EMI, and temperature variations.

• Compact Modular Form Factor: Facilitates high-density installation in control panels.

FAQ

1. How many analog output channels are available on the MC-TAOX52?
   The module provides 8 fully isolated analog output channels.

2. What types of signals can each channel output?
   Each channel can be configured to output current (0–20 mA, 4–20 mA) or voltage (0–10 V, ±10 V) signals.

3. Is each output channel electrically isolated?
   Yes, all channels feature full galvanic isolation to prevent cross-talk and maintain signal integrity.

4. What is the resolution of the digital-to-analog conversion?
   The module uses 16-bit DACs for high precision output.

5. Can output ranges be configured independently per channel?
   Yes, each channel can be individually configured to meet specific process requirements.

6. Does the module support diagnostic functions?
   Yes, it provides self-test routines, channel status monitoring, and communication error reporting.

7. What is the update rate for output signals?
   Each channel updates at 50 times per second, providing smooth and responsive control.

8. Is the MC-TAOX52 compatible with redundant system architectures?
   Yes, it is designed to work in redundant I/O configurations for high availability control systems.

9. What load impedances are supported for voltage and current outputs?
   0–1000 Ω for current output and ≥2 kΩ for voltage output.

10. Can the module be used with older Honeywell TDC 3000 systems?
    Yes, it is fully compatible with TDC 3000 and Experion PKS systems without modification.
