Product Introduction
The Honeywell MC-TDOD13 51304650-150 UCN Digital Output FTA (Field Terminal Assembly) is a robust and reliable solution designed to integrate digital output signals into industrial control systems. This module provides safe and isolated outputs for controlling devices such as relays, actuators, and other field equipment, offering precise and efficient control over critical industrial operations.
The MC-TDOD13 module utilizes Honeywell’s advanced signal processing technology to deliver high-speed, accurate, and noise-resistant digital output. With its compact design and versatile functionality, the module is ideal for use in demanding environments where control and monitoring of multiple field devices are required. Whether used in process automation, energy management, or safety-critical systems, the MC-TDOD13 ensures reliable signal integrity, operational efficiency, and ease of integration with other Honeywell control systems.
Product Parameters
| Parameter | Value |
|---|---|
| Dimensions | 230 x 123 x 20 mm |
| Weight | 0.6 kg |
| Output Type | Digital Output (ON/OFF) |
| Number of Outputs | 8 Digital Outputs |
| Output Voltage Range | 10V to 30V DC |
| Output Current | 3A per channel |
| Isolation Voltage | 500 VDC |
| Operating Temperature | -20°C to +60°C |
| Mounting | DIN Rail |
| Compliance | CE, UL, RoHS |
| Power Supply | 24V DC ± 20% |
Product Applications
The Honeywell MC-TDOD13 UCN Digital Output FTA is specifically designed for applications where multiple digital outputs are required to control various field devices such as relays, alarms, or actuators. Typical applications include:
-
Process Automation: Used to send digital commands to process control devices, such as valves, pumps, and other field instruments.
-
Factory Automation: Interfaces with automation equipment to control machinery, assembly lines, and other industrial systems in manufacturing environments.
-
Energy Management: Controls electrical devices such as circuit breakers, power meters, and transformers in power distribution systems.
-
Building Automation: Provides control signals for HVAC systems, lighting, and security devices in commercial and industrial buildings.
-
Safety Systems: Sends control signals to safety devices such as emergency shut-off valves or alarms, ensuring operational safety in critical environments.
-
Remote Control Systems: Used in remote terminal units (RTUs) for controlling field devices in distributed control systems, especially in energy, water, and oil industries.
Product Advantages
-
High Isolation Capability: The MC-TDOD13 features 500 VDC of isolation, which protects the control system from electrical interference and ensures the integrity of output signals.
-
Multiple Output Channels: It provides 8 digital output channels, offering efficient control for multiple devices within the same module.
-
Wide Voltage Range: The module supports a broad output voltage range (10V to 30V DC), making it versatile for various field devices.
-
High Current Capacity: Each channel supports up to 3A, providing reliable and high-power output for controlling industrial actuators and relays.
-
Easy Integration: The module mounts easily on a DIN rail, ensuring a straightforward installation process in industrial control panels.
-
Enhanced Durability: Designed to withstand temperatures ranging from -20°C to +60°C, the module operates reliably in demanding industrial environments.
-
Compact Design: The module’s small size (230 x 123 x 20 mm) and low weight (0.6 kg) make it ideal for space-constrained environments.
-
Status Indicators: Built-in LEDs provide clear visual feedback on the output status, simplifying diagnostics and maintenance.
-
Robust Compliance: Meets international standards, including CE, UL, and RoHS, ensuring safe operation and environmental compatibility.
-
Cost-effective Solution: Provides a high-performance, affordable solution for digital output control in various industrial automation applications.
FAQ
-
What type of output signals does the MC-TDOD13 module provide?
The MC-TDOD13 module provides digital output signals with ON/OFF control, making it suitable for controlling relays, actuators, and other binary devices. -
How many digital output channels does the MC-TDOD13 have?
The module offers 8 digital output channels, allowing for control of multiple devices simultaneously. -
What is the output voltage range supported by the MC-TDOD13?
The module supports an output voltage range of 10V to 30V DC, making it compatible with a wide range of industrial equipment. -
What is the current capacity of each output channel?
Each output channel can provide up to 3A, allowing it to control high-power devices such as motors or large relays. -
How does the MC-TDOD13 ensure signal integrity?
The module features 500 VDC isolation, which prevents electrical noise and surges from affecting the control system, ensuring reliable signal transmission. -
What is the operating temperature range of the MC-TDOD13?
The MC-TDOD13 operates within a temperature range of -20°C to +60°C, making it suitable for use in a wide variety of industrial environments. -
How is the MC-TDOD13 mounted in a control panel?
The module is designed for DIN rail mounting, ensuring easy installation and integration into industrial control panels. -
What compliance standards does the MC-TDOD13 meet?
The module complies with CE, UL, and RoHS standards, ensuring safety, environmental protection, and global compatibility. -
What types of field devices can be controlled by the MC-TDOD13?
The MC-TDOD13 can control a wide range of field devices, including relays, actuators, valves, alarms, and other digital devices in industrial systems. -
Can the MC-TDOD13 module be used in hazardous environments?
The module is designed for industrial environments but additional certification may be required for use in hazardous locations; consult with Honeywell for specific safety certifications.
