Product Overview
The Honeywell MU-TAIL03 51309202-125 is a high-precision Low-Level Analog Input Module designed to provide reliable and accurate analog signal measurement in a wide range of industrial applications. It is part of Honeywell’s advanced Experion system, used for precise monitoring and control of industrial processes. This module is ideal for reading low-level analog signals from sensors and converting them into readable data for system control.
The MU-TAIL03 is engineered for seamless integration into Honeywell’s control systems, ensuring compatibility with Experion PKS (Process Knowledge System) and other industrial control networks. It supports various types of low-level voltage and current input signals, making it a versatile component in industries such as chemical processing, manufacturing, energy, and utilities.
The module ensures high-quality signal conversion, enabling precise measurement and control of industrial parameters. Whether it’s for pressure, temperature, or other critical process variables, the MU-TAIL03 delivers dependable results, helping maintain operational efficiency and system reliability.
Technical Parameters
| Parameter | Specification |
|---|---|
| Model | MU-TAIL03 51309202-125 Low-Level Analog Input Module |
| Dimensions | 114 x 305 x 44 mm |
| Weight | 0.75 kg |
| Input Signal | Voltage (0-10V), Current (4-20mA) |
| Input Channels | 4 channels |
| Signal Conversion | 16-bit resolution |
| Accuracy | ±0.1% of full scale |
| Input Impedance | >1 MΩ |
| Power Supply | 24 V DC |
| Mounting Type | DIN Rail Mount |
| Operating Temperature | -20°C to 60°C |
| Humidity Range | 5% to 95% (Non-condensing) |
Applications
The Honeywell MU-TAIL03 Low-Level Analog Input Module is specifically designed to interface with a variety of sensors and provide accurate readings for critical process control in various industries. Its primary applications include:
-
Chemical and Petrochemical: Measuring and monitoring low-level signals from sensors like pressure transmitters, temperature sensors, and flow meters to ensure safe and efficient operation of chemical processes.
-
Manufacturing Automation: Used for real-time monitoring of equipment, processes, and systems, providing continuous analog signal measurement for automated control.
-
Energy and Utilities: Ideal for power generation facilities, oil and gas pipelines, and water treatment plants, where precise monitoring of analog signals is critical for ensuring operational safety and efficiency.
-
Building Management Systems (BMS): Helps control HVAC systems, lighting, and other building automation systems by interfacing with low-level sensors.
-
Environmental Control: Used in environmental monitoring systems to measure parameters like pH levels, humidity, and temperature, ensuring regulatory compliance and process accuracy.
Advantages
-
High-Precision Measurement: The MU-TAIL03 module provides 16-bit resolution, delivering precise and accurate analog signal conversion for critical applications.
-
Wide Input Compatibility: Supports both voltage (0-10V) and current (4-20mA) inputs, making it highly flexible and compatible with various industrial sensors.
-
Reliable Signal Conversion: The module ensures high accuracy (±0.1% of full scale), making it suitable for precise monitoring and control in demanding industrial applications.
-
Seamless Integration: It easily integrates into the Experion PKS and other Honeywell systems, offering smooth communication and data transfer for effective process control.
-
Compact and Efficient: With its DIN Rail mountable design, the module saves space in control cabinets and simplifies installation, while its small footprint of 114 x 305 x 44 mm and weight of 0.75 kg makes it ideal for space-constrained environments.
-
Wide Operating Range: The module operates in environments with temperatures ranging from -20°C to 60°C, ensuring reliable performance across various industrial conditions.
FAQ
-
What types of signals can the MU-TAIL03 module process?
The module processes low-level voltage (0-10V) and current (4-20mA) input signals, making it compatible with a wide range of industrial sensors. -
How many input channels does the MU-TAIL03 support?
The MU-TAIL03 supports 4 input channels, allowing it to process multiple signals simultaneously. -
What is the accuracy of the MU-TAIL03 module?
The module provides ±0.1% accuracy of the full scale, ensuring reliable and precise signal conversion. -
What is the resolution of the MU-TAIL03 module?
The module features 16-bit resolution, providing high precision for low-level signal measurements. -
What is the power supply requirement for the MU-TAIL03?
The module operates on a 24 V DC power supply, which is standard for industrial control systems. -
How is the MU-TAIL03 mounted?
The module is designed for DIN rail mounting, making it easy to install and integrate into control panels. -
What is the operating temperature range of the MU-TAIL03?
The module operates within a temperature range of -20°C to 60°C, making it suitable for a wide variety of industrial environments. -
Can the MU-TAIL03 be used with other control systems?
While the module is designed for integration with Honeywell Experion PKS, it can be used with any system that supports compatible analog input signals. -
What is the input impedance of the MU-TAIL03?
The input impedance of the module is greater than 1 MΩ, ensuring minimal signal loss and maintaining high signal integrity. -
Is the MU-TAIL03 module suitable for high-speed applications?
Yes, the module is capable of processing analog signals with high precision and reliability, making it suitable for a wide range of real-time monitoring applications.
