Product Description
The Honeywell TC-CCN012 ControlNet Interface Module is a reliable communication module designed for integration with Honeywell’s Experion and C300 systems. It facilitates high-speed, deterministic data exchange between Honeywell controllers and ControlNet devices, ensuring robust and time-sensitive industrial network performance.
Technical Specifications
| Parameter | Value |
|---|---|
| Module Name | TC-CCN012 |
| Communication Protocol | ControlNet |
| Application | Interface between C300 and ControlNet devices |
| Mounting | Cabinet-mounted (rack installation) |
| Dimensions (W x H x D) | 22 x 124 x 126 mm |
| Weight | 0.1 kg |
| Network Support | ControlNet Redundant or Non-Redundant |
| Environmental Rating | Standard industrial environments |
Applications
-
Distributed control systems using Honeywell Experion PKS
-
Integration of third-party ControlNet field devices
-
High-speed I/O communication in manufacturing and process control
-
System expansion via ControlNet network without interrupting existing operations
Advantages
-
Supports deterministic and high-speed communications
-
Seamlessly integrates with Honeywell C300 controllers
-
Redundant communication path support enhances reliability
-
Easy configuration through Honeywell engineering tools
-
Compact size suitable for dense cabinet layouts
FAQ
Q1: What is the function of the TC-CCN012 module?
A1: It serves as a communication bridge between the C300 controller and ControlNet network devices.
Q2: Can it be used with redundant networks?
A2: Yes, it supports both redundant and non-redundant ControlNet setups.
Q3: Is the module hot-swappable?
A3: No, power must be cycled before replacement.
Q4: What Honeywell system is it compatible with?
A4: It is primarily used with Experion PKS and C300 controllers.
Q5: How is the module mounted?
A5: It is installed in a rack-mounted cabinet configuration.
Q6: What type of devices can it connect to?
A6: Any standard ControlNet-enabled field device.
Q7: What is the weight of the module?
A7: The module weighs 0.1 kg.
Q8: What configuration tool is used?
A8: Honeywell’s engineering tools, such as Control Builder.
Q9: Does it support firmware updates?
A9: Yes, it supports firmware upgrades through Honeywell systems.
Q10: What is the benefit of using ControlNet?
A10: It offers deterministic performance and real-time data delivery.
Related Honeywell Models (Same Series/Function)
| Model | Description | Protocol | Dimensions (mm) | Weight |
|---|---|---|---|---|
| TC-CCN013 | ControlNet Interface with diagnostics | ControlNet | 22 x 124 x 126 | 0.1 kg |
| TC-FXX102 | Field I/O Interface Module | Fieldbus | 22 x 124 x 126 | 0.11 kg |
| TC-IAH161 | Analog Input Module | HART | 22 x 124 x 126 | 0.12 kg |
| TC-OAH061 | Analog Output Module | HART | 22 x 124 x 126 | 0.1 kg |
| TC-CCR012 | Redundant ControlNet Interface | ControlNet | 22 x 124 x 126 | 0.1 kg |
| TC-CEN013 | ControlNet Node Interface | ControlNet | 22 x 124 x 126 | 0.1 kg |
Popular Honeywell Models
| Model | Description | Application | Dimensions (mm) | Weight |
|---|---|---|---|---|
| 8C-PCNT02 | C300 Controller Module | Process Control | 30 x 200 x 140 | 0.15 kg |
| 8C-PAOHA1 | Analog Output w/ HART Module | Analog Output | 22 x 124 x 126 | 0.12 kg |
| 8C-PDILA1 | Digital Input Module | Digital Signal Acquisition | 22 x 124 x 126 | 0.1 kg |
| 8C-PDODA1 | Digital Output Module | Digital Signal Control | 22 x 124 x 126 | 0.1 kg |
| 900SP1-0300 | HC900 Expansion Processor | ControlEdge Systems | 45 x 100 x 120 | 0.18 kg |
| FC-IO-0001 | I/O Extension Module | HC900 Process Systems | 22 x 124 x 126 | 0.1 kg |
