Product Overview
The Honeywell TC-CCN013 97197873 A01 Redundant Network Interface Module is a high-performance and reliable solution designed to provide redundant communication capabilities within Honeywell’s control systems. This module plays a critical role in enhancing the reliability and availability of industrial control systems by ensuring uninterrupted network communication, even in the event of a failure. The TC-CCN013 module is particularly suitable for mission-critical applications in industries such as power generation, petrochemicals, oil & gas, and manufacturing, where continuous data communication is essential for the safe and efficient operation of processes.
The module features dual redundant network interfaces, offering fault tolerance and ensuring that if one network path fails, the other will seamlessly take over, providing a high level of communication reliability. This makes the TC-CCN013 module ideal for use in systems requiring high availability and fault tolerance, ensuring that the communication infrastructure remains robust and operational even in challenging environments.
Key Features
-
Redundant Communication Paths: Dual network interfaces provide redundant communication paths, ensuring continuous communication in case of failure.
-
High Availability: The module offers high availability with automatic failover between the two network paths.
-
Seamless Network Switching: Enables automatic and seamless switching between network interfaces, minimizing downtime.
-
Compact and Space-Efficient Design: Designed to fit easily into control panels without occupying excessive space.
-
Easy Integration: Compatible with Honeywell control systems and seamlessly integrates with Experion PKS and other Honeywell systems.
-
Built-in Diagnostics: Provides comprehensive diagnostics and status monitoring to quickly identify and address network issues.
-
Improved System Resilience: Enhances the resilience of the entire network by providing fault tolerance and ensuring consistent communication.
-
Flexible Configuration: Configurable to suit specific application requirements, offering flexibility in network setup.
-
Long-Term Reliability: Engineered for long-term use in harsh industrial environments, ensuring reliable operation and minimal maintenance.
Technical Specifications
| Specification | Description |
|---|---|
| Product Model | TC-CCN013 97197873 A01 |
| Product Type | Redundant Network Interface Module |
| Network Interfaces | Dual Ethernet Ports (Redundant) |
| Network Type | TCP/IP, Ethernet |
| Data Rate | 10/100/1000 Mbps |
| Operating Temperature Range | -20°C to +70°C (-4°F to +158°F) |
| Storage Temperature Range | -40°C to +85°C (-40°F to +185°F) |
| Power Supply | 24 V DC (Nominal) |
| Power Consumption | <5 Watts |
| Dimensions | 120 x 130 x 40 mm |
| Weight | 0.35kg |
| Protection Features | Over-voltage, Over-current Protection |
| Certifications | CE, UL, RoHS, IEC61508 (SIL-rated) |
Typical Applications
The Honeywell TC-CCN013 97197873 A01 Redundant Network Interface Module is used in a variety of industries and critical applications where network reliability and communication are paramount:
-
Power Generation: Ensures redundant communication paths between control systems and field devices in power plants.
-
Petrochemical and Chemical Plants: Provides fault tolerance for control systems in highly regulated and safety-critical environments.
-
Oil & Gas: Ensures reliable communication for offshore and onshore oil and gas installations, where downtime is costly.
-
Manufacturing: Enables continuous data exchange between production systems and control systems, ensuring minimal disruption.
-
Water Treatment: Provides reliable communication for supervisory control and data acquisition (SCADA) systems in water treatment plants.
-
Transportation: Used in transportation systems for real-time monitoring and communication in control systems.
-
HVAC Systems: Ensures seamless communication for building automation systems that rely on real-time data for control and optimization.
-
Automotive Manufacturing: Provides fault-tolerant network communication for manufacturing lines that rely on continuous data flow for operations.
Product Advantages
-
Redundancy and High Availability: Dual network interfaces ensure that communication remains uninterrupted in the event of a failure, providing fault tolerance and high availability.
-
Seamless Failover: Automatic failover between redundant network paths minimizes downtime and ensures that data transmission is always operational.
-
Improved Network Resilience: Provides a robust network infrastructure, reducing the risk of communication failure and enhancing overall system reliability.
-
Compact Design: The module is space-efficient, allowing easy installation in control panels with limited space.
-
Comprehensive Diagnostics: Built-in diagnostics tools enable quick identification of network issues, reducing troubleshooting time and ensuring operational efficiency.
-
Flexible Integration: Easy to integrate with Honeywell’s Experion PKS and other control systems, providing a smooth and reliable solution for critical applications.
-
Durable and Long-lasting: Designed to operate in harsh industrial environments, providing a long service life with minimal maintenance requirements.
-
Compliant with Industry Standards: The module meets international standards such as CE, UL, RoHS, and IEC61508, making it suitable for SIL-rated applications.
Frequently Asked Questions (FAQ)
-
What is the primary function of the TC-CCN013 module?
The TC-CCN013 is designed to provide redundant network communication paths, ensuring high availability and seamless failover between network interfaces. -
What types of network interfaces does the TC-CCN013 support?
It supports dual Ethernet ports with TCP/IP and Ethernet communication protocols, providing flexible network integration. -
What is the maximum data rate of the module?
The module supports data rates of 10/100/1000 Mbps, enabling high-speed communication for industrial control systems. -
Can the module handle network failures?
Yes, the module offers automatic failover between the two network interfaces, ensuring communication continuity in case of network failure. -
What is the power requirement for the TC-CCN013?
The module requires a 24 V DC nominal power supply for operation. -
What is the temperature range for operating the TC-CCN013?
The module operates within a temperature range of -20°C to +70°C (-4°F to +158°F), suitable for industrial environments. -
Is the TC-CCN013 module compatible with Honeywell’s control systems?
Yes, it integrates seamlessly with Honeywell’s Experion PKS and other Honeywell automation systems, providing reliable communication in critical applications. -
What certifications does the TC-CCN013 have?
The module is certified for CE, UL, RoHS, and IEC61508 (SIL-rated), ensuring compliance with safety, environmental, and industrial standards. -
How does the TC-CCN013 enhance system reliability?
The dual redundant network interfaces provide fault tolerance, ensuring communication remains active even during network issues or failures. -
What is the weight of the TC-CCN013 module?
The module weighs approximately 300 grams, making it easy to handle and install in control panels.
