Product Overview
The Honeywell TC-PCIC01 is a ControlNet communication interface module designed for use with PC-based control and monitoring systems. It enables integration of PCs into ControlNet networks for reliable, high-speed deterministic data transfer in industrial automation environments.
Applications
-
Integration of PC-based HMIs with ControlNet
-
Real-time process control and monitoring
-
Distributed control systems (DCS)
-
Factory automation and SCADA systems
-
Data acquisition systems requiring ControlNet connectivity
Advantages
-
Seamless connectivity to ControlNet for PCs
-
High-speed deterministic communication
-
Compatible with Honeywell Experion systems
-
Compact and lightweight for easy installation
-
Stable and proven module for demanding industrial use
Technical Specifications
| Parameter | Description |
|---|---|
| Model | TC-PCIC01 |
| Interface | ControlNet |
| Bus Type | PCI |
| Communication Type | Deterministic, real-time data exchange |
| Operating System Support | Windows-based systems (Honeywell certified) |
| Dimensions (W x H x D) | 156 x 88 x 20 mm |
| Weight | 0.34 kg |
| Operating Temperature | 0 to 60°C (32 to 140°F) |
| Humidity | 5% to 95% non-condensing |
Frequently Asked Questions (FAQ)
Q1: What is the function of the TC-PCIC01 module?
A1: It provides ControlNet communication for PCs in industrial control networks.
Q2: What type of bus does the TC-PCIC01 use?
A2: It uses the standard PCI bus for PC integration.
Q3: Can this module be used with non-Honeywell systems?
A3: It is optimized for Honeywell systems, but may support other ControlNet-compatible systems if properly configured.
Q4: What software is required for the TC-PCIC01?
A4: Honeywell-certified ControlNet drivers and configuration tools compatible with the operating system.
Q5: Is this module hot-swappable?
A5: No, the module must be installed with the system powered down.
Q6: Is the TC-PCIC01 still in production?
A6: It may be nearing legacy status; users should check with Honeywell for availability or alternatives.
Q7: Does it support redundant communication?
A7: No, TC-PCIC01 is a single-channel interface; redundancy requires additional hardware.
Q8: What ControlNet speed is supported?
A8: It operates at the standard ControlNet speed of 5 Mbps.
Q9: What form factor does it use?
A9: Standard half-height PCI card form factor.
Q10: How is the module typically used in Experion systems?
A10: It connects PC nodes like engineering workstations or operator stations to the ControlNet segment for control or data acquisition.
Related Models (Same Series or Function)
| Model | Description | Interface | Dimensions (mm) | Weight (kg) |
|---|---|---|---|---|
| TC-PCIC01K | TC-PCIC01 Kit with accessories | ControlNet | 156 x 88 x 20 | 0.36 |
| TC-PCIC02 | PCI-based ControlNet Interface Module | ControlNet | 156 x 88 x 20 | 0.34 |
| TC-CCN011 | ControlNet Interface Single Media | ControlNet | 120 x 90 x 20 | 0.32 |
| TC-CCN013 | ControlNet Interface Single Media | ControlNet | 120 x 90 x 20 | 0.33 |
| TC-CCR011 | ControlNet Redundant Media Interface | ControlNet | 120 x 90 x 20 | 0.35 |
| TC-PGCN11 | ControlNet Gateway Redundant Media | ControlNet | 180 x 100 x 25 | 0.45 |
