Product Introduction
The Ovation 1C31025G05 Analog Input Module is a high-performance and flexible module designed to receive and process analog input signals in industrial automation systems. As part of the Ovation control system by Emerson, this module is specifically designed to handle high-precision analog inputs, making it ideal for process control, monitoring, and data acquisition applications.
This module supports a variety of input types, including 0-10V, 4-20mA, and other common industrial signal formats. It is designed for use in high-speed systems where accurate data acquisition is critical. The Ovation 1C31025G05 module is equipped with features that ensure accurate signal processing and provide high input isolation to prevent signal interference, even in electrically noisy environments.
With its compact form factor, the module fits easily into DIN rail installations, providing a clean and easy installation process. The module is ideal for controlling systems that require continuous monitoring and precise control over processes, such as flow meters, pressure transmitters, temperature sensors, and other analog devices.
Product Specifications
| Parameter | Details |
|---|---|
| Model Number | 1C31025G05 |
| Module Type | Analog Input Module |
| Dimensions | 41 x 159 x 108 mm |
| Weight | 0.6 kg |
| Number of Inputs | 8 analog inputs |
| Input Range | 0-10V, 4-20mA (configurable) |
| Input Type | Voltage, Current |
| Resolution | 16-bit resolution |
| Accuracy | ±0.1% of full scale |
| Isolation | 1500V Isolation |
| Supply Voltage | 24V DC (nominal) |
| Environmental Rating | IP20 (protection against dust) |
| Operating Temperature | -10°C to +60°C |
| Mounting | DIN rail mounting |
Product Applications
The Ovation 1C31025G05 Analog Input Module is designed for a wide range of applications that require accurate analog signal input for real-time control and monitoring. Key applications include:
-
Process Control Systems: The module is ideal for use in systems that require precise measurement of variables such as temperature, pressure, and flow. It interfaces with instruments like pressure transmitters and flow meters to ensure accurate data input for process control systems.
-
Automation Systems: It is used in automated manufacturing systems where real-time control and feedback are required. The module receives signals from sensors and relays the data to the control system for further processing and decision-making.
-
Industrial Monitoring Systems: Used in systems that monitor critical industrial processes, the module helps in collecting continuous data from analog sensors to monitor process variables and detect potential issues early.
-
Energy Management: The module is utilized in energy management systems for reading data from energy meters, monitoring power consumption, and controlling power distribution systems.
-
Test and Measurement Equipment: In research and testing applications, the 1C31025G05 module is used to collect analog data from test equipment and provide the data to analysis systems for further testing.
-
Environmental Monitoring: The module is used in environmental monitoring systems to read signals from devices measuring environmental factors like humidity, temperature, and air quality.
Product Advantages
-
High-Precision Analog Input: With 16-bit resolution and ±0.1% accuracy, the Ovation 1C31025G05 ensures accurate and reliable analog signal processing for demanding applications.
-
Versatile Input Range: The module supports a wide range of input signals, including 0-10V and 4-20mA, making it compatible with a variety of industrial sensors and devices.
-
High Input Isolation: With 1500V isolation, the module is well-protected against electrical noise and voltage spikes, ensuring consistent and reliable data collection even in harsh industrial environments.
-
Compact and Space-Efficient: The module’s small size of 41 x 159 x 108 mm makes it ideal for installations where space is limited, while still providing up to 8 analog inputs for multi-channel applications.
-
Easy Installation: The DIN rail mounting feature allows for quick and easy installation in control cabinets, providing flexibility and ease of integration into existing systems.
-
Wide Operating Temperature Range: With an operating temperature range of -10°C to +60°C, the module can perform reliably in a variety of environmental conditions, from cold climates to hot industrial settings.
-
Durable and Robust Design: The module is designed to be used in industrial environments and is rated IP20 to protect it from dust, ensuring long-term reliability and minimal maintenance.
-
Energy-Efficient: The 24V DC supply voltage allows for low energy consumption, making the module ideal for large-scale industrial systems where energy efficiency is important.
FAQ
Q1: What types of input signals does the Ovation 1C31025G05 support?
The module supports 0-10V and 4-20mA input signals, which are common in industrial applications for sensors such as pressure transmitters, temperature sensors, and flow meters.
Q2: How many analog inputs are available on the Ovation 1C31025G05?
The module provides 8 analog inputs, allowing it to handle multiple signals from various sensors or devices in industrial control systems.
Q3: What is the resolution of the Ovation 1C31025G05?
The module features 16-bit resolution, ensuring high-precision data acquisition for accurate measurement of analog signals.
Q4: What is the accuracy of the Ovation 1C31025G05?
The module offers ±0.1% accuracy of full scale, ensuring reliable and consistent performance in demanding measurement applications.
Q5: What is the isolation rating of the Ovation 1C31025G05?
The module provides 1500V isolation, protecting the system from electrical noise and voltage spikes that could interfere with accurate signal processing.
Q6: What is the supply voltage for the Ovation 1C31025G05?
The module requires a 24V DC nominal supply voltage, which is typical for industrial-grade input modules.
Q7: What is the operating temperature range for this module?
The Ovation 1C31025G05 operates within a temperature range of -10°C to +60°C, making it suitable for use in a variety of industrial environments.
Q8: How is the Ovation 1C31025G05 mounted?
The module is designed for DIN rail mounting, providing easy integration into control panels and other industrial systems.
Q9: Can the Ovation 1C31025G05 handle high-speed applications?
Yes, the module is capable of handling high-speed applications due to its high resolution and fast response time for analog data acquisition.
Q10: Is the Ovation 1C31025G05 module suitable for use in outdoor environments?
While the module is IP20-rated for protection against dust, it is designed for indoor use. Additional protective enclosures are recommended for outdoor installations.
Recommended Related Models
| Model | Description |
|---|---|
| 1C31025G06 | A version with 16 analog inputs for larger-scale applications. |
| 1C31025G04 | A model with higher accuracy (±0.05%) for precise measurement in critical systems. |
| 1C31025G02 | A compact version with 4 analog inputs for smaller applications. |
| 1C31026G01 | A higher-density model with 12 analog inputs, suitable for complex monitoring systems. |
| 1C31030G01 | A model designed for high-temperature environments, with an extended operating range. |
| 1C31025G07 | A specialized version with built-in signal conditioning for certain sensor types. |
Popular Ovation Models
| Model | Description |
|---|---|
| 1C31035G01 | A multi-channel input/output module with flexible I/O configurations. |
| 1C31045G03 | A model with enhanced signal processing capabilities for high-speed control systems. |
| 1C31055G02 | A rugged input module designed for use in harsh industrial environments with high vibration. |
| 1C31065G01 | A low-power version of the analog input module, designed for energy-efficient applications. |
| 1C31075G04 | A heavy-duty model with extended surge protection for critical industrial processes. |
| 1C31085G03 | A versatile input/output module for industrial automation systems requiring high flexibility. |
