Product Introduction
The Ovation 1C31025G06 Digital Output Module is an essential component of the Ovation control system by Emerson. It is designed to provide high-density, reliable digital output control for industrial automation systems. With its 32 digital output channels, this module is perfect for applications that require the control of multiple external devices, such as motors, actuators, relays, and solenoids.
The module supports open-collector outputs, making it versatile and suitable for controlling a variety of devices that operate at different voltages and currents. The Ovation 1C31025G06 is engineered for industrial environments, offering robust protection against electrical surges, noise, and other disturbances, ensuring continuous, high-performance operation even in the most demanding conditions.
With its compact design and DIN rail mounting, the module can easily be integrated into existing systems, providing a space-efficient and cost-effective solution for controlling multiple devices simultaneously.
Product Specifications
| Parameter | Details |
|---|---|
| Model Number | 1C31025G06 |
| Module Type | Digital Output Module |
| Dimensions | 41 x 159 x 108 mm |
| Weight | 0.6 kg |
| Number of Outputs | 32 outputs |
| Output Type | Open Collector, 24V DC max |
| Output Current | 0.5 A per output |
| Supply Voltage | 24V DC (nominal) |
| Environmental Rating | IP20 (protection against dust) |
| Operating Temperature | -10°C to +60°C |
| Response Time | 20 ms (typical) |
| Isolation | 1500V Isolation |
| Mounting | DIN rail mounting |
Product Applications
The Ovation 1C31025G06 Digital Output Module is ideal for controlling a wide range of devices in industrial and automation applications. Key applications include:
-
Industrial Automation Systems: The module is used to control a wide variety of industrial devices such as relays, actuators, and solenoids in automated production lines and other complex systems.
-
Process Control Systems: It interfaces with equipment such as valves and motors in processes where precision and reliability are essential for controlling critical systems in industries like chemicals, oil, and gas.
-
Machine Control: The module provides digital outputs to control components like pumps, conveyors, and other machine parts in automated machinery.
-
Safety Systems: The Ovation 1C31025G06 is used in emergency stop circuits, enabling quick shutdowns of equipment in case of a fault or safety trigger, ensuring the protection of machinery and personnel.
-
Energy and Power Management Systems: This module is often used in energy distribution systems to control devices such as circuit breakers, transformers, and other power management equipment.
-
Test and Measurement Systems: The module is used for triggering and controlling test setups, where devices such as test relays and actuators need to be controlled for testing purposes.
Product Advantages
-
High Output Density: With 32 outputs, the Ovation 1C31025G06 allows for high-density control in industrial automation applications, minimizing the need for multiple modules and reducing space requirements.
-
High Reliability: The module offers 1500V isolation, which helps protect against electrical interference and ensures consistent performance even in noisy environments.
-
Compact and Space-Efficient: At 41 x 159 x 108 mm, the module is compact yet provides ample control for industrial systems, making it easy to integrate into existing setups.
-
Fast Response Time: The module boasts a 20 ms response time, providing quick actuation of connected devices and ensuring fast control in high-speed systems.
-
Robust and Durable: Designed with an IP20 rating, the module is protected against dust ingress, making it suitable for use in typical industrial environments.
-
Energy Efficient: The 24V DC nominal supply voltage ensures that the module operates efficiently, helping to reduce power consumption in large-scale systems.
-
Flexible and Versatile: The open-collector output configuration allows the module to control devices operating at different voltages and current levels, making it highly adaptable to various industrial needs.
-
Easy Installation: The module can be DIN rail mounted, making installation straightforward and saving time during setup. Its space-efficient design allows it to be placed alongside other modules in control cabinets.
FAQ
Q1: How does the Ovation 1C31025G06 Digital Output Module function?
The module provides 32 open-collector outputs to control devices such as relays and solenoids. It is powered by a 24V DC supply and can drive devices with a maximum current of 0.5 A per output.
Q2: What type of output does the Ovation 1C31025G06 support?
The module supports open-collector outputs, allowing it to control devices that require various voltage and current levels, typically used in industrial control systems.
Q3: How many outputs are available on this module?
The Ovation 1C31025G06 provides 32 outputs, making it suitable for controlling multiple devices simultaneously in industrial and automation applications.
Q4: What is the maximum current the Ovation 1C31025G06 can handle per output?
Each output can handle a maximum current of 0.5 A, suitable for controlling relays, actuators, and other low-power devices in automation systems.
Q5: What is the response time of the Ovation 1C31025G06?
The module has a typical response time of 20 ms, which is fast enough for high-speed control applications requiring quick device activation.
Q6: What is the isolation rating of the Ovation 1C31025G06?
The module offers 1500V isolation, which ensures that sensitive equipment is protected from electrical surges and noise, providing reliable operation in industrial environments.
Q7: What is the supply voltage for this module?
The Ovation 1C31025G06 operates on a 24V DC nominal supply voltage, which is standard for most industrial control systems.
Q8: How is the module mounted?
The module is designed for DIN rail mounting, which makes it easy to install in control panels or cabinets alongside other automation equipment.
Q9: What is the environmental rating of the module?
The module has an IP20 rating, which protects it from dust ingress, making it suitable for indoor industrial environments where dust and other small particles may be present.
Q10: Can the Ovation 1C31025G06 be used in high-speed applications?
Yes, with its fast response time of 20 ms, the module is well-suited for high-speed control tasks, such as in machine automation and process control systems.
